Specifications

• Certifications
  • Star K Certified: No
  • Prop65: Standard
  • Energy Star Qualified: No
• Controls
  • Control Location: Front
  • Control Type: Push Button
• Details
  • Hood And Vent Selections: Fan Off/Decrease Speed; Fan On/Decrease Speed; Lamp On/Off; Timer
  • Lighting Control Type: Push Button
  • Damper Included: No
  • Hood Type: Wall-Mount Canopy
  • Number Of Task Light Settings: 1
  • Number Of Vent Speeds: 3
  • Task Lighting: Yes
• Dimensions
  • Canopy Height: 11.6
  • Carton Depth: 14 inches
  • Gross Weight: 40 pounds
  • Net Weight: 27 pounds
  • Carton Height: 25.5 inches
  • Carton Width: 40 inches
• Electrical
  • Power Cord Included: No
• Ventilation Details
  • Auto Function: No
  • BTU Threshold: 65 K
  • Blower Type: Centrifugal
  • Duct Direction: Vertical
  • Duct Outlet Size: 6
  • Duct Type: Round
  • Exhaust Vent Location: Top
  • HVI (CFM HS Vertical): 270
  • Maximum Motor CFM: 400
  • Night Light: No
  • Night Light Type: N/A
  • Sones High Speed Vertical: 5
  • Sound Max Speed (Sones): 5
  • Sound Min Speed: 0.7
  • Sound Min Speed (Sones): 0.7
  • Task Light Type: LED
  • Vent Material: Metal
  • Venting: Exterior or Recirculating
  • Duct Length: 42.056
  • Filters: Dishwasher Safe Grease Filter
  • Blower Motor: Blower Motor Included
  • Sound Max Speed: 5

Description

Size: 36 inches

Blower: 400 CFM internal blower for efficient and powerful ventilation

Ventilation: Convertible ventilation for flexible installation options

Controls: User-friendly electronic controls for easy operation

Lighting: LED task lighting for bright, energy-efficient illumination

Filter: Dishwasher-safe filter for easy cleaning and maintenance

Material: Fingerprint resistant stainless steel for a sleek, smudge-free finish

Features

• 3-Speed, 400 CFM Motor Class: Helps remove smoke, odor and moisture with 400 CFM Motor Class hood venting that helps keep your kitchen clean. Three fan speeds provide the right amount of ventilation for every meal you prepare.
• Dishwasher-Safe Grease Filter: Dishwasher-safe filters trap unwanted grease and odors and wash easily for re-use.
• LED Task Lighting: Bright, long-lasting LED Task Lighting makes it easy to see what you’re cooking.
• Vent Timer: The Vent Timer automatically turns off the fan according to the timer so you can set it and forget it.
• Filter Replacement Reminder: Get reminded when its time to clean your grease filter and replace your charcoal filter to keep your hood running smoothly.
• 65K BTU Cooktop Threshold: Handle the heat and cooking power of a gas cooktop with up to 65K total BTUs or any electric cooktop.
• 7 Sones Sound Level at high speed (When configured for outside ventilation. As published by aham.org.): Stay focused on cooking and making memories in the kitchen, even when venting at the highest speed. At maximum speed, sound level is 7 Sones.
• Electronic Controls with Display: Clean the smooth, flat surface of these controls as easily as you use them.
• Convertible Ventilation (recirculating or vented): A convertible design allows for installation that can be vented externally or internally. When venting internally a recirculation kit is required and sold separately. Air passes through charcoal filters to trap grease and odors before pushing the air back into the home.
• 6" Round Damper Included: Help regulate the flow of air through the chimney with the included 6" round damper (part number W10446915).
• Optional Chimney Extension Kit: Extend chimney height for ceilings over 9 feet with the optional chimney extension kit. See installation instructions for details.
• Optional Recirculation Kit (non-vented/duct-free): This hood can be installed without needing to vent outside. Recirculation passes the air through filters to trap grease and odors before pushing the air back into the home. Recirculation kit sold separately. Part number W11548457.
