Specifications

• APPEARANCE
  • Door Style : Right Swing
  • Control Knobs : White
  • Color Appearance : White on White
• CAPACITY
  • Dryer Capacity : 5.9 cu ft
  • Wash Basket Type : Stainless Steel
  • Washer Capacity : 3.9 cu ft
• ECONOMICAL / QUIET
  • Quiet Package : Quiet-By-Design
• FEATURES
  • Control Type : Rotary-Electronic
  • Water Levels : Adaptive Fill
  • Washer Options/Settings : Deep Rinse (select when using fabric softener)
  • Automatic Dry Control : Yes
  • Washer Control Features : LED Indicators
  • Case Material : Steel
  • Additional Dryer Features : Up-Front Lint Filter
  • Fuel Type : Electric
  • Washer Cycles : Bulky Items, Casuals, Colors/Normal (Heavy, Normal, Light), Delicates, Drain + Spin, Speed Wash, Whites (Heavy, Normal, Light)
  • Maximum Spin Speed : 800 RPM
  • Number of Cycles : 12 Washer/4 Dryer
  • WiFi Connect : Optional (Requires part no. PBX23W00Y0)
  • Wash/Rinse Temperatures : 6
  • Timed Dry : 10/20/30/40/60/80 Minutes, Damp Dry, De-Wrinkle, Quick Fluff (no heat)
  • Drum Type : Alcosta Aluminized Drum
  • Cottons Cycle : Less Dry, More Dry, Optimum Dry
  • Product Type : Stacked Washer & Dryer Combo
  • Heat Selections : 4
  • Additional Washer Features : Inlet Fill Hoses Included, Lid Latch
  • Additional Cycles : Dewrinkle, Quick Fluff
  • Exhaust Options : 3-Way (Rear; Left; Right)
  • Wash Mechanism : Infusor
  • Easy Care Cycle : Casuals, Less Dry, More Dry
  • Dispenser : Bleach
  • Wash/Spin Speed Combinations : 1
  • Delicates Cycle : Less Dry, More Dry
• FILTER
  • App Filter - Agitator : Yes
  • App Filter - Capacity : Washer Medium (3.8-4.0 cu. ft.)
  • App Filter - Product Type : Stacked Washer & Dryer Combo
• POWER / RATINGS
  • Volts/Hertz : 120/240V or 120/208V; 60Hz
  • Circuit Breaker or Time Delay Fuse : 30 Amp
  • Energy Consumption (kWh/year) : 140
• WARRANTY
  • Parts Warranty : Limited 1-year entire appliance
  • Warranty Notes : See written warranty for full details
  • Labor Warranty : Limited 1-year entire appliance
• WEIGHTS & DIMENSIONS
  • Overall Width : 26.75 in
  • Dryer Door Opening Width (in.) : 16.13
  • Approximate Shipping Weight : 279 lb
  • Door Width : 22 in
  • Overall Depth : 30.875 in
  • Overall Height : 75.875 in
  • Dryer Door Opening Height (in.) : 18.63
  • Door Open Height : 54 in
  • Cabinet Width : 27 in
  • Depth with Door Open 90° : 47.5 in
  • Net Weight : 249 lb

Description

PreciseFill: Automatically adjusts the water level to match the load size for more efficient washing.

Wi-Fi Capable: Allows remote control and monitoring of laundry cycles through a smartphone app for added convenience.

Deep Rinse: Ensures detergent is thoroughly rinsed from clothes, providing a more effective and gentle clean.

Rotary Controls: Simple, easy-to-use rotary controls for selecting the desired wash cycle.

Wash Cycles: Offers 11 wash cycles to accommodate various fabrics and laundry needs.

Wash/Rinse Temperatures: Provides 6 wash and rinse temperature settings for customized care of different fabrics.

Spin Speed: 800 RPM spin speed for efficient water extraction, reducing drying time.

Features

• PreciseFill Technology : Take the guesswork out of choosing the right water level with PreciseFill, which auto-senses the size of the load to add just the right amount of water for maximum cleaning performance
• Deep Rinse : Ensure clothes are rinsed free of detergent, fabric softener and stubborn soils
• 11 Wash Cycles : Choose from 11 wash cycles that accommodate every load type
• 6 Water Temperatures : Pick the water temperature you prefer and wash your way
• ENERGY STAR® qualified : Meets or exceeds federal guidelines for energy efficiency for year-round energy and money savings
• WiFi Capable : Monitor performance and check cycle status of your washer and dryer using your mobile device.* *Required ConnectPlus accessory part number PBX10W00Y0 sold separately
• Efficient Infusor : Optimize energy efficiency without sacrificing wash performance
• Cycle Status Lights : Easily track your wash and dry cycles with lights that indicate the status with just a glance
• End of Cycle Chime : Conveniently know when a cycle is complete with an audible alert
