Specifications

• Controls
  • Control Lock : Yes
  • Sabbath Mode : Yes
• Cooking Controls
  • Bake : Yes
  • Bread Proof : Yes
  • Broil : Yes
  • Convection Bake : Yes
  • Convection Convert : Yes
  • Convection Roast : Yes
  • Cook Time : Yes
  • Dehydrate : Yes
  • Delay Clean : Yes
  • Delay Start : Yes
  • Keep Warm : Yes
  • Kitchen Timer : Yes
  • Clock : Yes
  • Door Lock : Yes
  • Lockout : Yes
  • On-Off : Yes
  • Oven Light : Yes
  • Oven Lock : Yes
  • Perfect Turkey : Yes
  • Probe : Yes
  • Self Clean : Yes
  • Slow Cook : Yes
  • Timer On / Off : Yes
  • Quick Preheat : Yes
  • Temperature Display : Yes
  • Steam Roast : Yes
  • Air Fry : Yes
  • Set Clock : Yes
  • Steam Clean : Yes
  • Steam Bake : Yes
• Cooking Controls Function
  • Program Fahrenheit or Celsius : Yes
  • Change between Continuous Bake Setting or 12-Hour Energy Saving Feature : Yes
  • Delayed Bake : Yes
  • Silent Control Panel : Yes
• Cooktop
  • Cooking Surface Type : Gas
  • Grate Material : Cast Iron
  • Grate Style : Continuous
  • Sealed Burners : Yes
  • Grate Quantity : 3
• Cooktop Performance
  • Right Front Element Burner : 18,000 / 1,200 BTU Dual
  • Right Rear Element Burner : 5,000 / 500 BTU
  • Left Front Element Burner : 18,000 / 1,200 BTU Dual
  • Left Rear Element Burner : 9,000 / 850 BTU
  • Center Front Element Burner : 16,000 / 2,000 BTU
  • Center Rear Element Burner : 16,000 / 2,000 BTU
• Dimensions and Volume
  • Oven Interior Width : 30 5/8"
  • Oven Capacity : 4.6 Cu. Ft.
  • Minimum Height : 35 3/4"
  • Depth With Door 90° Open : 48 3/8"
  • Depth With Handle : 27 5/8"
  • Oven Interior Height : 13 3/4"
  • Oven Interior Depth : 16 7/8"
• Display
  • Control Location : Front
  • Display Light Color : White
  • Display Type : Capacitive Touch
• Electrical Specifications
  • Voltage Rating : 240 V
  • Minimum Circuit Required : 30 Amps
• Exterior
  • Exterior Finish : Smudge-Proof® Stainless Steel
  • Backlit Knobs : Yes
• General Specifications
  • Frigidaire Fit Promise : Yes
  • AB-1200 : Information available at frigidaire.com/en/ab1200
  • Product Weight : 240 lbs
  • Warranty - Labor : 1 Year
  • Prop 65 Label : Yes
  • Warranty - Parts : 1 Year
• Installation
  • Adjustable Leveling Legs : Yes
  • LP Conversion Kit Included : Yes
  • Plinth : Yes
  • Rear Ventilation Trim : Yes
• Oven
  • Bake Element : 1900 Watts
  • Broil Element : 3800 Watts
  • Convection Element : 2400 Watts
  • Number of Convection Fans : 2
  • Oven Interior Color : Midnight Black
  • Oven Light Watts : 40 Watts
  • Rack Position Type : Ladder
  • Rack Type 2 : Flat
  • Rack Type 2 Quantity : 1
  • Bake Element Type : Hidden
  • Rack Type 1 : Glide
  • Rack Type 3 : Air Fry Tray
  • Cleaning System : Yes
  • Rack Type 1 Quantity : 1
  • Number of Rack Positions : 5
  • Oven Light Quantity : 2
  • Oven Light Type : Halogen
  • Convection : Yes
  • Convection Type : Total
  • Rack Type 3 Quantity : 1
• Safety Certifications and Approvals
  • RoHS : Yes
  • CSA Listed : Yes
  • Star-K Certification : Yes

Description

Frigidaire Gallery 36'' Dual Fuel Range with Total Convection system enables cooking modes like Air Fry, Quick Preheat, Slow Cook, Steam Bake, Convection Bake and more! The flexible six burner cooktop offers ultimate cooking flexibility including two powerful 18,000 BTU Quick Boil Burners and a 5,000 BTU burner for simmering delicate foods. Dual Fuel technology offers the power of a gas cooktop and precision of an electric oven. Also includes a temperature probe and Air Fry Tray and features our fingerprint resistant, Smudge-Proof�Stainless Steel finish.

Features

• Gives you maximum versatility in the kitchen, powering cooking modes like Air Fry, Slow Cook, Convection Bake, Steam Bake, Convection Roast, Steam Roast, Bread Proof, Dehydrate and more!
• Make healthier and delicious meals for your entire family - right in your oven.
• Six burner cooktop provides the ultimate cooking flexibility, including two powerful 18,000-BTU Quick Boil Burners, two 16,000-BTU burners and a 5,000-BTU simmer.
• Your food cooks slowly and at a lower temperature (as low as 100° F), allowing you to lock in moisture and flavor without over or undercooking your food.
• Monitors and alerts when the desired finished cooking temperature has been reached.
• Select Steam Clean for a quick, 30 minute clean or choose Self Clean, which is available in 2, 3 and 4 hour cycles.
• Features the power of a gas cooktop and the precision of an electric oven for baking, so you get maximum versatility and delicious results.
• With Steam Bake, steam evenly circulates throughout the oven cavity, resulting in breads and muffins that rise higher and are light and fluffy.
• Steam Roast uses moisture to make perfectly crispy and tender meats and vegetables that are roasted to perfection.
• Start cooking in just a few minutes with Quick Preheat
• Air Fry tray included, perfect for crispy and delicious Air Fry results.
• Our extending Glide Rack makes it easier to monitor and lift your food out of the oven.
• Features a responsive 4.3 inch, full color, capacitive touch digital control panel.
• Lights up when the burner is turned on.
• Move even your heaviest pots and pans without the need to lift them.
• Convenient drop down door storage compartment is located below the oven cavity, allowing you to store any unused oven racks or baking trays.
• Resists fingerprints and cleans easily.
• Product complies with the Americans with Disabilities Act.
