Specifications

• APPEARANCE
  • Handle : Towel Bar
  • Door Style : Flat Door
  • Door Appearance : Full-length flat door
  • Color Appearance : Stainless Steel
  • Installation : Built-Up Floor Capable, Side Installation or Top Installation Included
  • Handle Color : Stainless Steel
• ECONOMICAL / QUIET
  • Quiet Package : 50 dBA
• FEATURES
  • Wash System : 3-Level
  • Tub Type : Tall Tub
  • Leveling System : 4 Leveling Legs
  • Number of Place Settings : 16
  • Dishwasher Options : Bottle Jets, Delay Start 1-12 Hr. with Countdown, Dry Boost™ (High), Dry Boost™ (Normal), Lock Controls, Sabbath Mode, Start/Reset, Steam + Sani (Certified to NSF Standard 184), Steam PreWash, Wash TempBoost, Wash Zone Lower Only, Wash Zone Upper Only
  • OU Certified : No
  • Number of Options : 7
  • Style : Built-In Top Control
  • Water Filtration System : 100% Filtration with Piranha Hard Food Disposer and Removable Filter
  • Sensor : Clean Sensor
  • Latch : Center Pull
  • Cutlery Tray : Optional 3rd rack (GPF3RACK)
  • Rack Features : 1 Piece Silverware Basket with 3 Cell Covers, 1 Utility Shelf with Stem Safe, Ball-Tipped Tines, Chop stick slots
  • Dishwasher Cycles : 1 Hour Wash, AutoSense, Heavy Wash, Normal Wash, Rinse
  • Rack Color : Silver
  • Dispenser : Detergent, Rinse Aid
  • Wash Arms : Lower, Middle, Upper
  • Wash System Features : Active Flood Protect, Automatic HotStart, Automatic Temperature Control, Fill Level Pressure Sensor, Piranha™ Hard Food Disposer with removable filter
  • Exterior Style : Traditional
  • Active Flood Protection : Active Flood Protect
  • Number of Cycles : 5
  • Sabbath Mode : Yes
  • Showroom Power Mode : Yes
  • EcoBalance Compatible : Yes
  • Control Type : 8 Touchpads, Cap Touch Controls, Top Controls
  • Product Type : Built-In
  • Upper Rack : 1 Stem Safe Shelf, Adjustable, Removable
  • WiFi Connect : Built-In
  • Dishwasher Drying Features : Calrod Heater, Dry Boost™
  • Tub and Door Liner : Hybrid Stainless Steel Interior
  • Dishwasher Control Features : 3 Digit Countdown Display with 1 "Clean" light / 1 "Sanitized" light Cycle Progress Indicators, Audible End-of-Cycle Signal, Last Cycle Memory
• FILTER
  • App Filter - Cabinet Width : Dish Traditional 24 in.
  • App Filter - Stainless Steel Interior : No
  • App Filter - Product Type : Dish Built-In Top Control
  • App Filter - WiFi Connect : Built-In
  • App Filter - Food Disposer : Yes
  • App Filter - Bottle Wash : Yes
• POWER / RATINGS
  • Power Connection : Optional cord kit (GPFCORD - WX09X70910, WX09X70911)
  • Energy Consumption (kWh/year) : 240
  • Calrod Heater Watts : 800/500
  • Electrical Requirements : 120V ; 60Hz ; 7.1A
• WARRANTY
  • Warranty Notes : See written warranty for full details
  • Parts Warranty : Limited 1-year entire appliance
  • Labor Warranty : Limited 1-year entire appliance
• WEIGHTS & DIMENSIONS
  • Height w/ Legs Retracted - Minimum Height : 33.375 in
  • Cutout Width (in) : 24 in
  • Overall Depth : 24 in
  • Cabinet Width : 24 in
  • Net Weight : 60 lb
  • Overall Width : 23.75 in
  • Cutout Height (in) : 33 1/2 in
  • Approximate Shipping Weight : 75 lb
  • Overall Height : 33.375 in
  • Overall Depth with Handle : 25.875 in
  • Height w/Legs Extended - Maximum Height : 34.625 in
  • Depth with Door Open : 27.5 in
  • Cutout Depth (in) : 24 in

Description

Top Control Panel: Sleek, top-mounted control panel for a clean, modern look and easy access to settings and wash cycles.

Stainless Steel Interior Door: Durable stainless steel interior door resists stains, odors, and ensures long-lasting performance while enhancing the dishwasher’s sleek appearance.

Sanitize Cycle: Effectively eliminates harmful bacteria and germs, ensuring your dishes are thoroughly sanitized for added peace of mind and hygiene.

Dry Boost Feature: Accelerates the drying process, ensuring that even plastic items come out completely dry and ready to use.

Multiple Wash Cycles: Includes various wash cycle options, from heavy-duty to delicate, providing versatility for a wide range of dishwashing needs.

Quiet Operation: Operates quietly, minimizing noise disruption and allowing you to run the dishwasher without disturbing your household.

Energy Efficient: Designed to reduce water and energy consumption, helping to lower utility bills while maintaining powerful cleaning performance.

User-Friendly Controls: Simple and intuitive top control interface, making it easy to adjust settings and select the ideal wash cycle for your dishes.

Sleek Modern Design: The stainless steel door and top control panel enhance your kitchen’s aesthetic with a contemporary, stylish look.

Features

• WiFi Powered by SmartHQ™ : Monitor cycle status, check detergent pod count and automatically reorder detergent using your mobile device
• Bottle Jets : This dishwasher with bottle jets ensures a deep clean for tall items, narrow glasses, jars and more. In the upper rack, each of the four bottle jets directs water and detergent inside to effectively wash hard-to-reach areas
• Dry Boost™ : Dry Boost gets hard-to-dry items like plastics up to 3x drier compared to heated dry
• Water Leak Sensor : This dishwasher features Active Flood Protect, preventing potential overflows for greater peace of mind. A water sensor cancels the wash cycle before a flood can occur and alerts you with blinking lights and a tone
• Steam + Sani : Save time with a Steam option that loosens tough soils before the wash cycle begins, so you get a complete clean with no pre-rinsing or soaking necessary. Plus, a Sanitization cycle reduces 99.999% of bacteria on dishes
• Reliable Performance : This American made dishwasher is durable, long-lasting and dependable. Its consistent performance will give you totally clean and dry dishes with every cycle
• Wash Zone : Wash a true half load in the upper or lower rack whenever you need to, instead of waiting on a full load. Just choose your wash zone: upper or lower. The feature works in combination with most cycles, saving you time and conserving energy
• AutoSense Wash Cycle : This energy efficient dishwasher has an AutoSense cycle that detects the soil level and amount of dishes, then automatically adjusts wash settings for the ultimate clean
• High Wash Performance : Get a complete wash with no pre-rinse, thanks to a variety of powerful wash cycles. No matter how many dishes you load or how dirty they are, rest assured you'll get spotless results every time
• Choose Your Cycle : This dishwasher offers a heavy wash, normal wash, rinse cycle and 1-hour wash cycle for outstanding wash performance and clean dishes every time, no matter the load size
• Adjustable Upper Rack : Enjoy flexible loading with an adjustable upper rack. Easily move it up or down to fit bottles, large platters and other items as tall as 10.5"
• Hard Food Disposer : The Piranha™ hard food disposer with a removable filter has a stainless steel blade that rotates at 3,600 RPM, preventing large particles from clogging the wash arms and ensuring consistently clean dishes
• ENERGY STAR® Dishwasher : This efficient, ENERGY STAR® dishwasher saves energy without sacrificing features or functionality
• Quiet 50 dBA Dishwasher : This quiet dishwasher provides a powerful clean without unwanted noise or disturbances. A status light on the door lets you know when it's running
• Extra Large Capacity : This extra large capacity dishwasher has enough space for 14 place settings and large dishware, making cleanup easy after gatherings
