Specifications

• General
  • Product Dimensions: 36" W x 19 3/4" D x 2 3/4" H
  • Ducted Hood Height: Min 22 13/16" - Max 40 15/16"
  • Duct: Diameter 6"
  • Convertible/Recirculating: Yes
  • Color/Finish: Stainless Steel
  • Air Flow: Low - 232 CFM Medium - 330 CFM High - 550 CFM
  • Warranty: 2 Years Parts & Labor
  • Eletrical: Requires a minimum of 120V/60Hz/3A
  • Compatible Accessories: Charcoal Filter (FT0136) Recirculating Kit (ARC3601T) 10ft Duct Extension (RHDC01AT) *Not included must be purchased separately
  • Noise Level: Low - 47 dBA Medium - 55 dBA High - 65 dBA
  • Filter Type: Aluminum Mesh
  • Control Type: 3 Speed Touch Control

Description

• 3-Speed 550 CFM Blower
  Efficiently removes smoke, steam, and odors with adjustable fan speeds, providing optimal air circulation for different cooking needs.

• Touch Control
  Offers a sleek and easy-to-use interface to control fan speed and lighting with just a tap.

• LED Lighting
  Bright, energy-efficient LED lights illuminate your cooking area for better visibility and precision.

• 5-Layer Aluminum Mesh Filter
  Effectively traps grease and particles, and is dishwasher-safe for easy cleaning and maintenance.

• Heat Sensor
  Automatically detects temperature spikes, ensuring the safe operation of the range hood and your kitchen.

• Replacement Indicator
  Notifies you when it's time to clean or replace the filters, maintaining optimal performance.

• 36-Inch Width
  Perfect size for most kitchen setups, providing a sleek and modern design that fits seamlessly with your kitchen décor.

Features

• • 3-Speed/550 CFM Blower
    Features 3 fan speeds—low (232 CFM), medium (330 CFM), and high (550 CFM)—allowing for customizable air circulation to efficiently remove smoke, steam, and cooking odors.

  • Touch Control
    Sleek and modern design with touch-sensitive controls, eliminating the need for physical buttons and allowing for easy operation and adjustment of settings.

  • LED Lighting
    Dual-level LED light strip beautifully illuminates your cooking area for enhanced visibility.

  • 5-Layer Aluminum Mesh Filter
    Provides superior particle capture and longer filter life, effectively trapping grease and dirt. The durable aluminum construction is dishwasher-safe for easy cleaning.

  • Heat Sensor
    Automatically detects abnormal temperature spikes, protecting your kitchen from fire hazards while optimizing energy efficiency.

  • Replacement Indicator
    Reminds you when to clean or replace the filters for optimal performance (charcoal filter not included).

  • Convertible Venting
    Can be converted to recirculating with additional charcoal filters (FT0136) and recirculation kit (ARC3601T) (not included).

  • 5-Minute Automatic Delay-Off
    A convenient feature that automatically shuts off the fan after 5 minutes, conserving energy and preventing overheating for safety.

  • Noise Level
    Operates quietly with noise levels ranging from 47 dBA (low speed) to 65 dBA (high speed), ensuring a comfortable kitchen environment.

  • Duct Cover Included
    Stainless steel duct cover complements the hood's design and extends to accommodate ceiling heights of 8 to 9 feet.
