Specifications

• Accessories (included)
  • Cutlery basket : true
  • Kickstrip : true
  • Knife clip and multipurpose clip : true
• Accessories (sold separately)
  • Handle kit Contemporary round, aluminium : AHS-OBDD-60S
  • Handle kit Contemporary square fine, aluminium : AHD5-OBDD-60SX
  • Handle kit Contemporary square fine, black : AHD5-OBDD-60SB
  • Handle kit Contemporary square, aluminium : AHD3-OBDD-60S
  • Door panel stainless steel : ADDD24DTPX
  • Handle kit Professional round flush : AHP3-DWDD-SX
  • Handle kit Professional round flush, Brass off-stands : AHP3DDDW24BA
  • Handle kit Professional round flush, Dark Copper off-stands : AHP3DDDW24DC
  • Handle kit Classic : AHCL-DDDW-24X
• Capacity and loading
  • Accommodates round plates up to : 12.25" (top) 11" (bottom)
  • Pitch adjustable tines : true
  • Adjustable height, foldable cupracks : true
  • Fold down tines : true
  • Place settings : 14
• Consumption
  • Energy usage : 263kWh/year
  • Water usage (per wash cycle) : 3.28 gal running both tubs
• Controls
  • Electronic fault/Diagnostic indicator : true
  • Knock to pause : true
  • Rinse aid indicator light : true
  • Keylock : true
  • End of cycle beeps : true
  • Energy saving delay start option of up to 12 hours : true
  • Internal wash selector : true
  • Smart Appliance : true
• Features
  • Quiet operation : true
  • SmartDrive™ technology : true
  • Fan assisted drying : true
  • Flood protection : true
  • Flow through detergent dispenser : true
• Performance
  • Noise on standard cycle top drawer : 43dBA
• Power requirements
  • Amperage : 10A
  • Rated current : 15A
  • Supply frequency : 60Hz
  • Supply voltage : 100 - 120V
  • Electric circuit : 3 wire
• Product dimensions
  • Width : 23 9/16"
  • Depth : 21 3/4"
  • Height : 34 - 36 3/8"
• Warranty
  • Parts and labor : Limited 2 years
• Wash Program Modifiers
  • Quick : true
  • Sanitize : true
  • Wash modifiers : 3
  • Extra Dry : true
• Wash programs
  • Delicate : true
  • Rinse : true
  • Eco : true
  • Fast : true
  • Heavy : true
  • Wash programs : 6
  • Medium : true
• Water connection
  • Supplied hose to suit 3/8" (9mm) male compression fitting : true
  • Water supply : 3/8" to suit Male Compression Fitting
  • Inlet water temperature : max 140°F
  • Water pressure : 30kPa - 1000 kPa

Description

14 Place Settings: Ample space to accommodate large loads and a variety of dish types.

6 Wash Programs: Multiple options to suit different washing needs and requirements.

Knock to Pause: Conveniently pause the cycle with a simple knock on the unit.

Sanitize Option: Ensures your dishes are thoroughly sanitized for hygienic cleaning.

44 dBA Sound Level: Operates quietly, making it ideal for homes or apartments where noise levels matter.

Childlock: Provides safety by preventing accidental interruptions or cycle changes.

ENERGY STAR® Certified: Energy-efficient operation, helping to reduce energy consumption and utility costs.

Features

• Slide your DishDrawer™ Dishwasher into an existing kitchen space or integrate into kitchen cabinetry, for a seamless look whilst delivering superior dish care.
• DishDrawer™ Dishwashers are as easy to open and close as kitchen drawers and can be conveniently positioned at bench height for ease of loading and minimal bending. Flexible racking allows you to make adjustments to fit in a variety of dishes.
• With the ability to use both drawers independently and select different wash programs the DishDrawer™ Dishwasher can wash everything from fine glass and crystal to heavily soiled pots and pans.
• Each drawer holds a true half load for guilt-free small washes and fast turnaround of your dishes. Both drawers operate independently so different wash cycles can run simultaneously to accommodate a variety of loads.
• The Quick wash modifier delivers a faster wash while maintaining performance. The Sanitize option provides extra protection killing 99.9% of bacteria in the final rinse. The Extra Dry setting is perfect for plastic dishes.
• Instead of needing a remote control, these DishDrawer™ Dishwashers have a knock to pause function. A knock on the front panel will pause the dishwasher which can be re-started again by using the start/play button.
• Running at a very low decibel rating, these DishDrawer™ dishwashers do their job without making a fuss. The combination of intelligent technology and simple mechanics means greater reliability and excellent wash performance.
