Specifications

• ACCESSORIES
  • Wall Case : RAB46/47/48/24 Required At Additional Cost
• APPEARANCE
  • Color Appearance : White
• CAPACITY
  • Cooling BTUH (MAX) : 10000 Btu
  • Cooling EER (BTUH / Watt) : 9.6
  • Heating - Electric - BTUH - AHAM - 1R : 10600/8600
  • Dehumidification (pts./hr.) : 3.0
  • Cooling BTUH (MIN) : 9800 Btu
• FEATURES
  • Louver Style : 6-Way
  • Fan Speed Selections : 3 Cooling, 3 Fan Only
  • Optional Grill : RAG13/RAG13A/RAG14E
  • Product Type : Built-In
  • Refrigerant Type : R410A
  • Filter Type : Easy Access, Rigid, Tilt-Out, Washable
  • Chassis Type : Fixed
  • Vent/Air Exchange Exhaust : Top
  • Thermostat Type : Thermistor
  • LCDI / AFCI power cord : Yes
  • Cord Length : 48"
  • Rotary Compressor : Yes
  • Digital Time Temp Display : Yes
  • Plug Type : Perpendicular/NEMA 6-20
  • Air Flow Volume CFM High/Medium/Low : 292/275/252
  • Room Air Conditioner Features : Auto Fan, Batteries Included, Dehumidify Function, Energy Saver, Filter Indicator, Infrared Remote Control, On/Off Timer, Sleep Mode
• FILTER
  • App Filter - Voltage : 230 V
• POWER / RATINGS
  • Volts/Hertz : 230V-208V/60Hz
  • Cooling - Watts : 1042/1022
  • Voltage (MIN) : 208 V
  • Heating - Electric - Heater Watts : 3450/2821
  • Cooling - Rated Cooling Amps AHAM : 4.6/5.0
  • Voltage/Hertz/Phase : 230-208/60/1
  • Heating - Electric - Heater Amps : 15.0/13.5
  • CEER : 9.6
  • Voltage (MAX) : 230 V
• WARRANTY
  • Labor Warranty : Limited 2-year entire appliance
  • Parts Warranty : Limited 2-year entire appliance, Limited 2-year refrigeration system
• WEIGHTS & DIMENSIONS
  • Overall Height : 14.5625 in
  • Overall Width : 24.0625 in
  • Depth to Louvers : 20.625 in
  • Overall Depth : 19 in
  • Approximate Shipping Weight : 81 lb
  • Net Weight : 81 lb

Description

10,000 BTU cooling capacity for efficient temperature control in medium-sized rooms

Heat function for year-round comfort, providing both cooling and heating options

230/208V voltage for reliable performance and energy efficiency

Designed for thru-the-wall installation, offering a space-saving and sleek look

3-speed fan for adjustable air circulation to suit your preferences

Washable filter for easy maintenance and long-lasting performance

Auto mode for automatic temperature adjustment, ensuring consistent comfort

Sleek, compact design that blends seamlessly with your room decor

Ideal for rooms that require both cooling and heating, enhancing year-round comfort

Features

• True Universal Fit : Simple slide-in installation is built in for a precise fit into a variety of different wall sleeves. Quickly fit and retrofit with confidence. Trim kit and installation kit included
• Sleek Appearance : Streamlined design and bright white color will complement every room—cooling or heating your home in style
• Large LCD Display : Intuitive & easy-to-read LCD display controls room air comfort at a single touch
• ECO Mode : Innovative mode where the fan cycles off during cooling intervals, creating energy savings while keeping the room comfortable
• Dry Mode : Designed for humid environments, it helps provide a dryer & more comfortable atmosphere with room-air dehumidification
• 3-Speed Fan : Select High, Medium, Low or Auto Setting to achieve the best in air comfort & ultimate flexibility. Available on heat-cool models
• 6-Way Directional Airflow : Direct where the air flows with up to 6 directional vents—cooling and/or heating the areas of the room that need it the most
• Washable Filter : Easy to remove and rinse clean, the filter helps remove dust and other particles from transmitting in the air—providing a cleaner environment
• Auto Mode : Automatically select heating or cooling mode and fan speed to maintain the current temperature setpoint. It monitors the room temperature for optimal comfort
• Remote Control Included : Slim, intuitive and easy to use, the remote control enables adjusting temperatures and settings conveniently from anywhere in the room
• Universal Trim Kit : Designed for a custom appearance and easy installation, the trim kit provides a seamless appearance to the built-in wall sleeve
• Sleep Mode : Efficient setting to adjust temperature during sleep times for up to 7 hours, creating more energy savings
• 2 Year Warranty : GE Appliances cares about its products, offering replacement of any part of the air conditioner which fails due to defect in materials or workmanship up to 2 years from the date of purchase
