Specifications

• ACCESSORIES
  • Optional Side Filler Panel Kit : JX36BDS
  • Recirculating Charcoal Filter Kit : Included, WB02X35607
  • Optional Kits : 15" Bump Out Kit - JXBUMPBB, CXOTRHKPMBT Brushed Black, CXOTRHKPMBZ Brushed Bronze, CXOTRHKPMCG Brushed Brass, CXOTRHKPMCU Brushed Copper, CXOTRHKPMFB Flat Black, CXOTRHKPMSS Brushed Stainless
• APPEARANCE
  • Door Swing : Hinges on Left
  • Handle Color : Brushed Stainless
  • Door Color : Black Stainless
  • Case Color : Graphite Gray
  • Color Appearance : Matte Black
• CAPACITY
  • Vent CFM : 300
  • Exhaust Capacity : 300 ft3/min
  • Total Capacity (cubic feet) : 1.7 cu ft
• ECONOMICAL / QUIET
  • Venting Type : Externally Vented
• FEATURES
  • Display Type : LED
  • Microwave Sensor Cooking Controls : Beverage, Cook (5 Foods), Popcorn, Reheat, Steam Cook
  • Electronic Digital Display with Clock : Yes (LED)
  • Display Screen Size (Diagonal Length) : 3.13
  • Cooking Modes : Air Fry, Convection Bake, Convection Roast, Fast Cook, Microwave
  • Style : Over-The-Range
  • Oven Interior : Stainless Steel
  • Rack Type : 1 Round Rack, 1 Square Rack, 2 Fixed Positions
  • Microwave Watts (IEC-705) : 950 W
  • Turntable On / Off : Yes
  • Power Levels : 10
  • Cooktop Lighting : Auto Night Light, High/Low/Off, LED
  • Control Features : Add 30 Seconds, Air Fry, Cancel/Off, Chef Connect On/Off, Cook Time, Defrost: Weight/Time, Display On/Off, Mute On/Off, My Cycle, Power Level, Settings, Start/Pause, Steam Clean, Surface Light, Sync Auto Off; Surface Light Sync; Vent Fan Sync, Timer On/Off, Turntable On/Off, Vent Fan
  • Cooking Technology : Microwave/Convection/Air Fry
  • Convection Cooking Controls : Bake, Fast Cook, Roast
  • Display On/Off : Yes
  • Microwave Oven Interior : Stainless Steel
  • Exhaust Fan : 3-Speed, 300-CFM, Hi/Med/Low/Off
  • Turntable Size : 13.6 in
  • Interior Oven Light : Halogen
  • Control Type : Dial, Glass Touch
  • Product Type : Over-the-range Microwave
  • Turntable : Glass
• FILTER
  • App Filter - Wattage : 1000 to 1099
  • App Filter - Cabinet Width : Cooking 30 in. (Standard)
  • App Filter - Product Type : Microwave Over-the-Range
  • App Filter - Capacity : Microwave Medium (1.5 - 1.8 cu. ft.)
  • App Filter - Voltage : 120V
  • App Filter - Convection : Yes
  • App Filter - Cooking Modes : Microwave Warm/Proof
  • App Filter - Control Type : Electronic touchpad
  • App Filter - Venting Type : External
  • App Filter - Cooking Technology : Microwave with Convection
• POWER / RATINGS
  • Input Volts/Hertz : 120/60
  • Electrical Input - 120V Amperage : 14.5
  • Electrical Input - 120V Watts : 1700
• WARRANTY
  • Parts Warranty : Limited 1-year entire appliance, Limited 5-year magnetron tube
  • Warranty Notes : See written warranty for full details
  • Labor Warranty : Limited 1-year entire appliance
• WEIGHTS & DIMENSIONS
  • Approximate Shipping Weight : 95 lb
  • Cabinet Width : 30 in
  • Height (Front) : 16 5/16 in
  • Overall Width : 29.875 in
  • Net Weight : 85 lb
  • Overall Height : 16.3125 in
  • Exterior Height (Rear) : 16.5 in
  • Cavity (W x H x D) : 21-5/8 x 9-3/4 x 14-1/8
  • Overall Depth : 17.9375 in

Description

The 30 Inch Over-the-Range Convection Microwave Oven offers a variety of convenient features for your kitchen:

• 1.7 cu. ft. Capacity: Spacious interior to accommodate larger dishes and cookware.
• Sensor Cooking: Automatically adjusts cooking time and power for optimal results.
• Steam Cook: Prepares healthier meals by steaming food to preserve nutrients.
• Fast Cook: Saves time with quicker cooking cycles for your convenience.
• My Cycle: Customizable one-touch cooking options for personalized meals.
• Steam Clean: Easily maintain a clean interior with a steam-cleaning function.
• Chef Connect: Syncs with compatible appliances to enhance kitchen efficiency.
• 300 CFM Exhaust Fan: Provides powerful ventilation with a 3-speed exhaust system to eliminate smoke, odors, and steam.
• LED Cooktop Lighting: Bright, energy-efficient lighting to illuminate your cooktop.
• Removable Oven Rack: Offers flexible cooking options and easy cleaning.
• 950 Cooking Watts: Powerful performance for efficient cooking and reheating.
• UL Listed: Meets safety standards for peace of mind.

This over-the-range convection microwave is designed for convenience, versatility, and efficiency in your kitchen.

Features

• Air Fry : Make your favorite "fried" foods healthy, thanks to a mode that crisps without using oil for frying
• Create a streamlined cooking experience : Simplify your cooking steps by using Chef Connect to automatically activate vents and surface lights when a range element is turned on, as well as sync your microwave and range clocks
• A simple and smart addition to your culinary repertoire : Fresh vegetables and rice are perfectly prepared with a steam cook button that simplifies the entire process
• Say goodbye to guesswork : Enjoy consistently delicious results with sensor cooking controls that automatically adjust the time and power
• Delicious results in no time at all : Enjoy oven-quality results in mere minutes with a fast cook setting that combines convection and microwave cooking technology
• A microwave that’s as versatile as you are : Achieve crisp, golden brown results with a convection cooking setting and a special rack that allows air to circulate around foods for even heat distribution
• Brighten up the room : Illuminate the entire cooking surface with crisp, clear LED cooktop lighting that can also save on energy costs
• Sparkling clean with just a wipe : Focus on the food and forget the mess knowing that the stainless steel interior with steam clean lets you swiftly wipe away spills and splatters
• Like a breath of fresh air : Keep your kitchen ready for guests with a three-speed, 300-CFM venting system that removes smoke, grease, odors and moisture
• Cook more at once : Prepare plenty of food with full-width removable oven rack that allow for multi-level cooking at the same time
• Cook your way with just one touch of a button : Enjoy the convenience of one-touch cooking with My Cycle, a custom cycle that remembers the exact time and temperature settings of your favorite foods
• More room for more food : Entertaining unexpected guests is easy with the 1.7 cu. ft. capacity that helps prepare a large amount of food quickly
• Create a look that matches your personal style : Select any combination of premium finishes and hardware options to create a stunning look customized to any owner’s taste
