Specifications

• AC
  • Air Discharge : Front of Unit
  • Fan Speeds - Cool : 3
  • Fan Speeds - Fan : 3
  • Fan Speeds - Heat : 3
  • Motor RPM (Low) : 1340 RPM
  • Motor RPM (Med) : 1440 RPM
  • Motor RPM (High) : 1550 RPM
  • Noise Level dBA (Low) : 58 dBA
  • Noise Level dBA (Med) : 59 dBA
  • Option for Advanced Filtration : Yes
  • Rear Grill : Yes
  • Slide-Out Chassis : No
  • Air CFM (High) : 273 CFM
  • Dust Air Filter : Yes
  • Supplemental Heat : Yes
  • Air CFM (Low) : 230 CFM
  • Air CFM (Med) : 252 CFM
  • Air Direction Control : Manual
  • Noise Level dBA (High) : 61 dBA
  • Filter Access Location : Front
  • Filter Check Indicator : Yes
• Accessories Sold Separately
  • PureAir Filter : Yes
  • Sleeve Part Number : 912001373
• Connectivity
  • ??Wi-Fi Enabled : No
• Controls
  • Control Type : Electronic
  • Remote Control : Yes
• Dimensions and Volume
  • Sleeve Height : 15 1/2"
  • Max Wall Thickness : 18"
  • Sleeve Width : 26"
  • Sleeve Depth : 21 1/2"
• Electrical Specifications
  • Amps (Electrical Heat) : 15 Amps
  • Amps (Cool) : 6.5 Amps
  • Plug Type : LCDI 6-20P
  • Watts (Cool) : 1180 Watts
  • Watts (Electrical Heat) : 3450 Watts
  • Voltage Rating : 208/230v
• Functions
  • Auto Restart : Yes
  • Clean Air Ionizer : No
  • Dry Mode : Yes
  • Energy Saver : Yes
  • Low Voltage Start-up : Yes
  • Sleep Mode : Yes
  • 24-Hour On/Off Timer : Yes
  • Auto Fan : Yes
• General Specifications
  • Refrigerant Type : R-32
  • Product Weight : 75 lbs
  • Prop 65 Label : Yes
  • Warranty - Labor : 1 Year
  • Warranty - Parts : 1 Year
• Included Accessories
  • Trim Kit : Yes
• Installation
  • Power Cord Length : 66"
• Performance
  • Dehumidification - Pints per Hour : 3.5
  • Cool Area : 550 sq.
  • BTU (Electrical Heat) : 10600 BTU
  • Combined Energy Efficiency Ratio : 9.5
  • BTU (Cool) : 12000 BTU
• Safety Certifications and Approvals
  • CSA Listed : Yes
  • Energy Efficiency Verification (Canada) : Yes
  • ENERGY STAR Certified : No

Description

Wall-mounted design for efficient space-saving installation

12,000 BTU cooling capacity, ideal for cooling rooms up to 550 sq. ft.

10,600 BTU heating capacity for year-round comfort

Remote control for convenient operation from anywhere in the room

Sleep mode feature adjusts temperature for comfortable sleep

Multi-speed fan for customizable airflow settings

Energy-efficient operation for optimal performance and reduced energy costs

Quiet performance for a peaceful environment

Sleek, modern design to complement various room aesthetics

Features

• Use this unit year-round with a supplemental heating function, making this more than your standard air conditioner.
• Enjoy more cooling flexibility with three different fan speeds.
• Customize times to fit your schedule for immediate comfort when you get home by presetting the unit to turn on and off in half hour increments.
• Feel comfortable in your home's spaces with the quick cool/warm mode. The unit's fan speeds up so that your room can reach the desired temperature faster.
• The temperature gradually increases a few degrees over the course of the night to make the room more comfortable for sleeping and to save energy.
• This unit turns on and off at different intervals helping to reduce utility bills while keeping your home comfortable.
• Easily manage your room's temperature and fan speed from across the room with the included remote control.
• Comes with an extra long three-prong cord making extension cords unnecessary.
• Automatically resumes operating at its previous settings when power is restored to your unit.
• Get more out of your room air conditioner when you purchase the PureAir® RAC-7 Advanced Filter.
