Specifications

• APPEARANCE
  • Adjustable Rollers : 2
  • Dispenser Color : Color-Matched
  • Door Stops : Yes
  • Textured Steel Case : Case Only - Dark Gray
  • Handle Color : Black Stainless
  • Case Color : Black
  • Exterior Design : Contoured Doors
  • Door Swing : Hinges on Left & Right
  • Color Appearance : Fingerprint Resistant Black Slate
  • Handle Design : Designer Style
  • Hidden Door Hinge(s) : Yes
• CAPACITY
  • Fresh Food Capacity : 18.5 cu ft
  • Total Capacity (cubic feet) : 27.7 cu ft
  • Freezer Capacity : 9.17 cu ft
• FEATURES
  • Temperature Management Features : Turbo Cool setting
  • Dispenser Features : Door Alarm, LED Dispenser Light, Water Filter Indicator Light
  • Control Type : External Electronic Digital Temperature Display
  • Icemaker : Optional 2nd Icemaker (IM5D) in Freezer, Space Saving Ice
  • Number of Doors : 3
  • Filter Location : Left wall
  • Door Alarm : Yes
  • Temperature Management System : TwinChill™ Evaporators
  • WiFi Connect : Optional (Requires part no. PBX23W00Y1)
  • Performance Features : Easily Removable Door Gaskets
  • Fresh Food Cabinet Shelves : 4 Adjustable, 1 Full-Width, 4 Spill Proof, 5 Total - Glass
  • Fresh Food Door Bins : 2 Adjustable, 3 with Gallon Storage, 6 Total
  • Freezer Features : Interior Lighting - LED (2), Turbo Freeze
  • Exterior Style : Free-Standing, Standard Depth
  • Temperature Display : External Digital
  • Fresh Food Features : Showcase LED Lighting 5
  • Configuration : French Door
  • Refrigerant Type : R600a
  • Dispenser : Cubes, Crushed Ice and Water, Large Color-Matched
  • Fresh Food Cabinet Drawers : 1 Full-Width with LED Lighting, 2 Adjustable Humidity, 3 Total
  • OU Certified : OU/CRC Enhanced Shabbos Mode, when used with Shabbos Keeper, sold separately
  • Sabbath Mode : Optional
  • Freezer Storage Baskets : 2 Full-Width
  • Defrost Type : Frost Guard
  • Leveling System : 2 Front Leveling Legs
  • Water Filtration : Advanced Filtration System, Find your filter here: https://www.geapplianceparts.com/store/parts/filter-finder, Removes Pharmaceuticals
  • Product Type : Bottom Freezer Refrigerator, French-Door Refrigerator
• FILTER
  • App Filter - Autofill : No
  • App Filter - Icemaker : Yes
  • App Filter - Product Type : Refer French Door
  • App Filter - Dispenser : Yes
  • App Filter - Capacity : Refer Extra Large (25 cu. ft. and above)
  • App Filter - Hot Water : No
• POWER / RATINGS
  • Energy Consumption (kWh/year) : 725
• WARRANTY
  • Warranty Notes : See written warranty for full details
  • Parts Warranty : Limited 1-year entire appliance
  • Labor Warranty : Limited 1-year entire appliance
• WEIGHTS & DIMENSIONS
  • Net Weight : 370 lb
  • Overall Width : 35.75 in
  • Back Air Clearances : 2 in
  • Overall Depth : 36.25 in
  • Height to Top of Hinge : 70.5 in
  • Approximate Shipping Weight : 390 lb
  • Width w/Door Open 90 Degrees Incl. Handle : 44.625 in
  • Case Depth Without Door : 29.375 in
  • Side Air Clearances : 0.125 in
  • Depth Without Handle : 34.75 in
  • Height to Top of Case : 69 in
  • Top Air Clearances : 1 in
  • Overall Height : 70.5 in
  • Depth with Door Open 90° : 48.375 in

Description

27.7 Cu. Ft. capacity provides ample storage for both fresh and frozen foods

French-door design offers easy access to the refrigerator section and freezer compartments

Bottom freezer with organized storage for easy access to frozen items

Adjustable shelves and drawers allow for customizable storage space

Energy-efficient cooling technology helps maintain freshness while reducing energy consumption

Sleek, modern design that complements any kitchen décor

Ideal for large households or those needing spacious and efficient food storage

Features

• Space-saving icemaker : Located on the door with integrated bins to create more usable storage space
• Showcase LED lighting : Positioned throughout the interior and under fresh food doors to spotlight foods inside the refrigerator and in the freezer
• Second icemaker option : Always have extra ice on hand with an optional second icemaker in the freezer (IM5D kit sold separately)
• Advanced Water Filtration : Reduces trace pharmaceuticals from water and ice* (* Removes 98% of ibuprofen, atenolol, fluoxetine, progesterone and trimethoprim. These pharmaceuticals are not necessarily in all users’ water)
• TwinChill™ evaporators : Separate climates in the fresh food and freezer sections help keep foods fresh
• Two humidity-controlled drawers and full-width drawer with LED light : Create the right environment for keeping fruits and vegetables fresh, while easily storing wider items like a party platter or a sheet cake
• Turbo Cool and Turbo Freeze settings : An extra boost of cold air restores interior to set temperature for optimum food freshness
• Tall dispenser : Makes and stores ice in the door, saving space
• Door alarm : Enjoy peace of mind knowing the refrigerator door is never left open
• Two-level freezer storage baskets : Baskets allow easy access to frozen foods
• Gallon door storage : Deep bins handle large containers in the door and free up valuable shelf space
• External controls with actual temperature display, child lock and door alarm : Eliminates the guesswork in setting refrigerator temperatures; conveniently displayed on the dispenser
• Cubed/crushed ice : An easy-to-use dispenser lets you choose either cubed or crushed ice
• Spill-proof shelves : A variety of shelf configurations provide additional options for food storage
• Enhanced Shabbos Mode : The Shabbos Keeper connects to your refrigerator to automatically enable Shabbos compatible modes each week and before every holiday (Shabbos Keeper sold separately, visit www.zmantechnologies.com for details)
