Specifications

• ACCESSORIES
  • Optional Backguard : Included
  • LP Conversion Kit : Included
• APPEARANCE
  • Oven Door Features : Oven Window
  • Handle Color : Stainless Steel
  • Control Knobs : Stainless Steel
  • Handle : Designer Style
  • Door Swing : Pull-Down
  • Color Appearance : Stainless Steel/Black
• CAPACITY
  • Total Capacity (cubic feet) : 2.9 cu ft
• FEATURES
  • Burner - Right Rear : 5,000 BTU
  • Oven Interior : 1 Incandescent Light, Blue Gray
  • Product Type : Free-Standing Single Oven
  • Cooktop Type : Standard Grates
  • Cooktop Burner Grate Material : Cast-Iron
  • Fuel Type : Natural Gas (factory set)
  • Control Location : Front
  • Oven Rack Features : 2 Flat Nickel Racks
  • Burner - Left Rear : 9,500 BTU
  • Oven Cleaning Type : Standard Clean
  • Burner - Left Front : 9,500 BTU
  • Leveling System : 4 Leveling Legs
  • Cooking Technology : Traditional
  • Valves (Degree of Turn) : 270
  • Cooktop Surface : Porcelain-Enamel
  • Ignition System : Electronic
  • Drawer Type : Lower Storage Drawer
  • Sabbath Mode : Yes
  • Configuration : Range with In Oven Broil
  • OU Certified : No
  • Oven Cooking Modes : Bake, Broil
  • Cooktop Burner Type : Sealed
  • Burner - Right Front : 15,000 BTU
  • Oven Rack Positions (Single or Upper/Lower) : 4
• FILTER
  • App Filter - Cabinet Width : Cooking 24 in.
  • App Filter - Control Type : Rotary knobs
  • App Filter - Product Type : Ranges Free-Standing Single Oven
  • App Filter - Fuel Type : Gas
  • App Filter - Cooking Technology : Traditional
  • App Filter - Cooktop Type : Standard Grates
  • App Filter - Convection : No
  • App Filter - Cleaning Type : Manual
• POWER / RATINGS
  • Volts/Hertz/Amps : 120V ; 60Hz ; 15A
  • Top Burner BTU Rating - LP (000's BTU's) : (1) 15.0; (2) 9.5; (1) 5.0
  • Top Burner BTU Rating - Nat. Gas (000's BTU's) : (1) 15.0; (2) 9.5; (1) 5.0
  • Bake/Broiler BTU Rating - Nat. Gas (000's BTU's) : 13.0
  • Bake/Broiler BTU Rating - LP (000's BTU's) : 13.0
• WARRANTY
  • Parts Warranty : Limited 1-year entire appliance
  • Warranty Notes : See written warranty for full details
  • Labor Warranty : Limited 1-year entire appliance
• WEIGHTS & DIMENSIONS
  • Net Weight : 107 lb
  • Cabinet Width : 24 in
  • Approximate Shipping Weight : 120 lb
  • Overall Width : 24 in
  • Oven Interior Dimensions (W x H x D) (in.) : 19 x 15-3/8 x 17-1/8
  • Depth Without Handle : 25.875 in
  • Height to Cooking Surface (in.) : 36 1/4 +/- 1/4
  • Overall Height : 41 in
  • Overall Depth : 28.125 in
  • Depth with Door Open : 45.625 in

Description

24'' Steam Clean Free-Standing/Slide-in Gas Range, combining compact design with powerful cooking capabilities.

Features a steam cleaning function for easy maintenance and a cleaner oven.

Offers flexible installation, allowing it to be used as either a freestanding or slide-in unit.

Versatile design, making it a great fit for modern kitchens with space constraints.

Ideal for those looking for a space-saving and efficient cooking solution.

Features

• Front controls : Easily-accessible controls make it simple to control the stovetop and oven
• Edge-to-edge cooktop with heavy-cast grates : Enjoy the versatility of a large cooking surface on the stove that can handle lots of cookware combinations
• In-oven broil : Healthy meals are hassle-free with in-oven broiling
• Sealed cooktop burners : Contains spills and make cleaning quick and easy
• Steam clean : The power of steam eliminates oven scrubbing with just a 30-minute cycle
• Modular backguard : Versatile design gives you the option of a traditional look, or flip down to create a slide-in appearance
