Specifications

• ACCESSORIES
  • Optional 12' Drain Hose : Optional hose kit (WD24X10065)
• APPEARANCE
  • Handle : Recessed
  • Installation : Built-Up Floor Capable, Flush Cabinet Installation, Side Installation or Top Installation Included
  • Handle Color : Fingerprint Resistant Stainless
  • Door Style : Long Door with Front Controls
  • Door Appearance : Full-length door
  • Control Panel Color : Color Matched
  • Color Appearance : Fingerprint Resistant Stainless
• ECONOMICAL / QUIET
  • Quiet Package : 47 dBA
  • Door Insulation : Insulation, Mastic
  • Motor Type : Variable Speed
  • Outer Wrap : Bitumen
  • Quiet Features : Quiet Water Valve, Sealed Toe Kick, Tub Collar Trim
• FEATURES
  • Upper Rack : Ball-Tip Tines, Height Adjustable, Removable
  • Number of Cycles : 5
  • Wash System : 3-Level, 600 Series
  • Sensor : Clean Sensor
  • Lower Rack : Ball-Tip Tines
  • OU Certified : No
  • Leveling System : 4 Leveling Legs
  • Dishwasher Options : Bottle Jets, Child Lock, Delay Start 1-12 Hr., Dry Boost™ (High), Dry Boost™ (Normal), Sabbath Mode, Start/Cancel, Steam + Sani (Certified to NSF Standard 184), Wash TempBoost, Wash Zone Lower Only, Wash Zone Upper Only
  • Number of Options : 11
  • Style : Built-In Front Control
  • Dishwasher Cycles : 1 Hour Wash, AutoSense, Heavy Wash, Normal Wash, Rinse
  • Rack Color : Silver
  • Dispenser : Rinse Aid with Indicator and Adjustment
  • Tub Type : Tall Tub
  • Latch : Center Pull
  • Control Type : 8 Touchpads, Cap Touch Controls, Front Controls
  • Additional Protection : Active Flood Protect
  • Cutlery Tray : One piece removable 3rd rack
  • Racking System : Full 3rd rack
  • Dishwasher Drying Features : Dry Boost™, Normal, High, Off
  • Top Rack/3rd Rack : Yes
  • Exterior Style : Traditional
  • Tub and Door Liner : Stainless Steel
  • Sabbath Mode : Yes
  • Showroom Power Mode : Yes
  • Number of Place Settings : 16
  • Water Filtration System : 100% Filtration with Piranha Hard Food Disposer and Removable Filter
  • Rack Features : 1 Piece Silverware Basket with 3 Cell Covers, Adjustable Upper Rack, Ball-Tipped Tines
  • Racking Material : Nylon
  • WiFi Connect : Optional (Requires part no. PBX23W00Y0)
  • Wash Arms : 3 Wash Levels, Bottle Jets, Lower, Middle, Upper
  • Wash System Features : Automatic HotStart, Automatic Temperature Control, Bottle Jets (4), Drain Pump, Piranha™ Hard Food Disposer with removable filter, Variable Speed Dual Pumps and Motors
  • Dishwasher Control Features : 1 "Clean" Light, 1 "Sanitized" Light Cycle Progress Indicators, 3 Digit Display Cycle Countdown with Bi-Color LED Status Light on door, Audible End-of-Cycle Signal, Control Lock with 1 Light, Last Cycle Memory
• POWER / RATINGS
  • Power Connection : Optional cord kit (GPFCORD - WX09X70910, WX09X70911)
  • Energy Consumption (kWh/year) : 240
  • Calrod Heater Watts : 800/500
  • Volts/Hertz/Amps : 120V; 60Hz; 6.6A
• WARRANTY
  • Warranty Notes : See written warranty for full details
  • Labor Warranty : Limited 1-year entire appliance
  • Parts Warranty : Limited 1-year entire appliance
• WEIGHTS & DIMENSIONS
  • Overall Depth : 24 in
  • Approximate Shipping Weight : 112 lb
  • Cutout Height (in) : 33 1/2 in
  • Cabinet Width : 24 in
  • Overall Height : 34 in
  • Height w/ Legs Retracted - Minimum Height : 33.375 in
  • Cutout Width (in) : 24 in
  • Cutout Depth (in) : 24 in
  • Net Weight : 99 lb
  • Height w/Legs Extended - Maximum Height : 34.625 in
  • Depth with Door Open : 27.5 in
  • Overall Width : 23.75 in

Description

Front Control Panel: Convenient, front-mounted control panel for easy access and quick selection of wash cycles and settings.

Stainless Steel Interior: Durable and sleek stainless steel interior that resists stains and odors, providing long-lasting performance and a modern look.

Sanitize Cycle: Effectively eliminates bacteria and germs, ensuring your dishes are not only clean but also sanitized for added peace of mind.

Multiple Wash Cycles: Includes a range of wash cycles to suit different cleaning needs, from heavy-duty cleans to delicate washes for fragile items.

Quiet Operation: Designed to run quietly, minimizing noise and allowing you to operate the dishwasher without disrupting your home.

Energy Efficient: Reduces water and energy consumption, helping to lower your utility bills while still delivering powerful cleaning results.

User-Friendly Controls: Intuitive controls make it easy to select the desired settings, ensuring a hassle-free dishwashing experience.

Sleek, Modern Design: Combines contemporary style with advanced features to enhance the appearance and functionality of your kitchen.

Features

• Dry Boost™ Technology : Dry Boost™ Technology outperforms standard heated-dry dishwashers by getting hard-to-dry items like plastics up to 3 times drier when compared to heated dry.
• Third Rack : The versatile third rack was redesigned to load more than just silverware with additional space for unique items.
• 4 Bottle Wash Jets : Ensure a deep clean for tall items, narrow glasses, jars and more thanks to this dishwasher with bottle jets. 4 powerful jets direct water and detergent inside to effectively wash hard-to-reach areas.
• Adjustable Upper Rack : Lift or lower the adjustable top rack of the dishwasher to accommodate bottles, large platters or any items as tall as 10.5" thanks to flexible loading capabilities.
• Steam + Sani : Save time with a high-temperature cycle that steams and sanitizes
• High Wash Performance : Get a complete wash with no pre-rinse thanks to a variety of wash cycles that provide a powerful clean. No matter how many dishes you load or how dirty they are, rest assured you'll get spotless results every time.
• Active Flood Protect : This dishwasher features Active Flood Protect, which prevents potential overflows for greater peace of mind. It works by using a water leak detector to sense when water is too high, pumping it out until a safe level is reached.
• Reliable Performance : Enjoy trusted performance from a trusted brand with this American-made, dependable dishwasher that provides totally clean and dry dishes with every cycle.
• 1-Hour Wash Cycle : Unload spotless plates, glasses, pots and pans without waiting hours for the dishwasher to finish with this one-hour dishwasher cycle.
• AutoSense Cycle : This energy-saving dishwasher has an AutoSense Cycle that detects soil level and amount of dishes before automatically adjusting the wash setting for the ultimate clean.
• Wash Zones : Wash a true half-load in the upper or lower rack whenever you need to thanks to this dishwasher with Wash Zones. The feature works in combination with most cycles, saving you time and conserving energy.
• Piranha™ Hard Food Disposer : The Piranha™ Hard Food Disposer lets you use your dishwasher without pre-rinsing. Its stainless steel impellers rotate to pulverize food particles and an anti-jamming design makes sure wash arms stay unclogged.
• Extra Large Capacity : This extra-large capacity dishwasher has enough space for 16 place settings and large dishware, making cleanup easy after large gatherings.
• 47 dBA Dishwasher : Enjoy a peaceful kitchen and a powerful wash with this super-silent, 47 dBA dishwasher.
• Optional WiFi : Monitor this dishwasher with a smartphone and a WiFi adapter (sold separately) to enjoy a smart dishwasher experience. Simply attach the adapter and start using the SmartHQ™ app to control and monitor your unit remotely. You can even reorder detergent.
