Specifications

• Blower Type (internal): 600 CFM (4-speed)
• Noise (sones): 6.8 Sones
• Finish: Stainless Steel
• Controls: Multiple backlight color touch controls for enhanced aesthetic and functionality
• Illumination: 2 LED lights, 2.1 W, 3000 K for efficient task lighting
• Grease Filter: 2 dishwasher-safe, stainless steel baffle slot filters for easy maintenance
• Duct Transition: 6" round with backdraft damper (top only)
• Installation Type: Ducted or recirculating (kit sold separately)
• Telescopic Chimney: Adjustable to fit ceiling heights from 7'5" to 9'1" (ducted) or 7'5" to 9'6" (recirculating)

Electrical Specifications:

• Volts: 120 V
• Frequency: 60 Hz
• Watts: 265 W

Dimensions:

• Width: 36"
• Depth: 19 11/16"
• Height: 28 3/4" (min) - 41 1/8" (max)

Description

• 4-Speed/600 CFM Blower: Powerful motor offering four fan speeds to efficiently eliminate smoke, odors, and grease from your kitchen.
• Multiple Backlight Color Touch Controls: Stylish and easy-to-use touch controls with customizable backlight colors for added convenience and a modern touch.
• LED Lighting: Energy-efficient LED lights that provide bright illumination for your cooking area.
• Dishwasher-Safe Baffle Filters: Durable baffle filters that are easy to clean and maintain, helping to capture grease and cooking residue.
• CFM Reduction: Adjust the fan’s airflow for optimized performance and energy efficiency based on your cooking needs.
• Hush System: Quiet operation, reducing noise levels while maintaining powerful performance, ensuring a peaceful kitchen environment.
• 36-Inch Width: Ideal for most kitchen spaces, providing ample coverage for your cooktop.

Features

• • 4-Speed/600 CFM Blower: Provides powerful ventilation to handle all your cooking needs, quickly and efficiently eliminating smoke and cooking odors from the air.
  • Multiple Backlight Color Touch Controls: Customize the touch controls with elegant color options such as white, green, blue, or red. Adjust brightness and control fan speed and LED lighting for enhanced functionality and aesthetics.
  • LED Light: Energy-efficient LED lighting with an expected lifespan of over 20,000 hours, designed to last the entire life of the hood.
  • Stainless Steel Baffle Slot Filters: High-efficiency baffle-shaped stainless steel filters that capture grease while allowing air to flow through. The durable design ensures silent operation and excellent capture efficiency at all blower speeds.
  • CFM Reduction System: The CFM Reduction System (CRS) allows you to adjust the blower’s CFM to meet local code requirements, providing added flexibility for different installation environments.
