Specifications

• APPEARANCE
  • Door Panel Color : Custom Panel Required
  • Panel Capability : Integrated
  • Door Style : Fully integrated door for custom panels
  • Handle : Custom Handle Required
  • Color Appearance : Custom Panel and Handle Required
  • Installation : Flush Cabinet Installation
• ECONOMICAL / QUIET
  • Quiet Package : 51 dBA
  • Door Insulation : Insulation, Mastic
  • Outer Wrap : U-Blanket
  • Motor Type : Single Speed
  • Quiet Features : Sealed Toe Kick, Tub Collar Trim
• FEATURES
  • Lower Rack : Nylon
  • Leveling System : Leveling Legs
  • Dishwasher Options : Child Lock, Delay Start 1-12 Hr., Sani (Certified to NSF Standard 184), Start/Reset, TempBoost
  • Style : Built-In Top Control
  • Water Filtration System : 3-Stage Manual Clean Filtration
  • Rack Features : 1 Plastic Utility Shelf - Upper, 2 Piece Silverware Basket with Cell Covers, Ball-Tipped Tines, Stem Safe
  • Dishwasher Cycles : AutoSense, Heavy Wash, Light Wash
  • Wash System : 3-Level, Standard
  • Number of Place Settings : 12
  • Dispenser : Rinse Aid with Indicator and Adjustment
  • WiFi Connect : Optional (Requires part no. PBX23W00Y0)
  • Control Type : 4 Pushbuttons, Fully Integrated Electronic, Top Controls
  • Racking System : Gray
  • Exterior Style : Custom Panel
  • Sensor : Clean Sensor
  • Latch : Pull with Custom Handle (not included)
  • Number of Options : 5
  • Number of Cycles : 3
  • Tub and Door Liner : Stainless Steel
  • Wash Arms : 2 with Upper Nozzle
  • Connected Capabilities : Amazon Alexa, IFTTT, Sonos, The Google Assistant
  • Dishwasher Control Features : 3 Digit Countdown Display with 1 "Clean" light / 1 "Sanitized" light Cycle Progress Indicators, Audible End-of-Cycle Signal, Cycle Countdown, Last Cycle Memory, Start/Reset Pad
  • Dishwasher Drying Features : Condensate Dry
  • Wash System Features : Automatic HotStart, Automatic Temperature Control, Dual Pump, Flood Control System, Piranha™ Hard Food Disposer
  • Upper Rack : Adjustable, Nylon
• FILTER
  • App Filter - Cabinet Width : Dish Traditional 24 in.
  • App Filter - Stainless Steel Interior : Yes
  • App Filter - Product Type : Dish Built-In Top Control
  • App Filter - WiFi Connect : Optional
  • App Filter - Food Disposer : Yes
  • App Filter - Bottle Wash : No
• POWER / RATINGS
  • Energy Consumption (kWh/year) : 240
  • Power Connection : Optional cord kit (GPFCORD - WX09X70910, WX09X70911)
  • Electrical Requirements : 120V ; 60 Hz ; 8.9 A
• WARRANTY
  • Labor Warranty : Limited 1-year entire appliance
  • Warranty Notes : See written warranty for full details
  • Parts Warranty : Limited 1-year entire appliance
• WEIGHTS & DIMENSIONS
  • Cabinet Width : 24 in
  • Net Weight : 81 lb
  • Overall Width : 23.75 in
  • Overall Height : 32.25 in
  • Cutout Height (in) : 32 3/8 in
  • Cutout Width (in) : 24 in
  • Height w/ Legs Retracted - Minimum Height : 32.25 in
  • Approximate Shipping Weight : 96 lb
  • Overall Depth : 23.5 in
  • Height w/Legs Extended - Maximum Height : 34.625 in
  • Depth with Door Open : 23 in
  • Cutout Depth (in) : 24 in

Description

ADA-compliant design, ensuring accessibility for individuals with disabilities

Stainless steel interior for durability, easy maintenance, and a modern look

Panel-ready design allows for seamless integration with your kitchen cabinetry

Includes a sanitize cycle for thorough cleaning and sanitization of dishes

Quiet, efficient operation for effective cleaning without disrupting your space

Ideal for kitchens requiring ADA compliance, offering both functionality

Features

• ADA Compliant with Low-Profile Installation : Great for 34” counter top heights and raised subfloors
• 3-Level Wash : Expect exceptionally clean table-ready dishes with powerful wash arms
• Autosense Cycle : A beam of light measures soil levels and water temperature to adjust to the ideal cycle time
• Piranha™ hard food disposer with removable filter : To ensure consistently clean items, this stainless steel blade rotates to pulverize food particles and helps to prevent large particles from clogging the wash arms
• Sanitize option (NSF Certified) : High-temperature rinse sanitizes and reduces by 99.999% the bacteria found on dishes
• Quiet Package : dBA 51
