Specifications

• Door
  • T1SF Door Tint Reflective door tint in dark smoke finish for maximum energy savings on full-size and two-door models : T4F Door Tint Neutral door tint in light smoke finish for moderate energy savings
  • T3F Door Tint Reflective door tint in light blue finish for medium energy savings : T2F Door Tint Tinted door in reflective deep blue finish with high energy savings
• Exterior
  • KEY Extra keys available for purchase : LHD Door reversal to left hand swing
• Overview
  • Depth: 26.63" (68 cm)
  • Depth with Handle: 27.75" (70 cm)
  • Depth with door at 90°: 48.75" (124 cm)
  • Compressor Warranty: 5 Years
  • Height of Cabinet: 69.75" (177 cm)
  • Weight: 187.0 lbs. (85 kg)
  • Shipping Weight: 220.0 lbs. (100 kg)
  • Parts & Labor Warranty: 1 Year
  • Amps: 1.7
  • Voltage/Frequency: 115 V AC/60 Hz
  • Width: 23.63" (60 cm)
  • Capacity: 15.9 cu.ft. (450 L)
  • Bottles: 160 bottles
  • Defrost Type: Automatic
  • Door: Glass
  • Cabinet: Black
  • US Electrical Safety: ETL
  • Canadian Electrical Safety: ETL-C
• Wine Cellar
  • Interior Width 2: 19.75" (50 cm)
  • Number of Zones: 2
  • Door Swing: RHD
  • Reversible: Yes
  • Thermostat Type: Digital
  • Interior Light: Yes
  • Fan Type: Interior and Exterior
  • Refrigerant Type: R600a
  • High Side PSI: 270.0
  • Compressor Step Height: 3.75" (10 cm)
  • Low Side PSI: 105.0
  • Interior Height 1: 29.5" (75 cm)
  • Interior Width 1: 19.75" (50 cm)
  • Compressor Step Width: 19.75" (50 cm)
  • Compressor Step Depth: 5.5" (14 cm)
  • Temperature Range: 41°F to 55°F (upper zone); 55°F to 72°F (lower zone)
  • Interior Depth 2: 21.0" (53 cm)
  • Refrigerant Amount: 1.91 oz.
  • Interior Depth 1: 21.0" (53 cm)
  • Interior Height 2: 31.0" (79 cm)
  • Shelf Qty: 14
  • Shelf Type: Wood

Description

15.9 Cu.Ft/160 Bottle Capacity: Ample space to store up to 160 bottles of wine, ensuring your collection is well-organized and easily accessible.

14 Wooden Slide-Out Shelves: Provides smooth access to your wine, allowing easy placement and removal of bottles while offering a premium look.

Dual Temperature Zones: Store red and white wines at their optimal temperatures with independent control for each zone.

Digital Thermostat: Precisely regulate and monitor the internal temperature for perfect wine preservation.

High Temperature Alarm: Alerts you if the internal temperature rises beyond the optimal range, keeping your wine safe.

Open Door Alarm: Notifies you when the door is left open, preventing temperature fluctuations that could affect your wine.

Temperature Memory Function: Retains the set temperature settings in case of a power outage, ensuring a consistent environment.

Factory Installed Lock: Provides added security, preventing unauthorized access to your wine collection.

Automatic Defrost: Maintains optimal conditions by automatically defrosting, eliminating frost build-up.

Black Cabinet, Left Hinge: Sleek and modern design with a black finish, fitting seamlessly into your kitchen or wine cellar with a left hinge for door opening.

Features

• Large capacity: Interior can hold up to 160 standard 750ml Bordeaux style bottles. If using this wine cellar for wider Burgundy style bottles, you can hold up to 118. For champagne, the interior can hold 22 bottles (plus an additional 132 of the standard Bordeaux style)
• Double pane tempered glass door: Slightly tinted glass provides full view of interior, with a stainless steel trim for added accent
• Two temperature zones: Lower zone is ideal for storing red wine (temperature range: 55ºF to 72ºF) while the upper zone accommodates white and sparkling wine stored between 41ºF and 55ºF
• Digital thermostats: Set and adjust two temperature zones separately with easy-to-use digital controls with an LED display in Celsius or Fahrenheit
• LED lighting: Recessed lighting offers an elegant, efficient view of your collection
• Slide-out wooden shelves: 14 wooden shelves offer proper storage
• Factory installed lock: Keyed lock for trusted security
• Reversible door: User-reversible door swing allows for more flexibility in placing the unit
• Fully finished black cabinet: Allows the unit to be used freestanding
• Professional handle: Stainless steel handle completes the professional look
• Automatic defrost: Reduced user maintenance with auto defrost operation
• Modified built-in use: Unit can be installed in built-in applications with at least 2" of clearance in the rear to ensure adequate ventilation
• High temperature alarm: Audible alarm sounds if the storage temperature rises out of recommended range
• Open door alarm: Alarm sounds if the door is left open for more than 60 seconds
• Temperature Memory Function: Unit will retain its last settings when power is restored in the event of power loss
• Sabbath Mode: Optional setting lets you disable the lighting and alarm for up to 96 hours
• Stainless steel kickplate: Sleek look with added protection
• 100% CFC free: Environmentally safe operation with no ozone-damaging chemicals
