Specifications

• APPEARANCE
  • Installation : Flush Cabinet Installation
  • Handle Color : White
  • Door Style : Full-Length Flat Door
  • Color Appearance : White
  • Handle : Towel Bar
• ECONOMICAL / QUIET
  • Door Insulation : Insulation, Mastic
  • Outer Wrap : U-Blanket
  • Motor Type : Single Speed
  • Quiet Package : 51 dBA
  • Quiet Features : Sealed Toe Kick, Tub Collar Trim
• FEATURES
  • Sensor : Clean Sensor
  • Lower Rack : Nylon
  • Leveling System : Leveling Legs
  • Number of Place Settings : 12
  • Dishwasher Options : Child Lock, Delay Start 1-12 Hr., Sani (Certified to NSF Standard 184), Start/Reset, TempBoost
  • Latch : Center Pull
  • Number of Options : 5
  • Style : Built-In Top Control
  • Dishwasher Cycles : AutoSense, Heavy Wash, Light Wash
  • WiFi Connect : Optional (Requires part no. PBX23W00Y0)
  • Racking System : Gray
  • Dishwasher Drying Features : Condensate Dry
  • Wash Arms : 2 with Upper Nozzle
  • Wash System Features : Automatic HotStart, Automatic Temperature Control, Dual Pump, Flood Control System, Piranha™ Hard Food Disposer
  • Dispenser : Rinse Aid with Indicator and Adjustment
  • Connected Capabilities : Amazon Alexa, IFTTT, Sonos, The Google Assistant
  • Dishwasher Control Features : 3 Digit Countdown Display with 1 "Clean" light / 1 "Sanitized" light Cycle Progress Indicators, Audible End-of-Cycle Signal, Cycle Countdown, Last Cycle Memory, Start/Reset Pad
  • Tub and Door Liner : Stainless Steel
  • Rack Features : 1 Plastic Utility Shelf - Upper, 2 Piece Silverware Basket with Cell Covers, Ball-Tipped Tines, Stem Safe
  • Control Type : 4 Pushbuttons, Fully Integrated Electronic, Top Controls
  • Wash System : 3-Level, Standard
  • Water Filtration System : 3-Stage Manual Clean Filtration
  • Exterior Style : Built-In
  • Upper Rack : Adjustable, Nylon
  • Number of Cycles : 3
• FILTER
  • App Filter - Food Disposer : Yes
  • App Filter - Cabinet Width : Dish Traditional 24 in.
  • App Filter - Stainless Steel Interior : Yes
  • App Filter - Bottle Wash : No
  • App Filter - Product Type : Dish Built-In Top Control
  • App Filter - WiFi Connect : Optional
• POWER / RATINGS
  • Energy Consumption (kWh/year) : 240
  • Electrical Requirements : 120V ; 60 Hz ; 8.9 A
  • Power Connection : Optional cord kit (GPFCORD - WX09X70910, WX09X70911)
• WARRANTY
  • Labor Warranty : Limited 1-year entire appliance
  • Parts Warranty : Limited 1-year entire appliance
  • Warranty Notes : See written warranty for full details
• WEIGHTS & DIMENSIONS
  • Height w/ Legs Retracted - Minimum Height : 32.25 in
  • Overall Depth : 23.5 in
  • Cutout Height (in) : 32 3/8 in
  • Cabinet Width : 24 in
  • Overall Height : 32.25 in
  • Cutout Depth (in) : 24 in
  • Cutout Width (in) : 24 in
  • Net Weight : 81 lb
  • Height w/Legs Extended - Maximum Height : 34.625 in
  • Depth with Door Open : 23 in
  • Approximate Shipping Weight : 96 lb
  • Overall Width : 23.75 in

Description

ADA-compliant design to ensure accessibility for individuals with disabilities

High-quality, durable stainless steel interior for a modern and long-lasting appearance

Sanitize cycle for effective dish cleaning and sanitization

Designed for efficient operation with powerful cleaning performance

Optimized for kitchens requiring ADA compliance, enhancing space and functionality

Reliable and convenient dishwasher solution for homes or businesses

Features

• ADA Compliant with Low-Profile Installation : Great for 34” counter top heights and raised subfloors
• 3-Level Wash : Expect exceptionally clean table-ready dishes with powerful wash arms
• Autosense Cycle : A beam of light measures soil levels and water temperature to adjust to the ideal cycle time
• Piranha™ hard food disposer with removable filter : To ensure consistently clean items, this stainless steel blade rotates to pulverize food particles and helps to prevent large particles from clogging the wash arms
• Sanitize option (NSF Certified) : High-temperature rinse sanitizes and reduces by 99.999% the bacteria found on dishes
• Quiet Package : dBA 51
