Specifications

• CAPACITY
  • Freezer (cu.ft.): 8.6 cu.ft.
  • Total Capacity (cu.ft.): 25.5 cu.ft.
  • Refrigerator (cu.ft.): 16.9 cu.ft.
• CONVENIENCE
  • Temperature Controls: Electronic/Digital
  • Door Alarm: Yes
  • ADA Compliant: Yes
  • Sabbath Mode: Yes
  • Auto Closing Door Hinge: Yes
• COOLING
  • Refrigerant: Low GWP, Zero ODP and More Energy Efficient Refrigerant (R600a/78g/ 2.75oz)
  • Temperature Sensors: 2
  • Compressor Type: Smart Inverter Compressor
  • Multi-Air Flow™ System: Yes
  • Evaporator: 1
• DIMENSIONS/CLEARANCES/WEIGHTS
  • Carton Dimensions (WxHxD): 38" x 72" x 31"
  • Weight (Unit/Carton): 291 lbs / 313 lbs
  • Width (Door Open 90° without Handle): 40"
  • Width (Door Fully Open without Handle): 56.75"
  • Dimensions (W case x H top of hinge x D with handles): 35 3/4" x 70 1/4" x 31 5/8"
  • Door Edge Clearance without Handle: 2.25"
  • Depth with Handles: 8.125"
  • Width (Door Open 90° with Handle): 44.875"
  • Depth (to Hinge Cover): 18.25"
  • Depth without Door: 24.75"
  • Door Edge Clearance with Handle: 4.25"
  • Height to Top of Case: 68.875"
  • Case Edge Clearance (Door Fully Open): 21"
  • Depth without Handles: 29.125"
  • Width: 35.75"
  • Depth (Draw Open Fully without Handle): 48.875"
  • Height to Top of Door Hinge: 70.25"
  • Installation Clearance: Sides 1/8", Top 1", Back 2"
  • Height (Floor to Top of Drawer): 27.875"
  • Depth (Total with Door Open): 43.625"
• ENERGY
  • ENERGY STAR® Qualified: Yes
  • Energy Consumption (kWh/Year): 699
• FREEZER
  • Drawers/Shelves: 2-Tier Organization
  • Freezer Handle: Pocket Handle
  • Freezer Light: LED Lighting (Upper)
  • Door Type: Pull Drawer
  • Drawer Divider: No
• LIMITED WARRANTY & UPC
  • Inverter Compressor (Parts Only): 6-10 Years
  • Parts & Labor: 1 Year
  • UPC: 195174081532
  • Compressor (Parts & Labor): 5 Years
  • Sealed System (Parts & Labor): 5 Years
• MATERIALS AND FINISHES
  • Insulation: Low GWP and Zero ODP Blowing Agent
  • Hidden Hinges: Yes
  • All Available Colors: PrintProof™ Stainless Steel
• REFRIGERATOR
  • Shelf Construction: Spill Protector™ Tempered Glass
  • Refrigerator Light: Yes
  • Handle Type: Pocket
  • No. of Door Bins: 4 Left, 4 Right
  • No. of Shelves: 4 Split (4 Fixed)
  • Cool Guard: Yes
  • Door-in-Door®: Yes
  • Crisper Bins: 2 Crispers
  • InstaView™ Door-in-Door®: Yes
• REFRIGERATOR THINQ® SMART FEATURES
  • ThinQ Care™: Yes
  • ThinQ® Smart Technology: Yes
  • wi-fi Enabled: Yes
  • ThinQ UP™: Yes
  • SmartDiagnosis™: Yes
• SUMMARY
  • Display Type: Smooth Touch Control / White LED
• WATER & ICE SYSTEM
  • Ice System: IcePlus™
  • In-Door Ice Maker Ice Type: Cubed / Crushed
  • Freezer Ice Maker Daily Production: 0.925 lbs
  • Dispenser Type: Ice & water
  • Ice Storage Capacity (lbs): 3.0 lbs + 4.0 lbs
  • Freezer Ice Maker Ice Type: Cube
  • Dispenser Light: Yes
  • Water Filter: LT1000P
  • Water Filtration System: 1 Stage

Description

Features

• ThinQ Offer: Get an extra 1-year limited warranty (up to $185 value) through 12/31/24. Terms apply?
• 26 cu.ft. Large Capacity lets you stock up on more of your favorites
• Knock twice on the InstaView® window to see more of your favorites without opening the door
• Never run out of ice during any event with Dual Ice Makers
• Store all your favorite foods while getting the ice you need through the SpacePlus® Ice System
• ThinQ Care helps monitor and maintain your refrigerator so it works efficiently for longer
