Specifications

• ACCESSORIES
  • Fill Hose : WH41X10207 (sold separately)
  • Optional Stacking Kit : GFA28KITN
  • Optional Riser : GFR0728PTDS (Sold Separately)
  • Optional Pedestal Accessory : GFP1528PTDS (Sold Separately)
• APPEARANCE
  • Handle Color : Carbon Graphite
  • Door Style : Chrome Outer Ring with Chrome Vent, Reversible Door, See-Thru Glass with Tinted Door Protect
  • Handle : Pocket Handle
  • Color Appearance : Carbon Graphite
  • Trim/Accents : Chrome Accents
  • Installation : Undercounter, Stacked, Side-by-Side, Built-In, Pedestal
• CAPACITY
  • Wash Basket Type : Stainless Steel - Tilted
  • Total Capacity (cubic feet) : 5.3 cu ft
• ECONOMICAL / QUIET
  • Quiet Package : Quiet-By-Design with dBT™ Quiet Control
• FEATURES
  • Washer Control Features : Add Garment/Pause, Control Lock, Delay Wash - Up to 24 hours, Digital Cycle Countdown, LED Display, LED Indicators, Remote Start, Variable End-of-Cycle Signal
  • Adaptive Capabilities : Adaptive Fill, Adaptive Spin, Auto-Load Sensing, Automatic Temperature Control
  • Receptacle Type : 3-Prong Grounding
  • Front Serviceable : Yes
  • Product Type : Front Load, Stackable
  • Dispenser : Bleach Timed Flow Through, Detergent (Liquid/Powder) Timed Flow Through, Fabric Softener Timed Flow Through, PreWash, Protected with Microban®, Smart Dispense - Bulk Detergent
  • Vibration Control : dBT™ Quiet Control patented technology
  • Control Type : Capacitive Touch, Capacitive Touch with Center Knob, Power On/Off, Start/Pause
  • Steam : Yes
  • Water Levels : Automatic Temperature Control, More Water Option
  • Optional Soil Levels : 5, Extra Heavy, Extra Light, Heavy, Light, Normal
  • Whites Cycle : Yes
  • Washer Cycles : Active Wear, Bulky/Bedding, Cold Wash, Delicates, Normal, Power Clean (Downloaded), Quick Wash, Rinse + Spin, Sanitize + Allergen, Self Clean, Towels, Whites
  • Water Temp System : Tap Cold, Cold, Warm, Hot, Extra Hot
  • Washer Options/Settings : 1 Step Wash + Dry, Adaptive My Settings, Add Garment, Delay Wash, Extra Rinse, My Settings, Pre Wash, Remote Start, Stain Guide, Time Saver, UltraFresh Vent
  • Additional Washer Features : Belt Drive, Front Serviceable, Internal heater, LED Basket Light, Power Cord Attached, Reversible Door
  • Wash/Rinse Temperatures : 5
  • OdorBlock Capabilities : UltraFresh Vent System Plus™ with OdorBlock™
  • Advanced Technology : Smart AI Features, including UltraFresh Vent System+ with OdorBlock™, Adaptive SmartDispense, and Adaptive MySettings
  • Pedestal : Optional
  • Specialty Cycles : Pre-Wash
  • Style : Front-Loading
  • Number of Cycles : 12
  • SmartDispense™ Technology : Adaptive SmartDispense
  • Connected Capabilities : Amazon Alexa, Geneva, Sonos, The Google Assistant
  • Maximum Spin Speed : 1300 RPM
  • Spin Speeds : 5
  • WiFi Connect : Built-In
  • Leveling System : Adjustable Leveling Legs
• POWER / RATINGS
  • Volts/Hertz : 120V; 60Hz
  • Motor Speeds : Variable
  • Circuit Breaker or Time Delay Fuse : 15 or 20 Amp
  • Energy Consumption (kWh/year) : 158
• WARRANTY
  • Warranty Notes : See written warranty for full details
  • Parts Warranty : Limited 1-year entire appliance, Limited 10-year motor
  • Labor Warranty : Limited 1-year entire appliance
• WEIGHTS & DIMENSIONS
  • Overall Height : 39.75 in
  • Approximate Shipping Weight : 264 lb
  • Depth with Door Open 90° : 56.5 in
  • Net Weight : 246 lb
  • Overall Width : 28 in
  • Overall Depth : 34 in

Description

5.3 cu. ft. capacity for handling large laundry loads

Smart technology with Adaptive SmartDispense for precise detergent distribution

ENERGY STAR® certified for energy-efficient performance

Steam function for deep cleaning and tough stain removal

UltraFresh Vent System Plus with OdorBlock to prevent odors and maintain freshness

Designed for efficiency, convenience, and high-performance cleaning

Features

• UltraFresh Vent System+ With OdorBlock™ : The first and only UltraFresh™ Vent System+ is enhanced with a sensor that detects and eliminates excess moisture to help prevent odors, ensuring your washer stays fresh and clean.
• Microban® Antimicrobial Technology : Get protection that lives on load after load with antimicrobial technology built into components including the gasket, dispenser, and draining system.
• Adaptive SmartDispense™ : Save time and effort with a dispenser that holds enough detergent for up to 32 loads. Plus, scan the barcode on the detergent bottle with the SmartHQ™ app and the washer will dispense the right amount based on the type of detergent.
• Smart Features Powered by SmartHQ™ : With SmartHQ™, you can make sure your washer always has the latest features, from extra cycles for jeans and swimwear, to customized stain removal technology for treating up to 30 different stains. It also delivers remote status notifications and enables remote capabilities, so you can easily control and monitor your washer from anywhere.
• 1 Step Wash + Dry : Wash and dry a small load in your washer, eliminating the need to transfer clothes to the dryer.
• Adaptive MySettings : By learning your preferences, the washer and dryer personalize your cycle selections automatically.
• Sanitize + Allergen : This industry-first cycle sanitizes fabrics to kill 99% of common bacteria and allergens such as dust mites.
• Dynamic Balancing Technology (dBT™) : Our patented time saving technology senses and rebalances uneven loads during the spin cycle, providing a quiet wash.
• Reversible Door : Easily reverse your washer and dryer door for superior installation flexibility.
• PowerSteam : Steam safely penetrates deep into fabric fibers, loosening stains and delivering enhanced cleaning performance.
• ENERGY STAR® Qualified : Meets or exceeds federal guidelines for energy efficiency for year-round energy and money savings.
