Specifications

• ACCESSORIES
  • Wall Case : RAB46/47/48/26 Required At Additional Cost
• APPEARANCE
  • Installation : Wall Mounted
  • Color Appearance : Soft Gray
• CAPACITY
  • Cooling BTUH (MAX) : 12000 Btu
  • Heating - Electric - BTUH - AHAM - 1R : 10600/8600
  • Dehumidification (pts./hr.) : 3.4/3.4
  • Cooling BTUH (MIN) : 11700 Btu
• FEATURES
  • Louver Style : 6-Way
  • Optional Grill : RAG13/RAG13A/RAG14E
  • Product Type : Built-In
  • Refrigerant Type : R32
  • Style : Thru-Wall
  • Plug Type : Perpendicular/Right Angle LCDI
  • Temperature Range : 60->85 F
  • Cord Length : 68"
  • Airflow (cfm) Roomside (hi/low) : 285/245, 275/235
  • Outdoor Vent / Exhaust : Yes
  • Air Discharge : Over / Under
  • Hertz : 60
  • Filter Type : Rigid Frame, Tilt-Out, Washable
  • Heating - Electric - Input Watts : 3450/2821
  • WiFi Connect : Built-In
  • Unit Type : Heat / Cool Unit
  • Fan Speed Selections : 3 Cooling, 3 Fan Only
  • Room Air Conditioner Features : Batteries Included, Improved Corrosion Package, Remote Control, Smart Fan Switch
  • Chassis Type : Slide-In
  • Remote Control : Yes
  • Thermostat Type : Electronic Digital
  • Control Type : Electronic
  • Rotary Compressor : Yes
• FILTER
  • App Filter - Voltage : 230 V
• POWER / RATINGS
  • Volts/Hertz : 230V-208V/60Hz
  • Voltage/Hertz/Phase : 230-208/60/1
  • Voltage (MIN) : 208 V
  • CEER : 9.5/9.5
  • Heating - Electric - Heater Amps : 15.0/13.5
  • Voltage (MAX) : 230 V
• WARRANTY
  • Warranty Notes : See written warranty for full details
  • Parts Warranty : Limited 2-year entire appliance, Limited 5-year sealed refrigerating system
  • Labor Warranty : Limited 2-year entire appliance, Limited 5-year sealed refrigerating system
• WEIGHTS & DIMENSIONS
  • Approximate Shipping Weight : 90.5 lb
  • Depth to Louvers : 5 in
  • Overall Height (Excludes Sleeve) : 14.875 in
  • Overall Depth (Excludes Sleeve) : 19.90625 in
  • Overall Width : 26 in
  • Overall Depth : 21.8125 in
  • Overall Width (Excludes Sleeve) : 24.8125 in
  • Net Weight : 90.5 lb
  • Overall Height : 15.625 in

Description

12,000 BTU Cooling Capacity: Efficiently cools large rooms for year-round comfort.

10,600 BTU Heating: Provides heating during colder months for all-season use.

3-Speed Fan: Customize airflow to your desired level for optimal comfort.

Electronic Cap Touch Controls: Easy-to-use, responsive controls for precise adjustments.

ECO Mode: Reduces energy consumption to save on electricity costs.

Dry Mode: Removes excess moisture from the air, ideal for humid conditions.

Auto Mode: Automatically adjusts settings for the best possible comfort.

Washable Filter: Helps maintain clean air and reduces the need for frequent filter changes.

Remote Control Included: Convenient remote control for adjusting settings from a distance.

ADA Compliant: Designed to meet the accessibility needs of all users.

Features

• Built-in WiFi powered by SmartHQ™
• True Built In Design : The ultimate fit & finish for more usable space and the best in built-in installation. Sleeve and chassis are perfectly integrated, creating a seamless fit without leaks or gaps
• Premium Guard Seacoast Protection : Premium Seacoast Protection on heat/cool models has special coatings and double coats of paint on key components including coils, base pan, compressor and stainless screws
• Premium Finish : Bright, clean color & a decorative metallic silver accent encasing the air discharge louver, provide an overall sleek appearance
• Electronic Cap Touch Controls : Controls offer a high-end and smooth to-the-touch panel
• Large LCD Auto-Dimming Display : Intuitive & large white LCD display can be easily seen from anywhere in the room. Convenient Auto-Dimming feature provides ambient lighting during the night
• Slim Room Front : A slim room front provides more usable space in the room. It’s the sleekest design in the industry
• ECO Mode : Innovative mode where the fan cycles off during cooling intervals, creating energy savings while keeping the room comfortable
• Dry Mode : Designed for humid environments, it helps provide a dryer & more comfortable atmosphere with room-air dehumidification
• Auto Mode : Automatically select heating or cooling mode and fan speed to maintain the current temperature setpoint. It monitors the room temperature for optimal comfort
• 3-Speed Fan : Select High, Medium, Low or Auto Setting to achieve the best in air comfort & ultimate flexibility. Available on heat-cool models
• 6-Way Directional Airflow : Direct where the air flows with up to 6 directional vents—cooling and/or heating the areas of the room that need it the most
• Washable Filter : Easy to remove and rinse clean, the filter helps remove dust and other particles from transmitting in the air—providing a cleaner environment
• Remote Control Included : Slim, intuitive and easy to use, the remote control enables adjusting temperatures and settings conveniently from anywhere in the room
• Quiet Performance : Designed & engineered by GE Appliances for ultra-quiet comfort
