Specifications

• Accessories (sold separately)
  • Square handle option : AH-R36
• Burner ratings
  • Power back centre : 13000BTU
  • Power back right : 13000BTU
  • Total cooktop power : 88000 BTU
  • Power back left : 13000BTU
  • Power front centre : 15000BTU
  • Power front left : 17000BTU
  • Power front right : 17000BTU
  • Maximum burner power : 17000 BTU
• Capacity
  • Shelf positions : 5
  • Total capacity : 5.3cu ft
  • Usable capacity : 4cu ft
• Controls
  • Electric circuit : 3 wire
  • Metal illuminated dials : true
• Gas requirements
  • Supply Pressure (LPG) : 11" to 14" W.C
  • Fitting and pipe : ½ NPT, min. ?" Ø flex line
• Oven features
  • Auto re-ignition system : true
  • Broil pan : true
  • Electronic oven control : true
  • Full extension telescopic sliding shelves : true
  • Titanium coated, illuminated metal dials : true
  • Infrared Broiler : true
  • Internal light : true
• Oven functions
  • Bake : true
  • Number of functions : 4
  • Slow cook : true
  • Broil : true
  • Convection bake : true
• Oven performance
  • Broil power : 19,000 BTU
  • Bake power : 21,500 BTU
• Power requirements
  • Service : 15 A
  • Power supply : 120 V, 60 Hz
• Product dimensions
  • Depth : 29 1/8"
  • Height : 35 3/4 - 36 3/4"
  • Width : 35 7/8"
• Rangetop features
  • Sealed range top : true
  • Vent trim included : true
• Recommended Back Guards Ventilation
  • Combustible situation : BGRV3-3036H
  • Non combustible situation : BGRV2-3036 / BGRV2-1236
  • Recommended hood : HCB36-6_N (36" Professional Range Hood) / HCB36-12_N (36" Professional Range Hood, Dual Blower)
• Safety
  • Full extension telescopic sliding shelves : true
  • ADA compliant : true

Description

Professional style with power. 17,000 BTU gas burners paired with a large capacity gas oven.

Features

• Featuring a generous total capacity of 5.3 cu ft, with enough room to fit a 32 lb turkey and full-sized baking sheets.
• Sealed Dual Flow Burners™ deliver cooktop power up to 17,000 BTU for seriously fast boiling right down to a precise 140°F full surface simmer with the gentlest of flames.
• The cooktop is designed for easy access to any burner with grates you can smoothly slide pots across. The oven is large enough to hold full size baking sheets.
• This range has craftsmanship in every detail, with real stainless steel, cast-iron grates, and titanium coated dials. Each cavity features incandescent lights and full extension telescopic racks. From the robust legs to the powerful legs to the powerful cooktop, the Range is built to last.
• Cleaning up spills is effortless with the continuous, porcelain basepan. Your cooktop simply needs a quick wipe to keep it looking good as new.
• Precise control across high and low settings is delivered through the halo-illuminated cooktop dials.
