Specifications

• Certifications
  • UL: Yes
  • CUL: Yes
  • Prop65: Standard
  • ADA Compliant: No
• Controls
  • Electronic Display Type: LED
  • Display Color: Blue
• Cooktop Details
  • Auto Re-Ignition: No
  • Cooktop Control Knob Type: Weighted
  • Cooktop Control Location: Front
  • Cooktop Control Type: Knobs
  • Cooktop Surface Material: Porcelain Coated Steel
  • Griddle Included: Included
  • Hot Surface Indicator Light: No
  • Ignition Type: Direct Spark Ignition
  • Heating Element On Indicator Light: No
  • Cooktop Control Knob Color: Black Stainless
  • Cooktop Surface Color: Black
• Details
  • Automatic Convection Conversion Temperature Adjust: No
  • Oven Selections: Audible Signal; Broil; Cancel/Off; Clock; Control Lock; Convect Modes; Cook Time Indicator; Delay Start; Frozen Bake; Keep Warm Setting; Language Conversion; Sabbath Mode; Start Time; Stop Time; Timer
  • Fuel Type: Gas
  • LP Convertible: Yes - Kit Included
  • Oven Automatic Shut-Off: Yes
  • Oven Configuration: Single Oven
  • Oven Light Switch Location: Oven Control
  • Power On Indicator Light: No
  • Power Outage Compatible: Yes
  • Range Configuration: Freestanding
  • Range Type: Freestanding
  • Range Drawer Type: Storage Drawer
• Dimensions
  • Cutout Depth: 24
  • Cutout Height: 36
  • Cutout Width: 30
  • Depth Closed Excluding Handles: 25.313
  • Depth Closed Including Handles: 27.375
  • Depth With Door Open 90 Degree: 48
  • Oven Interior Height: 20
  • Oven Interior Width: 24.375
  • Carton Width: 32 inches
  • Gross Weight: 202 pounds
  • Net Weight: 187 pounds
  • Oven Interior Depth: 20.75
  • Carton Depth: 29 inches
  • Carton Height: 48.75 inches
• Electrical
  • Power Cord Included: Yes
• Element/Burner Details
  • Center Rear Element-Burner Power: 8,000 BTU
  • Center Rear Element-Burner Type: Oval Burner
  • Cooktop Element Style: Gas Burner
  • Left Front Element-Burner Power: 18,000 BTU
  • Left Front Element-Burner Type: High Output
  • Left Rear Element-Burner Type: Burner
  • Number Of Cooking Element-Burners: 5
  • Right Front Element-Burner Power: 15,000 BTU
  • Right Front Element-Burner Type: Burner
  • Right Rear Element-Burner Power: 5,000 BTU
  • Left Rear Element-Burner Power: 9,500 BTU
  • Right Rear Element-Burner Type: Simmer
• Exterior Details
  • Oven Control Location: Backguard
  • Oven Control Type: Electronic Touch
  • Handle Color: Black Stainless
  • Oven Window Size: Extra Large
  • Door Type: Metal & Glass
  • Handle Material: Metal
  • Handle Type: Reach Through Handle
• Grate Details
  • Grate Details: Dishwasher Safe; Hinged; Matte Finish; Porcelain Coated Cast Grates; Recessed
  • Number Of Grates: 2
• Oven Details
  • Convection Functions: Bake
  • Natural Gas Convertible: Yes
  • Number Of Oven Lights: 1
  • Number Of Oven Racks: 3
  • Oven Cleaning Type: AquaLift® Self Clean
  • Oven Cooking System: Convection
  • Oven Light Type: Incandescent
  • Oven Rack Type: 2 Standard and 1 Max Capacity
  • Interior Color: Grey
  • Number Of Rack Guides: 7
  • Door Removable: Yes
  • Hidden Bake Element: Yes
  • Broiler Location: Top of Oven
  • Convection Element Type: Fan
  • Bake Element Power: 18,000 BTU
  • Broiler Element Power: 11,000 BTU

Description

Skip preheating with Frozen Bake� technology. This freestanding gas range with self-cleaning oven lets you cut out routine steps so you can get dinner items like pizza to the table quickly. Get quick access to spills, too, with EZ-2-Lift� hinged cast-iron grates that let you wipe up under them without removing them.

Features

• EZ-2-Lift™ Hinged Cast-Iron Grates: Get quick access to spills on the cooktop with our industry-first EZ-2-Lift™ hinged cast-iron grates. The hinged design lets you wipe up under them without removing them. For a more thorough clean, the grates are also dishwasher-safe.
• Frozen Bake™ technology: Skip preheating and cook frozen favorites like pizza in fewer steps with preprogrammed settings.
• Fan Convection Cooking: Cook meals consistently with a fan in the back of the oven that distributes hot air more efficiently. This helps eliminate cold spots so you can bake on any rack.
• Fingerprint Resistant: Available in black stainless and stainless finishes that are easy to clean and resist fingerprints and smudges.
• SpeedHeat™ Burner: Get dinner to the table fast with this burner that generates the high heat needed to sear and boil quickly.
• Center Oval Burner: Easily fit large griddles and other longer cookware on this fifth burner so they heat evenly on the cooktop.
• Keep Warm Setting: Keep dishes from getting cold with this setting that delivers low heat to the oven while you finish preparing your meal.
• AquaLift® Self-Cleaning Technology
• Temperature Sensor: Get evenly-baked food with a sensor that monitors oven temperature and adjusts the cooking elements.
• Griddle: Make pancakes, grill vegetables or sear steaks with the included griddle that lets you cook breakfast, lunch and dinner right on the cooktop.
• 5.8 cu. ft. Capacity: Cook even your largest meals with 5.8 cu. ft. capacity.
• Large Oven Window: Keep an eye on your meal and track cooking progress through the Large Oven Window.
• Dishwasher-safe knobs: Make cleanup easy by washing knobs right in the dishwasher.
• Designed, engineered and assembled in the U.S.A.
