Specifications

• General
  • Cleaning: Self Clean
  • Range Fuel: Gas
  • Oven Fuel: Gas
  • Oven Category: Manual Clean
  • Utility Type: All Gas
  • Shipping Weight: 600 lbs
  • Electrical Rating: 120 VAC, 60 Hz
  • Product Dimensions: 47-7/8 W x 36 H x 28-3/8 D
  • Max Current: 12.8 AMP
  • Circuit Breaker Size: 15 AMP
  • Gas Connections: 1/2 NPT Male
  • Max. allowable input pressure: 1/2 psi
  • Natural Gas: 7 WC input pressure: 5 WC pressure regulator provided
  • Liquid Propane: 11 WC input pressure: 10 WC pressure regulator provided
  • Primary Oven Dimensions: 27 W x 15 H x 21
  • Primary Oven Volume: 4.9 cubic feet
  • Configuration: 6 Sealed Burners and 12 Thermo-Griddle Size: 48
  • Burner Type: Sealed
  • Oven Control Type: Dial
  • Cutout Dimension: 48-1/8 W X 24 D (std)
  • Product Weight: 560 lbs
  • Shipping Dimensions: 52 W x 48 H x 34 D
  • Wiring Type: 120 VAC, 3 Prong with dedicated ground
  • Companion Oven Dimensions: 12 W X 14 H x 21 D
  • Companion Oven Volume: 2.0 cubic feet

Description

The beautiful design of Precision ranges will complete your dream kitchen. Featuring the categories most powerful sealed burners, an integrated rotisserie, and a host of unique features, all built in the USA with hand crafted seamless construction. Precision Self Clean gas ranges assemble the wish lists of home chefs into a single product.

Features

• BAKE (both ovens)
• BROIL
• CONVECTION BAKE (primary and 60? companion ovens)
• CONVECTION BROIL
• SELF-CLEAN (primary ovens)
• Extra Large Oven fits Full Size Commercial Cookie Sheets (primary ovens)
• Infrared Broiler Under Glass (primary ovens)
• Integrated Moto-Rotis Rotisserie system (primary ovens)
• 5 rack positions
• Flex-Rolloven racks for smooth operation
• Height adjustable front levelers
• Height adjustable rear casters for easy installation
• Removable Door with Heavy Duty Hinges
• Front located Gas Shut-Off Valve and Electrical Disconnect.19,000 BTU Power-Flo Sealed burners turn down to a true simmer
• 18,000 BTU Thermo-Griddle plate
• Stay-Cool die cast, chrome plated metal knobs
• Auto-ignition/re-ignition on all burners
• Smooth-top continuous cast iron grates with easy to clean matte porcelain finish
• Integrated reversible wok grate
• Stainless Steel spill pan for long life
• 3" Integrated Island trim
• Cabernet Red trim available as an accessory.Self-Cleaning Convection oven
• 4.9 cu. ft. oven cavity - 27" W X 14" H x 21" D
• BAKE
• CONVECTION BAKE
• BROIL CONVECTION BROIL
• SELF-CLEAN
• 30,000 BTU oven burner for uniform baking
• 18,000 BTU Infrared Broil Burner Under Glass with Inconel Mesh construction
• Moto-Rotis integrated Rotisserie System
• Titanium speck porcelain oven interior
• 5 Rack Positions w/ 3 Heavy Duty Racks provided
• Broil pan provided
• 1-1/4" diameter professional-style handle
• Heavy-duty oven door hinges
• Extra large viewing window
• Bright 40W oven lights.Manual Clean
• Baking oven
• Large 2.0 cu. ft. oven cavity - 12" W X 14" H x 21" D
• BAKE
• 15,000 BTU oven burner for uniform baking
• Titanium speck porcelain oven interior
• 5 Rack Positions w/ 3 Heavy Duty Racks provided
• 1-1/4" diameter professional-style handle
• Heavy-duty oven door hinges
• Extra large viewing window
• Bright 40W oven lights
