Specifications

• ACCESSORIES
  • Air Fry Basket : Optional- JXAFTRAY1VSS
  • Center Grate : Optional - JXGRATE1
  • LP Conversion Kit : Included
  • Griddle Accessory : Reversible Integrated Grill/Griddle (Included)
• APPEARANCE
  • Cooktop Burner Grate Color : Matte Black
  • Handle Design : Designer Style
  • Handle Color : Black Stainless
  • Color Appearance : Fingerprint Resistant Black Stainless
  • Oven Door Features : Big View Oven Window
  • Control Knobs : Black Stainless
• CAPACITY
  • Total Capacity (cubic feet) : 6.8 cu ft
  • Capacity (Cu. Ft.) : 2.5 Upper / 4.3 Lower
• FEATURES
  • Ignition System : Electronic
  • Burner - Right Rear : 9,500 BTU
  • Connected Capabilities : Amazon Alexa, DiGiorno, Fresco, IFTTT, Innit, Sonos, The Google Assistant
  • WiFi Enabled Features : Clock Sync, Remote Control, Remote Notifications, Scan To Cook (Oven)
  • Cooktop Type : Continuous Grates with Griddle
  • Cooktop Burner Grate Material : Heavy Cast Iron
  • Interior Oven Light : 1 Auto Incandescent (Both Ovens)
  • WiFi Connect : Built-In
  • Cooktop Burner Grate Features : Continuous Grates
  • Control Type : Electronic Touch
  • Burner - Left Front : 20,000 BTU Tri-ring Burner
  • Cooking Technology : Traditional Upper; Convection Lower
  • Configuration : Double Oven Range
  • OU Certified : No
  • Cooktop Burner Type : Sealed
  • Oven Rack Positions (Single or Upper/Lower) : 2 / 5
  • Oven Cooking Modes : Bake, Broil (Lower Oven), Convection Bake (Lower Oven), Convection Roast (Lower Oven), No Preheat Air Fry (Lower Oven), Warming (Upper Oven)
  • Oven Rack Features : 3 Flat Nickel Racks
  • Power Boil Burner : Yes
  • Burner - Left Rear : 5,000 BTU Precise Simmer
  • Oven Cleaning Type : Self-Clean with Steam Clean Option (Both Ovens)
  • Griddle : Reversible Integrated Grill/Griddle (Included)
  • Sabbath Mode : Yes
  • Oven Control Features : Audible Preheat Signal, Auto Self Clean, Certified Sabbath Mode, Chef Connect, Control Lock Capability
  • Product Type : Free-Standing Double Oven
  • Fuel Type : Natural Gas (factory set)
  • Burner - Center : 10,000 BTU Oval
  • Burner - Right Front : 18,000 BTU Power Boil
  • Cooktop Surface : Dark Gray, Edge-to-Edge, One-Piece Upswept, Porcelain-Enamel
• FILTER
  • App Filter - Control Type : Electronic touchpad
  • App Filter - Product Type : Ranges Free-Standing Double Oven
  • App Filter - Cooking Technology : Convection, Traditional
  • App Filter - Dual Purpose Burner : Yes
  • App Filter - Convection : Yes
  • App Filter - Edge-to-Edge Cooktop : Yes
  • App Filter - Cabinet Width : Cooking 30 in. (Standard)
  • App Filter - WiFi Connect : Built-In
  • App Filter - Fuel Type : Gas
  • App Filter - Cleaning Type : Steam and Self-Clean
  • App Filter - Cooktop Type : Continuous Grates with Griddle
• POWER / RATINGS
  • Top Burner BTU Rating - Nat. Gas (000's BTU's) : (1) 10.0; (1) 9.5; (2) 18.0; (1) 5.0
  • Bake/Broiler BTU Rating - Nat. Gas (000's BTU's) : 7.0 / 120V - Upper; 14.0 / 16.5 - Lower
  • Bake/Broiler BTU Rating - LP (000's BTU's) : 7.0 / 120V - Upper; 13.5 / 13.5 - Lower
  • Volts/Hertz/Amps : 120v; 60Hz; 15A
  • Top Burner BTU Rating - LP (000's BTU's) : (1) 18.0; (1) 5.0; (1) 18.0; (1) 9.5; (1) 8.0
• WARRANTY
  • Parts Warranty : Limited 1-year entire appliance
  • Labor Warranty : Limited 1-year entire appliance
  • Warranty Notes : See written warranty for full details
• WEIGHTS & DIMENSIONS
  • Net Weight : 205 lb
  • Cabinet Width : 30 in
  • Approximate Shipping Weight : 242 lb
  • Overall Width : 30 in
  • Overall Height : 47.25 in
  • Overall Depth : 29.25 in
  • Depth with Door Open : 44 in
  • Depth Without Handle : 27.75 in
  • Height to Cooking Surface (in.) : 36 - 36 1/2
  • Oven Interior Dimensions (W x H x D) (in.) : 24 x 9-1/2 x 19-1/8 - Upper; 24 x 15 x 20-5/8 - Lower

Description

30'' free-standing gas range with a double oven for added cooking versatility

Convection technology for even cooking and baking results

No Preheat Air Fry function for healthier and faster meal preparation

Fingerprint-resistant finish for a sleek and smudge-free appearance

Ample cooking space to accommodate multiple dishes at once

Designed for reliable performance and modern kitchen convenience

Features

• No Preheat Air Fry : Cook healthier, crispier versions of your favorite foods in less time, thanks to an air fryer right in your oven that doesn’t require preheating, a basket or a special tray
• Reversible grill and griddle : This extra-large, reversible griddle and grill combination lets you enjoy the best in cooking versatility
• True Convection with Precise Air : This oven features True Convection, an advanced convection system that uses a third heating element and reversing fan for the highest level of heat and air circulation
• Synchronized clocks and lights : Synchronize your oven and GE Appliances over-the-range microwave so that clocks are always matching and lights automatically come on when a burner is activated with Chef Connect
• 3 oven racks : This oven features three adjustable racks for extra space in the oven
• Center oval burner : This center oval burner gives you a fifth burner and the perfect place to use griddles or odd-size cookware
• Self-clean with steam clean : This self-cleaning oven uses optional steam cleaning for light soils to clean the oven cavity with less heat and odor
• Heavy duty, dishwasher-safe grates : These cooktop grates can be cleaned one of two ways – either in the dishwasher, or on the bottom of a self-clean oven
• Tri-ring burner : A versatile burner offers three different-sized flame rings on a single burner element, so it's like having three burners in one
• Built-In WiFi, Powered by SmartHQ App : Connect, control and manage your oven from anywhere with your smartphone or tablet (Select features require WiFi Connection) See details
• GE Profile Connect + : Ensure your oven always has the latest features, like new Air Fry modes, with downloadable software upgrades
• Precise simmer burner : This burner setting provides low, even heat so delicate dishes don't burn
• Large capacity double oven : Cook an entire meal at once with a 6.7 cubic foot total capacity double oven which provides enough room for multiple dishes
