Specifications

• -
  • Microwave Interior Light: LED
• Certifications
  • CEC Listed: Yes
  • CUL: No
  • Prop65: Standard
  • UL: Yes
  • ADA Compliant: No
• Controls
  • Control Type: Electronic Touch
  • Convenience Cooking Controls: Yes
  • Display Color: Full Color
  • Number Of Keypads: 32
  • Number Of Power Levels: 10
  • Scrolling Electronic Display: Yes
  • Microwave Selections: Add 30 Seconds; Air Fry; Auto Cook; Beverage; Convect; Cook Power; Cook Time; Cook/Start; Crisp; Defrost; Dinner Plate; End of Cycle Signal; Fresh Vegetable; Keep Warm; Languages - English/French; Off/Cancel; Pizza; Popcorn; Potato; Reheat; Soften/Melt; So
  • Control Location: Bottom
  • Number Of Sensor Control Keypads: 4
  • One Touch Cooking: Yes
  • Electronic Display Type: LCD
• Details
  • Door Opening Direction: Left
  • Cavity Finish: Stainless
  • Clock: Yes
  • Microwave Type: Over-the-Range
  • Turntable: N/A
  • Work Surface Light: LED
  • Number Of Vent Speeds: 3
  • Grill Power: 1,700
  • Grill: Yes
• Dimensions
  • Cutout Depth Max: 13
  • Cutout Depth Min: 12.75
  • Cutout Height Max: 18
  • Display Screen Diagonal Length: 2.4
  • Interior Height: 9.125
  • Carton Height: 21.1 inches
  • Cutout Width Max: 30
  • Depth Closed Excluding Handles: 12.75
  • Carton Width: 32.9 inches
  • Gross Weight: 83.9 pounds
  • Net Weight: 75 pounds
  • Carton Depth: 16.7 inches
  • Depth Closed Including Handles: 12.75
  • Depth Excluding Doors: 12.75
  • Depth With Door Open 90 Degree: 41.5
  • Interior Depth: 11
  • Interior Width: 18.125
• Electrical
  • Power Cord Included: Yes
• Exterior Details
  • Cabinet Color: Black
  • Handle Color: N/A
• Microwave Details
  • Number Of Microwave Racks: 1
  • Turntable Diameter Size: 0
  • Door Release: Touch to Open
  • Sensor Cooking: Yes
• Oven Details
  • Cooking Power: 950
  • Convection: Yes
  • Convection Power: 1,400
• Smart Compatibility
  • Connectivity: Amazon Alexa; Google Assistant
  • Smart Appliance: Yes
  • Works With: App; Remote Access; Voice Controlled; WiFi
• Ventilation Details
  • Blower Type: Centrifugal
  • Duct Type: Rectangular
  • Vent Fan Location: Back
  • Venting: Exterior or Recirculating
  • CFM Motor Class: 400
  • Duct Direction: Vertical or Horizontal
  • Night Light: Yes
  • Duct Outlet Size: 3.25 W x 10 H
  • Fan Speed Indicator: Yes
  • Filters: Charcoal Recirculating Filter; Dishwasher Safe Grease Filter
  • Ventilation Type: Updraft

Description

1.1 Cu. Ft. Capacity: Provides ample space for a variety of cooking tasks.

3-Speed 400 CFM Blower: Ensures effective ventilation with three speed settings for optimal airflow.

1800 Watts: Delivers powerful cooking performance for quick and efficient meal preparation.

10 Power Levels: Offers versatility in cooking with multiple power settings for different food types.

One Touch Cooking: Simplifies cooking with pre-programmed settings for fast and convenient use.

WiFi Capable: Allows remote control and monitoring through your smart device.

Centrifugal Blower: Ensures high-performance ventilation for improved cooking and air circulation.

Infrared Sensor Modes: Adjusts cooking time and temperature for optimal results using advanced sensor technology.

Flush Built-In Design: Provides a sleek, modern look that seamlessly integrates into your kitchen.

Integrated Meat Thermometer: Monitors internal temperatures for precise cooking.

ADA Compliant: Meets the standards for accessibility, making it user-friendly for all.

Features

• Air Fry Mode: Replaces a countertop air fryer for all of the crisping with none of the clutter. Triple heating elements and a fan circulate hot air around the included air fry basket to crisp and brown food with less oil.*
• Multifunction Oven Modes: Replace a convection or toaster oven, freeing up counter space by elevating your baking, roasting, broiling and toasting. Triple heating elements and a fan direct heat where it's needed to cook at temperatures up to 450°F.
• Flush Built-In Design: Provides a seamless built-in look within a standard 12 ¾” deep cutout. When closed, the microwave door fits evenly with surrounding cabinet fronts, so your kitchen stands out, not the appliance.
• Infrared Sensor Modes: Provide intuitive assistance to smoothly melt chocolate, defrost frozen chicken without cooking the edges and help prevent splatters. Infrared sensors monitor cooking progress and automatically adjust cook time and temperature as needed.
• Integrated Meat Thermometer: Takes the guesswork out of cooking meat, fish, poultry, casseroles and more just the way you like. It continuously monitors cooking progress and automatically turns the oven off when your desired temperature is reached.
• Dehydrate Mode: Replaces a countertop dehydrator, helping remove moisture from food to concentrate flavor. A heating element and fan circulate consistent low heat around the included basket.
• Bread Proof Mode: Takes proofing dough to new heights. A heating element and fan circulate consistent low heat to help activate the yeast and promote rise.
• Turntable-Free Design: Maximizes cooking space for large dishes or multiple items at the same time. A hidden motor circulates microwave heating throughout the entire oven, eliminating the need for a traditional turntable.
• Smart Appliance: Gives you control over every stage of cooking. Remotely preheat, monitor and control the microwave oven with the KitchenAid™ App or with simple voice commands through your Google Assistant or an Alexa-enabled device, leaving your hands free to create.*
• Backlit Touch Controls: Illuminate when in use and fade unobtrusively into the sleek black glass of the oven door when the oven is off. A full-color LCD display makes it easy to see and select cooking modes, temperatures and cook times.
• Three-Speed 400 CFM Motor Class* Ventilation System *Performance varies based on installation. Resources available at AHAM.org: Features low, medium and high settings to help clear the air of smoke and steam, keeping up with all kinds of cooking adventures, from gentle simmering to high-heat searing.
• Keep Warm Mode: Maintains low heat for up to 60 minutes to keep cooked foods at serving temperature, allowing you to focus on other steps in your creative process or finish one dish while another rests.
• Steam Clean Mode: Uses the power of steam to help loosen cooked-on food without the need for harsh cleaners. After running this cycle, just wipe down the inside of the microwave with a damp cloth.
• PrintShield™ Finish: Resists smudges and fingerprints. The specialized coating for stainless steel is easy to clean with just water and a soft cloth, so you can spend more time cooking and less time cleaning up the kitchen.
• Two LED Lights with Night Light Setting: Provide two levels of brightness, allowing you to illuminate the entire cooking surface below with natural-looking light or subtly accent the kitchen with a soft, inviting glow.
• Stainless Steel Covered Grease Filters: Conceal aluminum mesh filters behind a sleek stainless steel panel for a fully finished look. Filters use multiple layers of screening to help capture the grease and odors of high-heat cooking and remove for easy cleaning with soap and water.
• 1.1 Cu. Ft. Capacity: Comfortably fits a variety of dishes with enough height for a mixing bowl and width for a 9" x 13" casserole dish or multiple items at the same time.
• 950-Watt Microwave Cooking Power: Cooks quickly to boil water, defrost ingredients or warm completed dishes to enjoy again.
• What's in the box: Model KMMF530P includes a Dishwasher-Safe Air Fry Basket, a Toasting Pan, an Oven Rack, and an Integrated Meat Thermometer
• Bake Mode: Uses dual heating elements to bake at temperatures up to 450°F, eliminating the need for a countertop convection or toaster oven. The included oven rack fits a 9" x 13" pan.
• Air Bake Mode: Uses triple heating elements and a fan for convection baking at temperatures up to 450°F, eliminating the need for a countertop convection oven. The included oven rack fits a 9" x 13" pan.
• Roast Mode: Uses dual heating elements and a fan to roast at temperatures up to 450°F, eliminating the need for a countertop convection oven. The included oven rack fits a 9" x 13" pan.
• Broil Mode: Uses a grill element in the top of the oven to broil at temperatures up to 400°F, eliminating the need for a countertop toaster oven. The included oven rack fits a 9" x 13" pan.
• Toast Mode: With included toasting pan combines direct heat from a toast element on the bottom of the oven and indirect heat from a grill element in the top to achieve your preferred level of browning, eliminating the need for a countertop toaster oven.
• Infrared Sensor Soften/Melt: Provides intuitive assistance to gently soften butter and cream cheese and smoothly melt chocolate and butter. Infrared sensors monitor progress and automatically end the cycle when food reaches the ideal temperature.
• Infrared Sensor Defrost: Provides intuitive assistance to defrost frozen chicken without cooking the edges. Infrared sensors continually monitor heat levels and automatically end the cycle before cooking starts.
• Infrared Splatter Prevention: Provides intuitive assistance to help prevent splatters inside the microwave. If infrared sensors detect that liquids are heating too quickly, they will automatically turn down the power level to help keep them from bubbling over.
