Specifications

• ACCESSORIES
  • Optional 12' Drain Hose : Optional hose kit (WD24X10065)
• APPEARANCE
  • Installation : Built-Up Floor Capable, Flush Cabinet Installation, Side or Top Mount Install Brackets Included
  • Handle Color : Fingerprint Resistant Stainless
  • Door Style : Long Door with Top Controls
  • Door Appearance : Full-length door
  • Control Panel Color : Storm Gray
  • Handle : Pocket Handle
  • Color Appearance : Fingerprint Resistant Stainless
• ECONOMICAL / QUIET
  • Door Insulation : Insulation, Mastic
  • Quiet Package : 45 dBA
  • Outer Wrap : Bitumen, Full-wrap Blanket
  • Quiet Features : Quiet Water Valve, Sealed Toe Kick, Tub Collar Trim
  • Motor Type : Variable Speed
• FEATURES
  • Wash System : 3-Level, 600 Series
  • Lower Rack : Ball-Tip Tines
  • Leveling System : 4 Leveling Legs
  • OU Certified : No
  • Sensor : Clean Sensor
  • Additional Protection : Active Flood Protect
  • Number of Place Settings : 16
  • Dishwasher Options : Bottle Jets, Child Lock, Delay Start 1-12 Hr., Dry Boost™ (High), Dry Boost™ (Normal), Sabbath Mode, Start/Cancel, Steam + Sani (Certified to NSF Standard 184), Wash TempBoost, Wash Zone Lower Only, Wash Zone Upper Only
  • Latch : Pull with Handle
  • Tub Type : Tall Tub
  • Number of Options : 11
  • Style : Built-In Top Control
  • Water Filtration System : 100% Filtration with Piranha Hard Food Disposer and Removable Filter
  • Racking Material : Nylon
  • Dishwasher Cycles : 1 Hour Wash, AutoSense, Heavy Wash, Normal Wash, Rinse
  • Control Type : 8 Touchpads, Cap Touch Controls, Top Controls
  • Wash Arms : 3 Wash Levels, Bottle Jets, Bottle Wash Jets, Deep Clean Silverware Jets, Lower, Middle, Upper
  • Wash System Features : Automatic HotStart, Automatic Temperature Control, Bottle Jets (4), Drain Pump, Piranha™ Hard Food Disposer with removable filter, Variable Speed Dual Pumps and Motors
  • Top Rack/3rd Rack : 3rd Rack + Caddy
  • Exterior Style : Traditional
  • Upper Rack : Ball-Tip Tines, Premium Height Adjustable, Smooth Glide Upper Rack
  • Sabbath Mode : Yes
  • Rack Color : Silver
  • Showroom Power Mode : Yes
  • Cutlery Tray : One piece removable 3rd rack
  • Dispenser : Rinse Aid with Indicator and Adjustment
  • WiFi Connect : Optional (Requires part no. PBX23W00Y0)
  • Racking System : Full 3rd rack + caddy
  • Dishwasher Drying Features : Dry Boost™, Normal, High, Off
  • Number of Cycles : 5
  • Tub and Door Liner : Stainless Steel
  • Rack Features : 1 Piece Silverware Basket with 3 Cell Covers, Adjustable Upper Rack, Ball-Tipped Tines
  • Dishwasher Control Features : 1 "Clean" Light, 1 "Sanitized" Light Cycle Progress Indicators, 3 Digit Display Cycle Countdown with Bi-Color LED Status Light on door, Audible End-of-Cycle Signal, Control Lock with 1 Light, Last Cycle Memory
• POWER / RATINGS
  • Power Connection : Optional cord kit (GPFCORD - WX09X70910, WX09X70911)
  • Energy Consumption (kWh/year) : 240
  • Calrod Heater Watts : 800/500
  • Volts/Hertz/Amps : 120V; 60Hz; 6.6A
• WARRANTY
  • Warranty Notes : See written warranty for full details
  • Parts Warranty : Limited 1-year entire appliance
  • Labor Warranty : Limited 1-year entire appliance
• WEIGHTS & DIMENSIONS
  • Height w/ Legs Retracted - Minimum Height : 33.375 in
  • Cutout Height (in) : 33 1/2 in
  • Cutout Width (in) : 24 in
  • Net Weight : 99 lb
  • Overall Width : 23.75 in
  • Cabinet Width : 24 in
  • Overall Height : 34 in
  • Height w/Legs Extended - Maximum Height : 34.625 in
  • Overall Depth : 24 in
  • Approximate Shipping Weight : 112 lb
  • Depth with Door Open : 27.5 in
  • Cutout Depth (in) : 24 in

Description

Fingerprint Resistant Top Control Panel: The sleek, top-mounted control panel resists fingerprints, ensuring a clean, polished appearance while offering easy access to all settings and wash cycles.

Stainless Steel Interior: Durable and stain-resistant, the stainless steel interior offers long-lasting performance, easy maintenance, and a modern aesthetic.

Sanitize Cycle: Effectively removes harmful bacteria and germs, ensuring that your dishes are not only clean but also sanitized for added peace of mind.

Multiple Wash Cycles: Offers a variety of wash cycle options to accommodate different dishwashing needs, from heavy-duty loads to delicate glassware washes.

Quiet Operation: Designed to run quietly, minimizing noise and providing a peaceful environment, making it ideal for homes with an open-concept kitchen or sensitive areas.

Energy Efficient: Reduces water and electricity consumption, helping to lower utility bills while still delivering exceptional cleaning performance.

User-Friendly Controls: Intuitive top-mounted controls make it easy to adjust settings and select the ideal wash cycle for your dishes.

Modern Design: The fingerprint-resistant finish and stainless steel interior combine to create a sleek, contemporary look that complements any kitchen décor.

Features

• Dry Boost™ Technology : Dry Boost™ Technology outperforms standard heated-dry dishwashers by getting hard-to-dry items like plastics up to 3 times drier when compared to heated dry.
• Third Rack with Removable Silverware Caddy : The versatile Third Rack was redesigned to load more than just silverware with additional space for unique items.
• Deep Clean Silverware Jets : A system of 40 deep-cleaning silverware jets blasts the silverware basket from the bottom up, removing all stuck-on food for sparkling results.
• 4 Bottle Wash Jets : Ensure a deep clean for tall items, narrow glasses, jars and more thanks to this dishwasher with bottle jets. 4 powerful jets direct water and detergent inside to effectively wash hard-to-reach areas.
• Smooth-Glide Upper Rack : This dishwasher with a smooth-glide rack makes loading and unloading smooth and simple. It easily extends on stainless steel ball bearings, so you can make light work of even the heaviest loads.
• Steam + Sani : Save time with a high-temperature cycle that steams and sanitizes. Get a complete wash with no pre-rinsing or soaking necessary and reduce 99.999% of bacteria.
• High Wash Performance : Get a complete wash with no pre-rinse thanks to a variety of wash cycles that provides a powerful clean. No matter how many dishes you load or how dirty they are, rest assured you'll get spotless results every time.
• Active Flood Protect : This dishwasher features Active Flood Protect, which prevents potential overflows for greater peace of mind. It works by using a water leak detector to sense when water is too high, pumping it out until a safe level is reached.
• Reliable Performance : Enjoy trusted performance from a trusted brand with this American-made, dependable dishwasher that provides totally clean and dry dishes with every cycle.
• Piranha™ Hard Food Disposer : The Piranha™ Hard Food Disposer lets you use your dishwasher without pre-rinsing. Its stainless steel impellers rotate to pulverize food particles and an anti-jamming design makes sure wash arms stay unclogged.
• 45 dBA Dishwasher : Enjoy a peaceful kitchen and a powerful wash with this super-silent, 45 dBA dishwasher.
• Extra Large Capacity : This extra-large capacity dishwasher has enough space for 16 place settings and large dishware, making cleanup easy after large gatherings.
• Optional WiFi : Monitor this dishwasher with a smartphone and a WiFi adapter (sold separately) to enjoy a smart dishwasher experience. Simply attach the adapter and start using the SmartHQ™ app to control and monitor your unit remotely. You can even reorder detergent.
• 1-Hour Wash Cycle : Unload spotless plates, glasses, pots and pans without waiting hours for the dishwasher to finish with this one-hour dishwasher cycle.
• AutoSense Cycle : This energy-saving dishwasher has an AutoSense Cycle that detects soil level and amount of dishes before automatically adjusting the wash setting for the ultimate clean.
