Specifications

• Accessories (included)
  • Full extension telescopic shelves : 2 sets (part 578744)
  • Small pot support : 1 (part 533981 cast)
  • Chromed shelf runners : 1 set
  • 2-pc grill system (Broil pan and Grill rack) : true
  • Broil pan : true
  • Broil rack : true
• Accessories (sold separately)
  • Kick strip, black (optional) : KICKOR36B1
  • Kick strip, red (optional) : KICKOR36R1
  • Kick strip, stainless steel (optional) : KICKOR36X1
  • Kick strip, white (optional) : KICKOR36W1
• Burner ratings
  • Semi-rapid burner (natural gas) : 8000BTU
  • Triple ring wok burner (LPG) x2 : 6100 - 12000BTU
  • Dual wok burner inner/outer (LPG) : 1000 - 18000BTU
  • Maximum burner power : 18000 BTU
  • Semi-rapid burner (LPG) : 7600BTU
  • Total cooktop power : 62000 BTU
  • Triple ring wok burner (natural gas) x2 : 6100 - 14000BTU
  • Dual wok burner inner/outer (natural gas) : 1000 - 18000BTU
• Capacity
  • Shelf positions : 7
• Cleaning
  • Acid resistant graphite enamel : true
  • Removable shelf runners : true
  • Removable oven door : true
• Controls
  • Laser etched graphics : true
• Gas requirements
  • Supply Pressure (LPG) : 11" W.C.P
  • Supply Pressure (natural gas) : 4" W.C.P
• Oven features
  • Auto re-ignition system : true
  • Concealed element : true
  • Electronic ignition : true
  • Full extension telescopic sliding shelves : true
  • Soft open/close door : true
  • Storage drawer : true
  • Convection : true
  • Internal light : 4 x 25W halogen (2 side & 2 top)
• Oven functions
  • Bake : true
  • Broil : true
  • Convection bake : true
  • Number of functions : 3
• Oven performance
  • Bake power : 17000 BTU
  • CoolTouch door : Quadruple glazed
  • Broil : 13000 BTU
• Power requirements
  • Amperage : 15A
  • Supply frequency : 60Hz
• Product dimensions
  • Depth : 25 1/4"
  • Width : 35 7/8"
  • Height : 35 3/4 - 37 1/4"
• Rangetop features
  • Hob rail : true
  • LPG/Natural gas compatible : true
  • Sealed range top : true
• Rangetop Performance
  • Number of burners : 5
• Safety
  • Full extension telescopic sliding shelves : true
  • Non-tip shelves : true
  • Spill containment : 5/8 gallon
  • Advanced cooling system : true
  • Anti-tilt bracket : true
  • Balanced oven door : true
  • Full extension telescopic shelves : 2 sets (part 578744)
  • ADA compliant : true

Description

Make your range a focal point. With a large capacity oven and five burners, this is the perfect way to cook for a crowd.

Features

• This range has been carefully crafted in every detail from performance to durability using quality materials including the balanced soft-close door and rounded rangetop rail.
• The generous 4.9 cu.ft total capacity oven gives you plenty of space to cook multiple dishes at once, with enough room to fit a 32 lb turkey.
• Precise cooktop controls let you sear or stir fry over instant, powerful heat. Use the high burner power or simmer a delicate sauce using the gentlest of heats.
• With its durable surface, your cooktop simply needs a quick wipe after cooking to keep it looking good as new for years to come.
