Specifications

• ACCESSORIES
  • Optional 12' Drain Hose : Optional hose kit (WD24X10065)
• APPEARANCE
  • Installation : Built-Up Floor Capable, Flush Cabinet Installation, Side or Top Mount Install Brackets Included
  • Door Appearance : Full-length door
  • Handle : Rounded Handle
  • Color Appearance : Fingerprint Resistant Stainless
  • Control Panel Color : Storm Gray
  • Handle Color : Stainless Steel
  • Door Style : Long Door with Top Controls
• ECONOMICAL / QUIET
  • Door Insulation : Insulation, Mastic
  • Quiet Package : 47 dBA
  • Outer Wrap : Bitumen
  • Motor Type : Variable Speed
  • Quiet Features : Quiet Water Valve, Sealed Toe Kick, Tub Collar Trim
• FEATURES
  • Wash System : 3-Level, 600 Series
  • Tub Type : Tall Tub
  • Leveling System : 4 Leveling Legs
  • Additional Protection : Active Flood Protect
  • Number of Place Settings : 16
  • Dishwasher Options : Bottle Jets, Child Lock, Delay Start 1-12 Hr., Dry Boost™ (High), Dry Boost™ (Normal), Sabbath Mode, Start/Cancel, Steam + Sani (Certified to NSF Standard 184), Wash TempBoost, Wash Zone Lower Only, Wash Zone Upper Only
  • Sensor : Clean Sensor
  • Latch : Pull with Handle
  • Number of Options : 11
  • Rack Features : 1 Piece Silverware Basket with 3 Cell Covers, Adjustable Upper Rack, Ball-Tipped Tines
  • Racking Material : Nylon
  • Style : Built-In Top Control
  • Dispenser : Rinse Aid with Indicator and Adjustment
  • WiFi Connect : Optional (Requires part no. PBX23W00Y0)
  • Control Type : 8 Touchpads, Cap Touch Controls, Top Controls
  • Racking System : Full 3rd rack
  • Wash Arms : 3 Wash Levels, Bottle Jets, Lower, Middle, Upper
  • Wash System Features : Automatic HotStart, Automatic Temperature Control, Bottle Jets (4), Drain Pump, Piranha™ Hard Food Disposer with removable filter, Variable Speed Dual Pumps and Motors
  • Dishwasher Cycles : 1 Hour Wash, AutoSense, Heavy Wash, Normal Wash, Rinse
  • Exterior Style : Traditional
  • Number of Cycles : 5
  • Water Filtration System : 100% Filtration with Piranha Hard Food Disposer and Removable Filter
  • OU Certified : No
  • Lower Rack : Ball-Tip Tines
  • Cutlery Tray : One piece removable 3rd rack
  • Top Rack/3rd Rack : Yes
  • Rack Color : Silver
  • Upper Rack : Ball-Tip Tines, Height Adjustable, Removable
  • Dishwasher Control Features : 1 "Clean" Light, 1 "Sanitized" Light Cycle Progress Indicators, 3 Digit Display Cycle Countdown with Bi-Color LED Status Light on door, Audible End-of-Cycle Signal, Control Lock with 1 Light, Last Cycle Memory
  • Dishwasher Drying Features : Dry Boost™, Normal, High, Off
  • Showroom Power Mode : Yes
  • Sabbath Mode : Yes
  • Tub and Door Liner : Stainless Steel
• POWER / RATINGS
  • Power Connection : Optional cord kit (GPFCORD - WX09X70910, WX09X70911)
  • Energy Consumption (kWh/year) : 240
  • Calrod Heater Watts : 800/500
  • Volts/Hertz/Amps : 120V; 60Hz; 6.6A
• WARRANTY
  • Warranty Notes : See written warranty for full details
  • Labor Warranty : Limited 1-year entire appliance
  • Parts Warranty : Limited 1-year entire appliance
• WEIGHTS & DIMENSIONS
  • Height w/ Legs Retracted - Minimum Height : 33.375 in
  • Cutout Height (in) : 33 1/2 in
  • Cutout Width (in) : 24 in
  • Cabinet Width : 24 in
  • Net Weight : 99 lb
  • Approximate Shipping Weight : 112 lb
  • Overall Height : 34 in
  • Cutout Depth (in) : 24 in
  • Height w/Legs Extended - Maximum Height : 34.625 in
  • Depth with Door Open : 27.5 in
  • Overall Depth : 24 in
  • Overall Width : 23.75 in
  • Overall Depth with Handle : 25.6 in

Description

Fingerprint Resistant Top Control Panel: Features a sleek, top-mounted control panel that resists fingerprints, maintaining a clean, polished look while providing easy access to settings and wash cycles.

Stainless Steel Interior: Built with a durable stainless steel interior that resists stains and odors, ensuring long-lasting performance and an elegant, modern appearance.

Sanitize Cycle: Effectively eliminates harmful bacteria and germs, ensuring your dishes are not only clean but also sanitized for added hygiene and peace of mind.

Multiple Wash Cycles: Offers a variety of wash cycles to meet different cleaning needs, from heavy-duty washes to delicate cycles for fragile items like glassware.

Quiet Operation: Designed for minimal noise, ensuring you can run the dishwasher without disrupting your household or daily activities.

Energy Efficient: Helps reduce water and energy consumption, lowering utility bills while still providing powerful and effective cleaning performance.

User-Friendly Controls: Simple and intuitive top controls make it easy to select the right wash cycle and customize settings for a hassle-free dishwashing experience.

Sleek, Modern Design: The fingerprint-resistant stainless steel finish and top-control design enhance the aesthetic of your kitchen while providing advanced functionality.

Features

• Dry Boost™ Technology : Dry Boost™ Technology outperforms standard heated-dry dishwashers by getting hard-to-dry items like plastics up to 3 times drier when compared to heated dry.
• Third Rack : The versatile third rack was redesigned to load more than just silverware with additional space for unique items.
• 4 Bottle Wash Jets : Ensure a deep clean for tall items, narrow glasses, jars and more thanks to this dishwasher with bottle jets. 4 powerful jets direct water and detergent inside to effectively wash hard-to-reach areas.
• Adjustable Upper Rack : Lift or lower the adjustable top rack of the dishwasher to accommodate bottles, large platters or any items as tall as 10.5" thanks to flexible loading capabilities.
• Steam + Sani : Save time with a high-temperature cycle that steams and sanitizes
• High Wash Performance : Get a complete wash with no pre-rinse thanks to a variety of wash cycles that provide a powerful clean. No matter how many dishes you load or how dirty they are, rest assured you'll get spotless results every time.
• Active Flood Protect : This dishwasher features Active Flood Protect, which prevents potential overflows for greater peace of mind. It works by using a water leak detector to sense when water is too high, pumping it out until a safe level is reached.
• Reliable Performance : Enjoy trusted performance from a trusted brand with this American-made, dependable dishwasher that provides totally clean and dry dishes with every cycle.
• 1-Hour Wash Cycle : Unload spotless plates, glasses, pots and pans without waiting hours for the dishwasher to finish with this one-hour dishwasher cycle.
• AutoSense Cycle : This energy-saving dishwasher has an AutoSense Cycle that detects soil level and amount of dishes before automatically adjusting the wash setting for the ultimate clean.
• Wash Zones : Wash a true half-load in the upper or lower rack whenever you need to thanks to this dishwasher with Wash Zones. The feature works in combination with most cycles, saving you time and conserving energy.
• Piranha™ Hard Food Disposer : The Piranha™ Hard Food Disposer lets you use your dishwasher without pre-rinsing. Its stainless steel impellers rotate to pulverize food particles and an anti-jamming design makes sure wash arms stay unclogged.
• Extra Large Capacity : This extra-large capacity dishwasher has enough space for 16 place settings and large dishware, making cleanup easy after large gatherings.
• 47 dBA Dishwasher : Enjoy a peaceful kitchen and a powerful wash with this super-silent, 47 dBA dishwasher.
• Optional WiFi : Monitor this dishwasher with a smartphone and a WiFi adapter (sold separately) to enjoy a smart dishwasher experience. Simply attach the adapter and start using the SmartHQ™ app to control and monitor your unit remotely. You can even reorder detergent.
