Specifications

• Accessories (included)
  • Cutlery basket : true
  • Knife clip and multipurpose clip : true
• Accessories (sold separately)
  • Handle kit Contemporary square fine, aluminium : AHD5-OBDD-60SX
  • Handle kit Contemporary square fine, black : AHD5-OBDD-60SB
  • Handle kit Professional round flush : AHP3-DWDD-SX
  • Handle kit Contemporary round, aluminium : AHS-OBDD-60S
  • Handle kit Professional round flush, Brass off-stands : AHP3DDDW24BA
  • Handle kit Classic : AHCL-DDDW-24X
  • Handle kit Contemporary square, aluminium : AHD3-OBDD-60S
  • Door panel stainless steel : ADDD24SPX
  • Handle kit Professional round flush, Dark Copper off-stands : AHP3DDDW24DC
• Capacity and loading
  • Pitch adjustable tines : true
  • Place settings : 7
  • Accommodates round plates up to : 11"
  • Adjustable height, foldable cupracks : true
  • Fold down tines : true
• Consumption
  • Energy usage : 144kWh/year
  • Water usage (per wash cycle) : 1.64 gal
• Controls
  • Electronic fault/Diagnostic indicator : true
  • Rinse aid indicator light : true
  • End of cycle beeps : true
  • Energy saving delay start option of up to 12 hours : true
  • Internal wash selector : true
  • Keylock : true
  • Knock to pause : true
  • Smart Appliance : true
• Features
  • Fan assisted drying : true
  • Flow through detergent dispenser : true
  • SmartDrive™ technology : true
  • Quiet operation : true
• Performance
  • Noise emissions : 43dBA
• Power requirements
  • Electric circuit : 3 wire
  • Rated current : 15A
  • Supply frequency : 60Hz
  • Supply voltage : 100 - 120V
  • Amperage : 5A
• Product dimensions
  • Depth : 21 3/4"
  • Height : 16 1/8"
  • Width : 23 9/16"
• Safety and compliance
  • ADA compliant : true
• Warranty
  • Parts and labor : Limited 2 years
• Wash Program Modifiers
  • Extra Dry : true
  • Wash modifiers : 3
  • Quick : true
  • Sanitize : true
• Wash programs
  • Delicate : true
  • Medium : true
  • Rinse : true
  • Wash programs : 6
  • Eco : true
  • Fast : true
  • Heavy : true
• Water connection
  • Inlet water temperature : Max 140°F
  • Supplied hose to suit 3/8" (9mm) male compression fitting : true
  • Water supply : 3/8" to suit Male Compression Fitting
  • Water pressure : 30kPa - 1000 kPa

Description

24 Inch Fully Integrated Panel Ready Single DishDrawerâ„¢ Dishwasher

7 place setting capacity, ideal for smaller households or apartments

9 wash programs to handle a variety of dishwashing needs

Operates quietly with a 44 dBa noise level for a peaceful environment

Sanitize option ensures enhanced cleaning for germ-free dishes

Knock to Pause feature allows easy pausing of the cycle with a simple tap

Key Lock for safety, preventing accidental changes to settings

Eco Option helps save water and energy for an environmentally friendly wash

Energy Star certified for efficient power usage

ADA compliant, ensuring accessibility for all users

Panel-ready design for seamless integration into your kitchen décor

Features

• Slide your DishDrawer™ Dishwasher into an existing kitchen space or integrate into kitchen cabinetry, for a seamless look whilst delivering superior dish care.
• DishDrawer™ Dishwashers are as easy to open and close as kitchen drawers and can be conveniently positioned at bench height for ease of loading and minimal bending. Flexible racking allows you to make adjustments to fit in a variety of dishes.
• The Quick wash modifier delivers a faster wash while maintaining performance. The Sanitise option provides extra protection killing 99.9% of bacteria in the final rinse. The Extra Dry setting is perfect for plastic dishes.
• Instead of needing a remote control, these DishDrawer™ Dishwashers have a knock to pause function. A knock on the front panel will pause the dishwasher which can be re-started again by using the start/play button.
• Running at a very low decibel rate, these DishDrawer™ Dishwashers do their job without making a fuss. The combination of intelligent technology and simple mechanics means greater reliability and excellent wash performance.
