Specifications

• Controls
  • Delay Start Hours : 1-24 Hours
  • Control Location : Top
  • Control Lock : Yes
  • Digital Display : Yes
  • Control Color : Black
  • Rinse Aid Indicator : Yes
• Dimensions and Volume
  • Depth With Door Open : 49 1/4"
  • Minimum Height : 33 1/2"
• Dishwasher
  • Filter Material : Stainless Steel
  • Filtered Water : 100 %
  • Smart Soil Sensor : Yes
  • Status Indicator Floor Beam : Yes
  • Tub Color : Midnight Ink
  • Tub Design : Tall Tub
  • Tub Material : Plastic
  • Wash Levels : 5
  • Wash System : Direct Feed
  • Water Pressure : 120 psi
  • Hard Food Disposer or Filtration : Yes
  • Interior Light : No
  • Motor Speeds : Multi-Speed
  • Detergent Dispenser : Yes
  • Filter Trap : Removable
  • Place Setting Capacity : 14
  • Rinse Aid Dispenser : Yes
  • Lower Spray Arm : Dual Orbit
  • Middle Spray Arm : Dual Orbit
  • Upper Spray Arm : Spray Arm
• Dishwasher Cycles
  • Energy Saver : Yes
  • Favorite : Yes
  • Heavy : Yes
  • Normal : Yes
  • China Crystal : Yes
  • Rinse Only : Yes
  • Number of Cycles : 8
  • Quick : Yes
  • Upper Rack : Yes
• Dishwasher Options
  • Drying System : MaxBoost
  • Heated Dry : Yes
  • High Temperature : Yes
  • Start/Cancel : Yes
  • Air Dry : Yes
• Electrical Specifications
  • Amps @ 120 Volts : 10 Amps
  • Voltage Rating : 120 V
  • Connected Load @ 120V : 1.2 kW
• Exterior
  • Door Type : StayPut
  • Exterior Finish : Smudge-Proof® Stainless Steel
  • Door and Handle Design : Wide Pocket
  • Door Latch : Pull
• General Specifications
  • Product Weight : 56 lbs
  • Prop 65 Label : Yes
  • Warranty - Labor : 1 Year
  • Sound Level : 49 dBA
  • Warranty - Parts : 1 Year
  • Annual Energy : 240 kWh
• Installation
  • Connection Location : Right Bottom
  • Number of Leveling Legs : 4
  • Water Inlet Location : Left Bottom Front
• Lower Rack
  • Maximum Height Clearance : 13"
  • Minimum Height Clearance : 11"
  • Number of Silverware Basket Lids : 3
  • Rack Type : Deluxe
  • Number of Silverware Basket : 1
  • Fold-Down : Yes
• Performance Certifications and Approvals
  • CEE Tier : Tier 1
  • cUL Listed : Yes
  • ENERGY STAR Certified : Yes
  • Meets ASSE 1006 Requirements : Yes
  • NSF Certified : Yes
  • UL Listed : Yes
• Upper Rack
  • Fold-Down : Yes
  • Minimum Height Clearance : 8"
  • Cup Shelf : Yes
  • Rack Handles : Yes
  • Rack Type : Adjustable
  • Stemware Holder : Yes

Description

14 Place Settings: Offers ample space to accommodate large loads and family-sized dishes.

8 Cycles: Includes a variety of wash cycles to suit different cleaning needs.

49 dBA Silence Rating: Operates quietly for a more peaceful kitchen environment.

Dual OrbitClean®: Provides superior coverage for thorough cleaning of every dish.

MaxBoostâ„¢ Dry: Enhances drying performance, leaving dishes dry and ready to put away.

DishSenseâ„¢: Automatically adjusts wash cycle settings based on load size for optimal cleaning.

NSF® Certified Sanitize: Ensures dishes are sanitized to meet rigorous standards.

Quick Wash: Offers a fast cleaning option for lightly soiled dishes.

Stay-Put Door: Keeps the door securely in place, even when partially open.

LED Floor Light: Provides a visual indication of the dishwasher's status.

ENERGY STAR® Certified: Energy-efficient design for a more sustainable and cost-effective operation.

Stainless Steel: Sleek, durable, and easy-to-clean finish that complements any kitchen décor.

Features

• The Dual OrbitClean® Wash System has two rotating wash arms with multi-directional spray patterns to remove tough, dried and baked on food.
• Skip pre-rinsing with our DishSense® sensor technology that adjusts cleaning performance based on the soil level of your dishes.
• MaxBoost™ Dry technology uses heating and a fan to push out moist air and pull in fresh, dry air so you don’t have to hand dry.
• Remove 99.9% of common household bacteria with NSF-Certified Sanitize Option.
• Save money and maximize energy efficiency.
• Keep your kitchen quiet and the noise inside your dishwasher where it belongs with extra, quality insulation.
• Make loading the dishwasher easier with adjustable racks and enough space to fit even your largest items.
• Convenient LED floor light shows cycle status- blue when your dishes are washing and green when they are clean.
• Save time and cleans dishes in just 34-minutes.
• Resists fingerprints and cleans easily.
• The door stays put at whatever angle you open it for easy loading and unloading.
