Specifications

• General
  • Appliance Type: Range Hoods
  • CCC Code Compliance Control: Yes
  • CFM Speed 1: 160
  • Control Type: Backlit LED
  • Returnable: No
  • Sones Speed 3: 4
  • Sones Speed 4: 6.5
  • Product Weight: 27
  • CFM Speed 4: 600
  • Color/Finish: Stainless
  • Commerical/Residential: Residential
  • Install Type: Wall chimney mount
  • Installation Type: Wall chimney mount
  • LIght Colors: White
  • Sones Speed 1: 1
  • Sones Speed 2: 2.5
  • Frequency (Hz): 60 Hz
  • CFM Speed 2: 250
  • CFM Speed 3: 395
  • Cooktop Lights: Twin LED Lights
  • Vent Material: Metal
  • Controls: Code Compliance Electronic Controls
  • Location: Indoor
  • Warranty 2 Explained: 2 Year Limited Material And Workmanship for the original owner
  • Filter Type: Dishwasher Safe Mesh Filters
  • Lighting Features: 3000K LED
  • Number of Light Bulbs: 2
  • Number of Speeds: 4
  • Control Lighting: Blue Backlit
  • Amperage: 3.6 Amps
  • Electrical: 120V - 60Hz - 3.6 Amps
  • Maximum Air Flow Capacity CFM): 600/395
  • Minimum Air Flow Capacity (CFM): 160
  • Mounting Height Above Cooktop: 27 - 32
  • Vent Location: Top
  • Sound Level: 1.0-6.5 Sones
  • Certification: UL
  • Wattage (watts): 430 watts
  • Warranty 1 Explained: 90 Day Love It Or Leave It
  • Light Type: Twin LED Lights
  • Wireless Compatibility: No
  • Voltage (volts): 120 VAC
  • Duct Size: 6 Dia.
  • Ductless Convertible: Ducted or Convertible

Description

• 4-Speed 600 CFM Internal Blower
  Offers powerful ventilation with adjustable airflow settings (395 or 600 CFM) to suit your cooking needs.

• Code Compliant Control
  Meets the required standards for safe and efficient operation in compliance with local regulations.

• Push Button Controls
  Easy-to-use push-button interface for fan speed and lighting control.

• LED Lights
  Energy-efficient LED lights beautifully illuminate your cooking area, offering both brightness and style.

• Convertible to Recirculating
  Can be easily converted to a ductless setup with an optional recirculating kit (sold separately), providing flexibility in installation.

• Sleek Designer Chimney Style
  Stylish, modern design that enhances the look of your kitchen while providing high performance.

• Dimensions
  Width: 36''
  Depth: 19 11/16''
  Height: Adjustable for different installation needs.

Features

• Backlit Electronic 4 Speed Control with Power Boost
• CCC Code Compliance Control – permanently set blower to 395 or 600 CFM to meet local codes
• High Efficiency 3000K LED lights brightly illuminate the cooktop
• Dishwasher Safe Aluminum Mesh Filter for efficient filtration
• 5 Minute Delay Shutoff Timer
• Convertible 6 in. Vertical Duct or Ductless Recirculating (Kit Sold Separately)
• Standard Chimney fits ceilings up to 9 in. tall (optional 10 in. duct extension)
• Made In Italy
• 2 year limited parts and labor warranty for the original owner
• NOTE *When CCC is enabled the number of fan speeds will be reduced to maximum 3 speeds
