Specifications

• Accessories (included)
  • Adjustable feet covers : true
  • Telescopic sliding runners : true
  • Branded coin end cap : true
• Accessories (sold separately)
  • Square handle option : AH-R48
• Burner ratings
  • Power back centre : 13000BTU
  • Power back right : 13000BTU
  • Power front centre : 15000BTU
  • Power front left : 19000BTU
  • Power front right : 15000BTU
  • Power griddle : 15000BTU
  • Total cooktop power : 103000 BTU
  • Maximum burner power : 19000 BTU
  • Power back left : 13000BTU
• Capacity
  • Shelf positions (second oven) : 5
  • Total capacity (main oven) : 4.8cu ft
  • Total capacity second oven : 2.1cu ft
  • Shelf positions (main oven) : 5
  • Usable capacity (main oven) : 3.8cu ft
• Cleaning
  • Easy clean porcelain basepan : true
  • Pyrolytic proof shelf runners : true
• Controls
  • Dial with illuminated halo : true
  • Dual control oven dials : true
  • Multi-language interface : true
  • Smart Appliance : true
  • Tilting touch screen interface : true
  • Wi-Fi connectivity : true
  • Precise cooking with food probe : true
  • Recipe and food based functions : true
  • Sabbath mode : true
  • High resolution display : true
• Gas requirements
  • Fitting and pipe : ½ NPT, min. ?" Ø flex line
  • Supply Pressure (LPG) : 11" to 14" W.C
• Oven features
  • Full extension telescopic sliding shelves : true
  • True convection : true
  • Auto re-ignition system : true
  • Electronic oven control : true
  • Internal light : true
  • Large broil pan : true
  • Self-clean proof side racks : true
  • Food probe : true
  • Concealed element : true
• Oven functions
  • Air fry : true
  • Bake : true
  • Classic bake : true
  • Clean : true
  • Convection bake : true
  • Dehydrate : true
  • Maxi Broil : true
  • Number of functions : 15
  • Pastry bake : true
  • Pizza bake : true
  • Slow cook : true
  • Rapid proof : true
  • Roast : true
  • True convection : true
  • Warm : true
  • Broil : true
  • Convection broil : true
• Power requirements
  • Connection : 4-prong grounding type [NEMA 14-50P plug]
  • Power supply : 120 / 240 V, 60 Hz
  • Service : 50 A
• Product dimensions
  • Height : 35 3/4 - 36 3/4"
  • Depth : 29 1/8"
  • Width : 47 7/8"
• Rangetop features
  • Vent trim included : true
  • Sealed range top : true
• Rangetop Performance
  • Number of burners : 6
• Recommended Back Guards Ventilation
  • Combustible situation : BGRV3-3048H
  • Non combustible situation : BGRV2-3048 / BGRV2-1248
  • Recommended hood : HCB48-12_N (48" Professional Range Hood, Dual Blower)
• Safety
  • ADA compliant : true
  • Child lock : true
• Secondary oven features
  • 3/4 Extension racks : 2
  • Electronic oven control : true
  • Food probe : true
  • Internal light : true
  • Concealed element : true
• Secondary oven functions
  • Air fry : true
  • Classic bake : true
  • Bake : true
  • Convection bake : true
  • Convection broil : true
  • Pastry bake : true
  • Pizza bake : true
  • Rapid proof : true
  • Roast : true
  • Warm : true
  • Maxi broil : true
  • Number of secondary oven functions : 11
• Warranty
  • Parts and labor : Limited 2 years

Description

With intuitive touchscreen and specialized cooking functions across two ovens, this range is a stand-out addition to your kitchen.

Features

• Our touchscreen interface provides an intuitive guided cooking experience that helps deliver perfect results, whether you’ve been cooking all your life or just starting out. Cook with a favorite method, a hero ingredient, or a go-to cooking function or recipe. The screen tilts for improved ergonomics and optimal visibility while cooking.
• Two independently operating cavities provide a large total capacity of 4.8 cu. ft. in the main cavity and 2.1 cu. ft. in the secondary. That’s enough room for a 32 lb turkey in one oven, and your sides in the other.
• No matter what you're cooking, you've got the right heat to get perfect results. Each of the 15 oven functions in the main cavity and 11 in the secondary have been extensively researched and carefully designed to cater to a broad range of dishes and cooking styles. The handy food probe helps you monitor your progress.
• Sealed dual flow burners deliver cooktop power up to 19,000 BTU for seriously fast boiling, and precise 140°F full surface, low temperature cooking with the gentlest of flames.
• This range has craftsmanship in every detail, with real stainless steel, cast-iron trivets, and beautifully weighted, halo illuminated dials. Each cavity features incandescent lights and full extension telescopic racks. From the robust legs to the powerful cooktop, this Range is built to last.
• The oven features a self-cleaning function and self-clean proof side racks, which don't need to be removed when using this function.
