Specifications

• Dimensions: 30" W x 19 11/16" D x Min: 20 3/8" - Max: 36 5/8" H
• Blower Type (internal): 400 CFM (3-Speed)
• Noise (sones): 5.9 Sones
• Finish: Stainless Steel
• Controls: Electronic Touch Controls with Adjustable Color Backlight
• Illumination: 2 LED, 2.1 W, 3000 K
• Grease Filter: Dishwasher-Safe, Anodized Aluminum Mesh Filter
• Duct Transition: 6" Round with Back Draft Damper (top only)
• Installation Type: Ducted or Recirculating (Kit sold separately)
• Telescopic Chimney: Can reach ceiling heights of min 6'9", max 8'8" (ducted out) & min 7'0", max 9'0" (recirculating)
• Electrical: 120 V, 60 Hz, 301 W

Description

• 3-Speed/400 CFM Blower: Efficient ventilation with three adjustable fan speeds, offering powerful airflow of up to 400 CFM to effectively eliminate smoke, grease, and odors.
• Backlight Color Touch Controls: Modern, easy-to-use touch controls with backlight, allowing for smooth operation even in dim lighting conditions.
• LED Lighting: Energy-efficient LED lighting to brightly illuminate your cooking area, enhancing visibility while saving on electricity costs.
• Dishwasher-Safe Mesh Filter: High-performance mesh filter captures grease and particles, and can be easily cleaned in the dishwasher for hassle-free maintenance.
• 30 Inch Size: Perfectly designed to fit a 30-inch cooking range, providing excellent coverage and functionality for most kitchens.
• Stylish and Functional: A sleek, modern design that adds both elegance and efficiency to your kitchen space.

Features

• • 3-Speed/400 CFM Blower: Provides sufficient ventilating power for most kitchens, ensuring effective smoke and odor removal while maintaining a quiet environment.
  • Backlight Color Touch Controls: Elegant white, green, blue, or red backlight colors illuminate the touch controls, allowing for easy management of fan speeds and lighting settings.
  • LED Lighting: Energy-efficient LED lights offer long-lasting illumination (up to 20,000 hours), helping you save on electricity while brightly lighting your cooking surface.
  • Dishwasher-Safe Mesh Filter: Elica's premium triple-layered anodized aluminum mesh filter is highly effective at capturing grease, resisting stains, and is durable enough for frequent dishwasher cleaning.
  • CFM Reduction System: An exclusive feature that allows the blower's CFM to be reduced to meet local code requirements, offering flexibility in installation and performance.
