Specifications

• CAPACITY
  • Freezer (cu.ft.): 7.9 cu.ft.
  • Refrigerator (cu.ft.): 15.8 cu.ft.
  • Total Capacity (cu.ft.): 23.7 cu.ft.
• CONVENIENCE
  • Temperature Controls: Electronic/Digital
  • Auto Closing Door Hinge: Yes
  • Door Alarm: Yes
  • ADA Compliant: Yes
  • Sabbath Mode: Yes
• COOLING
  • Evaporator: 1
  • Compressor Type: Smart Inverter Compressor
  • Temperature Sensors: 2
  • Multi-Air Flow™ System: Yes
  • Fresh Air Filter: Yes
  • Refrigerant: Low GWP, Zero ODP and More Energy Efficient Refrigerant (R600a / 78g / 2.7502)
• DIMENSIONS/CLEARANCES/WEIGHTS
  • Carton Dimensions (WxHxD): 38" x 72" x 29"
  • Weight (Unit/Carton): 219 lbs /313 lbs
  • Installation Clearance: Sides 1/8", Top 1", Back 2"
  • Width (Door Open 90° without Handle): 35.12"
  • Depth (Total with Door Open): 43.75"
  • Width (Door Fully Open without Handle): 45.5"
  • Depth with Handles: 29.87"
  • Height to Top of Case: 68.87"
  • Case Edge Clearance (Door Fully Open): 13.87"
  • Width: 35.75"
  • Depth (to Hinge Cover): 18.25"
  • Depth without Handles: 27.5"
  • Depth (Draw Open Fully without Handle): 73.87"
  • Dimensions (W case x H top of hinge x D with handles): 35 3/4" x 70 1/4" x 29 7/8"
  • Depth without Door: 23.75"
  • Door Edge Clearance without Handle: 2.12"
  • Height to Top of Door Hinge: 70.25"
  • Width (Door Open 90° with Handle): 40"
• ENERGY
  • Energy Consumption (kWh/Year): 699
  • ENERGY STAR® Qualified: Yes
• FREEZER
  • Drawers/Shelves: 2-Tier Organization
  • Freezer Handle: Pocket Handle
  • Freezer Light: LED Lighting
  • Drawer Divider: No
  • Door Type: Hybrid
• LIMITED WARRANTY & UPC
  • Sealed System (Parts & Labor): 5 Years
  • UPC: 195174092453
  • Inverter Compressor (Parts Only): 6 - 10 Years
  • Compressor (Parts & Labor): 5 Years
  • Parts & Labor: 1 Year
• MATERIALS AND FINISHES
  • Insulation: Low GWP and Zero ODP Blowing Agent
  • Hidden Hinges: Yes
  • All Available Colors: PrintProof™ Stainless Steel
• REFRIGERATOR
  • No. of Door Bins: 2 Left, 3 Right
  • No. of Shelves: 4 Split (4 Fixed)
  • Crisper Bins: 2
  • Cool Guard: Yes
  • Shelf Construction: Spill protector Tempered glass
  • Handle Type: Bar
• REFRIGERATOR THINQ® SMART FEATURES
  • SmartDiagnosis™: Yes
  • ThinQ® Smart Technology: Yes
  • wi-fi Enabled: Yes
  • ThinQ Care™: Yes
• SUMMARY
  • Display Type: Smooth Touch Control / White LED
• WATER & ICE SYSTEM
  • Water Filtration System: 1 Stage
  • Dispenser Type: Ice & water
  • Ice Storage Capacity (lbs): 3.0 lbs
  • Ice System: IcePlus™
  • Water Filter: LT1000P
  • Freezer Ice Maker Ice Type: Craft Ice
  • In-Door Ice Maker Ice Type: Cubed / Crushed
  • Dispenser Light: No
  • Freezer Ice Maker Daily Production: 0.7 lbs

Description

Features

• Zero Clearance™ hinges and thin door design lets you install the refrigerator in tight spaces and still fully open both doors.¹
• Sleek style you love and storage space you need in our largest-capacity Zero Clearance™ refrigerator.
• Dual ice makers automatically create standard ice cubes, crushed ice and slow-melting round Craft Ice™
• Doors are 45% thinner² for a seamless look that takes up less space.
• MAX out your chill and have extra ice on hand for those hot summer days or when entertaining large parties.
• Automatically increases ice production with just a touch of the control panel or through the ThinQ® app.
• Restyled bar handles and freezer pocket handle combine for easy opening and premium style.
