Specifications

• General
  • Product group: Hood
  • SKU: HMCB36WS
  • Internal article number: HMCB36WS
  • EAN code: 825225935711
  • Color body: Stainless Steel
  • Material chimney: Stainless steel
  • Typology: Wall-mounted
  • Construction type: Built-in
  • Current (A): 15
  • Volts (V): 120
  • Power cord length (cm): 0.0
  • Plug type: Fixed Connection, No Plug
  • Power Cord Length: 0"
  • Height of the packed product (mm): 741
  • Watts (W): 455
  • Width of the packed product (mm): 1012
  • Depth of the packed product (mm): 447
  • Diameter of air duct top: 6
  • Product packaging dimensions (HxWxD) : 29 1/8" x 39 7/8" x 17 5/8"
  • Net weight (kg): 23.5
  • Required distance above cooktop/ranges: 30''/30''
  • Gross weight (kg): 31.1
  • Height of the chimney : 25''- 31 1/2''/25" - 37"
  • Type of automatic control devices: Control via cooker/hotplate
  • Remote control: Yes
  • Frequency (Hz): 60
  • Air exhaust: Yes
  • Design: Wall chimney hood
  • Type of manual control devices: touch control
  • Number of motors: 1
  • Number of lights: 2
  • Brand: Thermador
  • Maximum CFM: 600
  • Light Control Type: Continuous
  • Diameter of air duct (mm): 150
  • Number of speed settings: 4-stage
  • UPC code: 825225935711
  • Motor location: Integrated motor in hood chimney
  • Odour filter: No
  • Optional accessories: CHFHMCD, CHXTHMCB, RECHMCB, REMCPW
  • Type of control: Electronic
  • Installation type: Wall-mounted
  • Type of control: Illuminated Buttons;Touch Control
  • Height of product, without chimney (mm): 127
  • Overall appliance dimensions (HxWxD) : 30" - 42" x 35 15/16'' x 23 3/16"
  • Type of lamps used: Low consumption
  • Total output power of the motors: 463
  • Total luminance (lux): 150
  • No-return airflow flap: Yes
  • Gross weight : 69.000
  • Net weight : 52.000

Description

• 36-inch wall mount design for a sleek and modern kitchen aesthetic
• Powerful 4-speed/600 CFM blower for efficient smoke, odor, and grease removal
• Touch control for easy operation and a user-friendly interface
• LED lighting to illuminate your cooking area with bright, energy-efficient light
• Hybrid mesh filter captures grease and airborne contaminants for cleaner air
• Noise Control Technologyâ„¢ ensures quieter operation, providing a peaceful kitchen environment

Features

• Masterpiece® Chimney Wall hoods are sleek, slim, and distinctive in design that add a sophisticated touch to contemporary kitchens
• Wi-Fi Enabled: allows for remote monitoring and control of lights and fan speed, notification to clean the grease filter via Home Connect app, works with smart home devices and services like Amazon Alexa.
• Noise Control Technology™: utilizes insulation that reduces noise up to 35% compared to hoods without it - so you can focus on entertaining.
• Delay Shut Off & Automatic Mode: features an Automatic Mode, that adjusts the fan speed according to your cooking style, as well as Delay Shut Off, which runs the hood 10 minutes after you are done cooking to remove any lingering odors.
• LED Lighting: highlights your meal from first course to last with multi-level vivid LED Lighting.
• Sleek Electronic Touch Control Panel: convenient control that is easy-to-use and easy-to-clean.
