Specifications

• Accessories
  • Optional Air Fry Tray Part Number : FRIGPEREAFT
  • Optional Trim Kit Part Number : WOMC3TRIMSS, WOMC3TRIMDSS
• Controls
  • Control Lock : Yes
  • Sabbath Mode : Yes
• Cooking Controls
  • Air Sous Vide : Yes
  • Bake Time : Yes
  • Broil : Yes
  • Child Lock : Yes
  • Clear Off : Yes
  • Clock : Yes
  • Convection Roast : Yes
  • Cook Time : Yes
  • Dehydrate : Yes
  • Delay Clean : Yes
  • Delay Start : Yes
  • Fast Preheat : Yes
  • Keep Warm : Yes
  • Kitchen Timer : Yes
  • Light : Yes
  • Off : Yes
  • Air Fry : Yes
  • Cancel : Yes
  • Quick Preheat : Yes
  • Set Clock : Yes
  • My Favorite : Yes
  • Perfect Turkey : Yes
  • Start Time : Yes
  • Steam Clean : Yes
  • Steam Roast : Yes
  • Stop : Yes
  • Temperature Display : Yes
  • Bake : Yes
  • Oven Light : Yes
  • Start : Yes
  • Timer On / Off : Yes
  • Bread Proof : Yes
  • Convection Bake : Yes
  • Preheat : Yes
  • Probe : Yes
  • Self Clean : Yes
  • Steam Bake : Yes
  • User Preferences : Yes
  • Slow Cook : Yes
  • Timed Bake : Yes
  • No Preheat : Yes
• Cooking Controls Function
  • Change between Continuous Bake Setting or 12-Hour Energy Saving Feature : Yes
  • Delayed Bake : Yes
  • Silent Control Panel : Yes
  • Timed Cooking : Yes
  • Program Fahrenheit or Celsius : Yes
• Dimensions and Volume
  • Lower Oven Interior Width : 25 1/5"
  • Lower Oven Interior Depth : 19 7/8"
  • Upper Oven Interior Height : 18 1/8"
  • Upper Oven Interior Width : 25 1/5"
  • Maximum Cutout Height : 50 1/4"
  • Oven Lower Capacity : 5.3 Cu. Ft.
  • Oven Upper Capacity : 5.3 Cu. Ft.
  • Total Capacity : 10.6 Cu. Ft.
  • Minimum Cutout Height : 48 7/8"
  • Depth With Door 90° Open : 48 3/16"
  • Depth With Handle : 27 3/5"
  • Lower Oven Interior Height : 18 1/8"
  • Upper Oven Interior Depth : 19 7/8"
  • Minimum Cutout Width : 28 1/2"
  • Maximum Cutout Width : 29"
• Display
  • Display Type : Capacitive Touch
  • Display Interface Color : White
  • Display Light Color : White
• Electrical Specifications
  • Amps @ 240 Volts : 40 Amps
  • Connected Load @ 240V : 9 kW
  • Minimum Circuit Required : 40 Amps
  • Voltage Rating : 240 V
• Exterior
  • Exterior Finish : Smudge-Proof® Stainless Steel
  • Handle Color : Stainless Steel
• General Specifications
  • Frigidaire Fit Promise : Yes
  • Product Weight : 260 lbs
  • Prop 65 Label : Yes
  • Warranty - Labor : 1 Year
  • Warranty - Parts : 1 Year
  • AB-1200 : Information available at frigidaire.com/en/ab1200
• Installation
  • Power Supply Connection Location : Top Left
• Oven
  • Bake Element Pass : 8
  • Bake Element Type : Hidden
  • Broil Element : 4000 Watts
  • Broil Element Pass : 6
  • Broil System : Yes
  • Convection Element : 3800 Watts
  • Convection Type : Total
  • Number of Convection Fans : 1
  • Cleaning System : Yes
  • Bake Element : 2500 Watts
  • Convection : Yes
  • Rack Position Type : Embossed
  • Oven Light Watts : 40 Watts
  • Number of Rack Positions : 6
  • Oven Interior Color : Midnight Black
  • Oven Light Quantity : 2
  • Oven Light Type : Halogen
  • Rack Type 1 : Flat
  • Rack Type 1 Quantity : 5
  • Rack Type 2 : Glide
  • Rack Type 2 Quantity : 1
• Safety Certifications and Approvals
  • RoHS : Yes
  • UL Listed : Yes
  • CSA Listed : Yes

Description

• 30-inch double electric wall oven with a spacious 10.6 cu. ft. total capacity, ideal for cooking large meals
• Air Fry function for healthier cooking with less oil, delivering crispy and delicious results
• Total Convection ensures even heat distribution for perfectly cooked dishes
• Self-cleaning function for effortless oven maintenance
• Touch screen control panel provides an intuitive and modern cooking experience
• No preheat function for faster cooking times, saving you time in the kitchen
• Steam bake option enhances baking by adding moisture for crispier, more flavorful results
• Temperature probe for precise cooking and accurate results
• Glide rack allows for easy access to dishes, even when the oven is full
• Air Sous Vide feature for precision cooking, delivering perfectly cooked meats and vegetables
• Control lock feature for added safety, especially in homes with children
• Sabbath mode for religious observances, ensuring compliance with cooking restrictions
• Star-K certified for guaranteed kosher cooking standards

Features

• Gives you maximum versatility in the kitchen, powering cooking modes like Air Fry, No Preheat, Slow Cook, Convection Bake, Steam Bake, Convection Roast, Steam Roast, Air Sous Vide, Bread Proof, Dehydrate and more!
• Eliminates time wasted waiting on your oven to heat up - simply place your food in the cold oven and get to meal time, in no time.
• Make healthier and delicious meals for your entire family - right in your oven.
• With Slow Cook, your food cooks slowly and at a lower temperature (as low as 100° F), allowing you to lock in moisture and flavor without over or undercooking your food.
• With Steam Bake, steam evenly circulates throughout the oven cavity, resulting in breads and muffins that rise higher and are light and fluffy.
• Monitors and alerts when the desired finished cooking temperature has been reached.
• We promise that your new 30" Frigidaire® Gallery double wall oven will fit your existing cabinet cutout of the same width and configuration, or we will reimburse you up to $300 for cabinet modification costs.
• Enjoy more cleaning flexibility. Select Steam Clean for a quick, 30 minute clean or choose Self Clean, which is available in 2, 3 and 4 hour cycles.
• Steam Roast uses moisture to make perfectly crispy and tender meats and vegetables that are roasted to perfection.
• Features a responsive 4.3 inch, full color, capacitive touch digital control panel.
• Uses precisely-controlled temperature and airflow to lock in flavor and moisture to cook foods to the finish temperature you want.
• Our extending Glide Rack makes it easier to monitor and lift your food out of the oven.
• Cook more at once with a combined 10.6 cu.ft. of oven capacity.
• Resists fingerprints and cleans easily.
• Optional ReadyCook™ Air Fry Tray allows you to achieve perfectly crispy and delicious results.
