Specifications

• ACCESSORIES
  • Optional Kits : 15" Bump Out Kit - JX15BUMPBB
  • Recirculating Charcoal Filter Kit : JX81C or WB02X33061 (Included)
• APPEARANCE
  • Handle Color : Black
  • Oven Door Features : Oven Window
  • Door Color : Black
  • Case Color : Black
  • Door Swing : Hinges on Left
  • Color Appearance : Black
• CAPACITY
  • Vent CFM : 300
  • Total Capacity (cubic feet) : 1.6 cu ft
• ECONOMICAL / QUIET
  • Non-Vented : Recirculating (Factory Set - Filter Included)
  • Venting Type : Convertible to External Venting
• FEATURES
  • Display Screen Size (Diagonal Length) : 2.01
  • Turntable On / Off : Yes
  • Microwave Watts (IEC-705) : 1000 W
  • Power Levels : 10
  • Display On/Off : Yes
  • Exhaust Fan : 2-Speed, 300-CFM
  • Turntable : Glass
  • Microwave Convenience Cooking Controls : Beverage, Defrost: Weight/Time, Popcorn, Potato, Reheat
  • Timer (On/Off) : Yes
  • Interior Oven Light : Incandescent
  • Cooking Modes : Microwave
  • Turntable Size : 13.5 in
  • Control Features : Add 30 Seconds, Cancel/Off, Cook Time, Power Level, Set Clock, Start/Pause, Surface Light, Timer On/Off, Turntable On/Off, Vent Fan
  • Control Type : Electronic Touch
  • Express Cook : 1-6 Minutes
  • Display Type : LED
  • Style : Over-The-Range
  • Cooking Technology : Microwave
  • Cooktop Lighting : Bright/Night/Off
• POWER / RATINGS
  • Electrical Input - 120V Amperage : 15
  • Input Volts/Hertz : 120/60
  • Electrical Input - 120V Watts : 1580
• WARRANTY
  • Labor Warranty : Limited 1-year entire appliance
  • Parts Warranty : Limited 1-year entire appliance
• WEIGHTS & DIMENSIONS
  • Approximate Shipping Weight : 63 lb
  • Overall Depth : 15.5625 in
  • Cabinet Width : 30 in
  • Net Weight : 63 lb
  • Overall Width : 29.875 in
  • Cavity (W x H x D) : 20-1/4 x 9-1/4 x 14-13/32
  • Overall Height : 16.125 in

Description

Capacity: 1.6 cu. ft., offering ample space for large dishes and family meals.

Venting System: Equipped with a 200-CFM venting system to effectively remove smoke, steam, and odors from the kitchen.

Fan Speeds: 2-speed ventilation control for customizable airflow depending on cooking needs.

Power Output: 1,000 watts, providing strong, consistent microwave cooking performance.

Defrost Options: Weight/Time Defrost settings, ensuring even thawing of frozen foods based on weight or time.

Turntable: Features a rotating turntable for even cooking and reheating.

Design: Stylish black finish, designed to complement modern kitchen décor.

Ease of Use: Simple controls and intuitive interface for easy operation.

Features

• Capacity: 1.6 cu. ft., providing spacious interior for larger food items and more versatile cooking.
• Power: 1000 watts (IEC-705 test procedure), delivering high performance for efficient cooking and reheating.
• Convenience Cooking Controls: Offers preset cooking functions for easy and quick operation.
• User-Friendly Operation: Quick and easy to use, allowing fast setup and operation for everyday meals.
• Weight and Time Defrost:
  • Simply enter the weight of the food, and the microwave automatically adjusts the optimal defrosting time and power level.
  • Alternatively, set a desired time for defrosting as needed.
• Turntable: Rotates food throughout the cooking cycle for even heating and better results.
• Two-Speed, 300-CFM Venting System:
  • Effectively removes smoke, steam, and odors from the cooktop.
  • Ensures a cleaner, fresher kitchen environment.
• Add 30 Seconds:
  • One-touch feature to quickly add 30 seconds of microwave cooking time, allowing for convenient, quick adjustments during cooking.
