Specifications

• Certifications
  • Energy Star Qualified: No
  • Prop65: Standard
• Controls
  • Control Location: Front
  • Control Type: Push Button
• Details
  • Damper Included: Yes
  • Hood Type: Wall-Mount Canopy
  • Lighting Control Type: Push Button
  • Number Of Task Light Settings: 1
  • Number Of Vent Speeds: 3
  • Task Lighting: Yes
  • Hood And Vent Selections: Fan High; Fan Med; Fan On/Off; Lamp
• Dimensions
  • Canopy Height: 11.8
  • Carton Depth: 14 inches
  • Carton Height: 25.5 inches
  • Carton Width: 34 inches
  • Gross Weight: 34 pounds
  • Net Weight: 24 pounds
• Electrical
  • Power Cord Included: No
• Ventilation Details
  • Blower Type: Centrifugal
  • Duct Direction: Vertical
  • Duct Length: 42
  • Duct Outlet Size: 6
  • Duct Type: Round
  • Exhaust Vent Location: Top
  • Auto Function: No
  • Blower Motor: N/A
  • HVI (CFM HS Vertical): 350
  • Maximum Motor CFM: 350
  • Minimum Motor CFM: 80
  • Night Light Type: N/A
  • Sound Max Speed: 7.5
  • Sound Max Speed (Sones): 7.5
  • Sones High Speed Vertical: 7.5
  • Sound Min Speed (Sones): 0.7
  • Task Light Type: LED
  • Vent Material: Metal
  • CFM Motor Class: 400
  • BTU Threshold: 65 K
  • Filters: Aluminum Mesh Filter
  • HVI (CFM HS Horizontal): N/A
  • Sones High Speed Horizontal: N/A
  • Sound Min Speed: 0.7
  • Venting: Exterior or Recirculating

Description

• 3-Speed/400 CFM Motor
  Efficient 3-speed motor providing 400 CFM for effective smoke and odor removal.

• Push-Button Controls
  Simple and easy-to-use push-button controls for adjusting fan speeds and lighting.

• LED Task Lighting
  Bright and energy-efficient LED lighting that illuminates the cooking area for better visibility.

• Dishwasher-Safe Grease Filters
  Easy-to-clean, dishwasher-safe grease filters for low maintenance and long-lasting performance.

• Flexible Ventilation Options
  Can be installed as ducted or non-ducted (recirculating) based on your kitchen's ventilation needs.

• ADA Compliant
  Designed to be accessible, meeting ADA requirements for kitchens with specific accessibility needs.

Features

• • 3-Speed/400 CFM Motor
    Efficiently removes smoke, odors, and moisture with a 400 CFM motor. Three fan speeds offer customizable ventilation for all your cooking needs.

  • Push-Button Controls
    Easily control fan speed and cooktop lighting with simple push-button controls.

  • LED Work Surface Lighting
    Provides bright, even lighting over your cooktop for improved visibility while cooking.

  • Dishwasher Safe Grease Filters
    Traps grease and removes odors; filters can be easily removed and washed in the dishwasher for hassle-free maintenance.

  • 65K BTU Cooktop Threshold
    Designed to handle up to 65,000 BTUs on gas cooktops, ensuring it performs well with both gas and electric cooking surfaces.

  • 7.5 Sones Sound Level at High Speed
    Operates at a sound level of 7 Sones when venting at the highest speed, maintaining a comfortable noise level even at maximum performance.

  • Convertible Ventilation (Recirculating or Exhaust)
    Offers flexible ventilation options, allowing you to vent fumes outside or filter and recirculate air within the kitchen.

  • Optional Chimney Extension Kit Available
    Extends chimney height to accommodate ceilings over 9 feet.

  • Additional Features
    Includes a 6-inch round damper and optional recirculation kit (sold separately). ADA Compliant for accessibility.
