Specifications

• Accessories (included)
  • Adjustable feet covers : true
  • Branded coin end cap : true
• Accessories (sold separately)
  • Square handle option : AH-R48
• Burner ratings
  • Maximum burner power : 23500 BTU
  • Power back centre : 18500BTU
  • Power back left : 18500BTU
  • Power front right : 23500BTU
  • Power back right : 18500BTU
  • Power front centre (2) : 18500BTU
  • Power back centre (2) : 18500BTU
  • Power front centre : 18500BTU
  • Power front left : 23500BTU
  • Total cooktop power : 158000 BTU
• Capacity
  • Total capacity (main oven) : 4.8cu ft
  • Shelf positions (main oven) : 5
  • Usable capacity (main oven) : 3.8cu ft
  • Shelf positions (second oven) : 5
  • Total capacity second oven : 2.1cu ft
• Cleaning
  • Pyrolytic self-clean : true
  • Easy clean porcelain basepan : true
• Controls
  • Dial with illuminated halo : true
  • Dual control oven dials : true
  • Electric circuit : 4 wire
  • Metal illuminated dials : true
  • Precise cooking with food probe : true
  • Smart Appliance : true
  • Wi-Fi connectivity : true
  • Recipe and food based functions : true
  • Sabbath mode : true
  • Tilting touch screen interface : true
  • High resolution display : true
  • Multi-language interface : true
• Gas requirements
  • Fitting and pipe : ½ NPT, min. ?" Ø flex line
  • Supply Pressure (natural gas) : 6" to 9" W.C
• Oven features
  • Auto re-ignition system : true
  • Concealed element : true
  • Electronic oven control : true
  • Full extension telescopic sliding shelves : true
  • Self-clean proof side racks : true
  • Internal light : true
  • Titanium coated, illuminated metal dials : true
• Oven functions
  • Dehydrate : true
  • Number of functions : 15
  • Rapid proof : true
  • Roast : true
  • Slow cook : true
  • True convection : true
  • Warm : true
  • Air fry : true
  • Bake : true
  • Classic bake : true
  • Maxi Broil : true
  • Clean : true
  • Convection bake : true
  • Convection broil : true
  • Pastry bake : true
  • Pizza bake : true
• Oven performance
  • Bake power : 4600
  • Broil : 3600W
  • Main oven - True convection power : 2500W
• Power requirements
  • Power supply : 120 / 240 V, 60 Hz
  • Connection : 4-prong grounding type [NEMA 14-50 plug]
  • Service : 50 A
• Product dimensions
  • Depth : 29 1/8"
  • Height : 35 3/4 - 36 3/4"
  • Width : 47 7/8"
• Rangetop features
  • Sealed range top : true
  • Vent trim included : true
• Recommended Back Guards Ventilation
  • Non combustible situation : BGRV2-3048 / BGRV2-1248
  • Combustible situation : BGRV3-3048H
  • Recommended hood : HCB48-12_N (48"" Professional Range Hood, Dual Blower)
• Safety
  • ADA compliant : true
• Secondary oven features
  • Electronic oven control : true
  • 3/4 Extension racks : 2
  • Concealed element : true
  • Food probe : true
  • Internal light : true
• Secondary oven functions
  • Warm : true
  • Classic bake : true
  • Air fry : true
  • Bake : true
  • Maxi broil : true
  • Number of secondary oven functions : 11
  • Pastry bake : true
  • Pizza bake : true
  • Rapid proof : true
  • Roast : true
  • Convection bake : true
  • Convection broil : true

Description

With intuitive touchscreen and specialized cooking functions across two ovens, this range is a stand-out addition to your kitchen.

Features

• Our touchscreen interface provides an intuitive guided cooking experience that helps deliver perfect results, whether you’ve been cooking all your life or just starting out. Cook with a favorite method, a hero ingredient, or a go-to cooking function or recipe. The screen tilts for improved ergonomics and optimal visibility while cooking.
• Two independently operating cavities provide a large total capacity of 4.8 cu. ft. in the main cavity and 2.1 cu. ft. in the secondary. That’s enough room for a 32 lb turkey in one oven, and your sides in the other.
• No matter what you're cooking, you've got the right heat to get perfect results. Each of the 15 oven functions in the main cavity and 11 in the secondary have been extensively researched and carefully designed to cater to a broad range of dishes and cooking styles. The handy food probe helps you monitor your progress.
• Sealed dual flow burners deliver cooktop power up to 23,500 BTU for seriously fast boiling, and precise 140°F full surface, low temperature cooking with the gentlest of flames.
• This range has craftsmanship in every detail, with real stainless steel, cast-iron grates, and beautifully weighted, halo illuminated dials. Each cavity features incandescent lights and full extension telescopic racks. From the robust legs to the powerful cooktop, this Range is built to last.
• The oven features a self-cleaning function and self-clean proof side racks, which don't need to be removed when using this function.
