Specifications

• APPEARANCE
  • Handle : Towel Bar
  • Installation : Flush Cabinet Installation
  • Handle Color : Black
  • Door Style : Full-Length Flat Door
  • Color Appearance : Black
• ECONOMICAL / QUIET
  • Quiet Package : 51 dBA
  • Motor Type : Single Speed
  • Door Insulation : Insulation, Mastic
  • Quiet Features : Sealed Toe Kick, Tub Collar Trim
  • Outer Wrap : U-Blanket
• FEATURES
  • Sensor : Clean Sensor
  • Lower Rack : Nylon
  • Leveling System : Leveling Legs
  • Number of Place Settings : 12
  • Latch : Center Pull
  • Number of Options : 5
  • Style : Built-In Top Control
  • Rack Features : 1 Plastic Utility Shelf - Upper, 2 Piece Silverware Basket with Cell Covers, Ball-Tipped Tines, Stem Safe
  • Dishwasher Cycles : AutoSense, Heavy Wash, Light Wash
  • Dispenser : Rinse Aid with Indicator and Adjustment
  • Wash System : 3-Level, Standard
  • Control Type : 4 Pushbuttons, Fully Integrated Electronic, Top Controls
  • Dishwasher Drying Features : Condensate Dry
  • Wash Arms : 2 with Upper Nozzle
  • Wash System Features : Automatic HotStart, Automatic Temperature Control, Dual Pump, Flood Control System, Piranha™ Hard Food Disposer
  • Dishwasher Options : Child Lock, Delay Start 1-12 Hr., Sani (Certified to NSF Standard 184), Start/Reset, TempBoost
  • Racking System : Gray
  • Connected Capabilities : Amazon Alexa, IFTTT, Sonos, The Google Assistant
  • Dishwasher Control Features : 3 Digit Countdown Display with 1 "Clean" light / 1 "Sanitized" light Cycle Progress Indicators, Audible End-of-Cycle Signal, Cycle Countdown, Last Cycle Memory, Start/Reset Pad
  • Number of Cycles : 3
  • Water Filtration System : 3-Stage Manual Clean Filtration
  • WiFi Connect : Optional (Requires part no. PBX23W00Y0)
  • Tub and Door Liner : Stainless Steel
  • Upper Rack : Adjustable, Nylon
  • Exterior Style : Built-In
• FILTER
  • App Filter - Stainless Steel Interior : Yes
  • App Filter - Product Type : Dish Built-In Top Control
  • App Filter - Cabinet Width : Dish Traditional 24 in.
  • App Filter - WiFi Connect : Optional
  • App Filter - Bottle Wash : No
  • App Filter - Food Disposer : Yes
• POWER / RATINGS
  • Energy Consumption (kWh/year) : 240
  • Power Connection : Optional cord kit (GPFCORD - WX09X70910, WX09X70911)
  • Electrical Requirements : 120V ; 60 Hz ; 8.9 A
• WARRANTY
  • Warranty Notes : See written warranty for full details
  • Parts Warranty : Limited 1-year entire appliance
  • Labor Warranty : Limited 1-year entire appliance
• WEIGHTS & DIMENSIONS
  • Cutout Height (in) : 32 3/8 in
  • Cutout Width (in) : 24 in
  • Height w/ Legs Retracted - Minimum Height : 32.25 in
  • Cabinet Width : 24 in
  • Overall Width : 23.75 in
  • Overall Depth : 23.5 in
  • Overall Height : 32.25 in
  • Cutout Depth (in) : 24 in
  • Height w/Legs Extended - Maximum Height : 34.625 in
  • Depth with Door Open : 23 in
  • Net Weight : 81 lb
  • Approximate Shipping Weight : 96 lb

Description

ENERGY STAR certified for energy efficiency, reducing water and electricity consumption.

ADA compliant design ensures easy accessibility, ideal for individuals with specific accessibility needs.

Stainless steel interior provides durability, resists stains, and supports excellent cleaning results.

Sanitize Cycle eliminates bacteria, providing hygienically clean dishes.

Quiet operation ensures a peaceful kitchen environment while cleaning effectively.

Powerful performance for spotless dishes with every wash.

Energy-efficient and reliable, making it perfect for households seeking both performance and sustainability.

Meets accessibility standards, making it suitable for a wide range of users.

Features

• ADA Compliant with Low-Profile Installation : Great for 34” counter top heights and raised subfloors
• 3-Level Wash : Expect exceptionally clean table-ready dishes with powerful wash arms
• Autosense Cycle : A beam of light measures soil levels and water temperature to adjust to the ideal cycle time
• Piranha™ hard food disposer with removable filter : To ensure consistently clean items, this stainless steel blade rotates to pulverize food particles and helps to prevent large particles from clogging the wash arms
• Sanitize option (NSF Certified) : High-temperature rinse sanitizes and reduces by 99.999% the bacteria found on dishes
• Quiet Package : dBA 51
