Specifications

• Certifications and Approvals
  • ADA Compliant : Yes
  • cUL Listed : Yes
  • UL Listed : Yes
  • ENERGY STAR Certified : Yes
  • RoHS : Yes
• Cooktop
  • Auto Pan Detect : Yes
  • Bridge Element : Yes
  • Bridge Element Location : Left
  • Cooking Surface Type : Smooth
• Cooktop Performance
  • Right Front Element Burner Size : 8"
  • Left Front Element Burner Size : 7"
  • Left Rear Element Burner Size : 7"
  • Center Rear Element Burner Size : 8"
  • Right Front Element Burner : 2,300 / 3,600 Watts (Boost)
  • Left Front Element Burner : 1,800 / 2,600 Watts (Boost)
  • Left Rear Element Burner : 1,800 / 2,600 Watts (Boost)
  • Center Element Burner : 2,300 / 3,600 Watts (Boost)
• Dimensions and Volume
  • Minimum Cutout Depth : 19 5/8"
  • Maximum Cutout Width : 29 7/8"
  • Cutout Height : 3 5/8"
  • Minimum Cutout Width : 28 1/2"
  • Maximum Cutout Depth : 20 1/2"
• Display
  • Display Interface Color : Red
  • Display Type : Capacitive Touch
  • Control Location : Front
• Electrical Specifications
  • Amps @ 240 Volts : 30 Amps
  • Minimum Circuit Required : 30 Amps
• General Specifications
  • Warranty - Parts : 1 Year
  • AB-1200 : Information available at frigidaire.com/en/ab1200
  • Frigidaire Fit Promise : Yes
  • Warranty - Labor : 1 Year
  • Product Weight : 39 lbs
  • Prop 65 Label : Yes

Description

Auto Sizingâ„¢ Pan Detection: Adjusts the cooking zone to fit the size of your cookware for efficient heating.

Bridge Element: Combines two cooking zones into one larger area, ideal for oversized pots or griddles.

Safe Surface: Keeps the cooktop cool to the touch, enhancing safety during use.

Touch Controls: Provides an intuitive and easy-to-use interface for seamless operation.

Temperature Precision: Maintains consistent heat for perfect cooking results.

TempLockâ„¢: Locks in the desired temperature, preventing accidental changes.

Cooktop Timer: Allows for precise cooking time control for added convenience.

ADA Compliant: Designed to be accessible and user-friendly for all individuals.

Features

• Unlike traditional electric and gas cooktops, Induction only heats the pan and the food in it, so the area around the pan stays cooler, allowing you to clean up spills and splatters while you cook.
• With induction, heat transfers directly to the cookware bypassing the cooktop surface, making induction incredibly fast.
• Sensors in the cooktop automatically adjust the power level to maintain a consistent temperature the entire time you cook - it's like cruise control for your cooktop.
• Recipient of the 2024 Food Network Editor’s Pick Award
• Connects two elements to allow for simultaneous control, perfect for a griddle pan.
• Induction only heats the pan and the food in it, so the area around the pan stays cooler.
• We promise that your new 30" Frigidaire induction cooktop will fit your existing countertop cutout of the same width and configuration, or we will reimburse you for cabinet modification costs up to $100.
• Get to mealtime easier with auto pot detection that lights up cooktop controls for the element a pan is placed on when the cooktop is on.
• Use less energy while you cook with energy-efficient induction technology which heats the pan directly so less heat loss in the cooking process.
• Most stainless steel and cast iron cookware is compatible with induction elements. Rule of thumb: if a magnet sticks to the bottom of the cookware, it’s induction-compatible.
• Cooktops are approved for installation above any of our Frigidaire or Frigidaire Gallery Single Electric Wall Ovens.
