Specifications

• ACCESSORIES
  • Air Fry Basket : Optional- JXAFTRAY1VSS
  • Optional Kits : CXFCGHKPMBT Brushed Black, CXFCGHKPMBZ Brushed Bronze, CXFCGHKPMCG Brushed Brass, CXFCGHKPMCU Brushed Copper, CXFCGHKPMFB Flat Black, CXFCGHKPMSS Brushed Stainless
  • LP Conversion Kit : Included
  • Trim Kit : JXFILLR1SS, Optional
  • Grates : Included Center Grate
• APPEARANCE
  • Handle Design : Café
  • Handle : Consumer Removable, Customizable, Professional Style
  • Installation : Flush Appearance, Free-standing cut-out, Power Cord Not Included
  • Control Knobs : Stainless Steel Appearance, Weighted
  • Color Appearance : Stainless Steel
  • Cooktop Burner Grate Color : Matte Black
  • Oven Door Features : Big Clear View Oven Window, Stainless Steel Frameless Oven Door
  • Handle Color : Brushed Stainless
• CAPACITY
  • Total Capacity (cubic feet) : 5.7 cu ft
• FEATURES
  • Ignition System : Electronic w/Auto Reignition
  • Oven Rack Features : 3 Self-Clean Oven Racks
  • Oven Control Features : Audible Preheat Signal, Auto Oven Shut-Off, Auto Self Clean, Automatic Oven Timer (Time Bake), Certified Sabbath Mode, Chef Connect, Control Lock Capability, Delay Bake Option (Time Bake), Delay Clean Option, Digipad Numeric Entry, Electronic Clock and Timer, Front Controls, In-Oven Broiling, Self-Clean Cool Down Time Display, Temperature Probe
  • Product Type : Slide-In Single Oven
  • Cooktop Type : Standard Grates
  • Cooktop Burner Grate Material : Cast-Iron
  • WiFi Connect : Built-In
  • Control Location : Front controls
  • Burner - Right Rear : 12,000 BTU
  • Style : Commercial
  • Dishwasher Safe Knobs : Yes
  • Burner - Left Front : 21,000 BTU Tri-ring Burner
  • Sabbath Mode : Yes
  • Leveling System : 4 Leveling Legs
  • Cooking Technology : Convection
  • Oven Features : 8-Pass Broil Element
  • Oven Cooking Modes : Baked Goods, Convection Bake, Convection Roast, Frozen Pizza Multi Rack, Frozen Pizza Single Rack (No Preheat), Frozen Snacks Multi Rack, Frozen Snacks Single Rack (No Preheat), No Preheat Air Fry, Proof, Turkey Mode, Warming
  • Oven Interior : 1 Incandescent Light, Black, Hidden Bake
  • Cooktop Burner Grate Features : Heavy-Cast Edge-to-Edge Grates
  • Control Type : Backlit, Glass Touch
  • Cooktop Burner Type : Sealed
  • Grill : Integrated Cast Iron, JXCGRILL1, Optional
  • Drawer Type : Warming Drawer; 3 Settings (High, Medium, Low)
  • Cooking System : True European Precise Air Reversing
  • Burner - Left Rear : 5,000 BTU Precise Simmer
  • Griddle : Included, Integrated Cast Iron
  • Burner - Center : 9,500 BTU Front / 9,500 BTU Rear
  • Valves (Degree of Turn) : 270
  • Self-Clean Oven Door Lock : Automatic
  • Cleaning Time : Variable with Delay Clean Option
  • Oven Cleaning Type : Self-Clean with Steam Clean Option
  • Connected Capabilities : Amazon Alexa, DiGiorno, Fresco, IFTTT, Innit, Sonos, The Google Assistant
  • Fuel Type : 240V Electric and Natural Gas
  • Configuration : Range with Warming Drawer
  • OU Certified : No
  • Burner - Right Front : 15,000 BTU
  • Cooktop Surface : Deep Recessed, Stainless Steel
  • Oven Rack Positions (Single or Upper/Lower) : 6
• FILTER
  • App Filter - Cooking Technology : Convection
  • App Filter - Tri-Ring Burner : Yes
  • App Filter - Drawer Type : Warming Drawer
  • App Filter - Product Type : Ranges Slide-In Single Oven
  • App Filter - Cabinet Width : Cooking 30 in. (Standard)
  • App Filter - Cooktop Type : Standard Grates
  • App Filter - Control Type : Electronic touchpad
  • App Filter - Fuel Type : Dual Fuel
  • App Filter - Convection : Yes
  • App Filter - Cleaning Type : Self-Clean
• POWER / RATINGS
  • Amp Rating at 208V : 30
  • Amp Rating at 240V : 30
  • Convection Wattage : 2500W
  • Power Connection : Power Cord - Not Included
  • Top Burner BTU Rating - Nat. Gas (000's BTU's) : (1) 21.0 Tri-Ring; (1) 15.0; (1) 12.0; (2) 9.5; (1) 5.0
  • Volts/Hertz/Amps : 208/240V; 60Hz; 30A
  • Top Burner BTU Rating - LP (000's BTU's) : (1) 18.0 Tri-Ring; (1) 15.0; (1) 12.0; (2) 9.5; (1) 5.0;
  • Bake/Broil Wattage - Main Oven : 2850/4000W
• WARRANTY
  • Labor Warranty : Limited 1-year entire appliance
  • Warranty Notes : See written warranty for full details
  • Parts Warranty : Limited 1-year entire appliance
• WEIGHTS & DIMENSIONS
  • Net Weight : 224 lb
  • Cabinet Width : 30 in
  • Approximate Shipping Weight : 244 lb
  • Overall Width : 29.875 in
  • Depth Without Handle : 26.875 in
  • Cabinet Opening : 30 in
  • Oven Interior Dimensions (W x H x D) (in.) : 24 x 19-7/8 x 20-5/8
  • Overall Depth : 29.5 in
  • Depth with Door Open : 47.5 in
  • Height to Cooking Surface (in.) : 36 1/4 +/- 1/4
  • Overall Height : 37.375 in
  • Height to Top of Rear Vent Trim : 37.375 in

Description

• Product Name: 30-Inch Slide-In Dual Fuel Smart Range
• Finish: Stainless Steel
• Cooktop:
  • Six sealed burners, including a powerful 21K triple ring burner for versatile cooking options.
• Oven Features:
  • 5.7 cu. ft. oven capacity, ideal for large meals and baking.
  • Warming drawer to keep food at the perfect temperature.
• Convenience Features:
  • Continuous grates for smooth movement of cookware.
  • Self-clean and steam clean options for easy oven maintenance.
• Smart Features:
  • Enhanced Shabbos Mode to meet specific observance needs.
• Certifications:
  • ADA compliant, ensuring accessibility and reliability.

This Stainless Steel range combines advanced cooking features with a sleek design, making it a versatile and efficient addition to any kitchen.

Features

• Built-In WiFi, Powered by SmartHQ App : Manage all aspects of your kitchen with the help of the SmartHQ™ App or your voice assistant (Select features require WiFi Connection) See details
• Personalized Features + Upgrades : Usher in the latest features by downloading cooking upgrades right to your oven, putting Air Fry and more in your repertoire
• No-Preheat Air Fry : Cook healthier, crispier versions of your favorite foods in less time, thanks to an air fryer right in your oven that doesn’t require preheating, a basket or a special tray (WiFi Enabled)
• Expansive six-burner cooktop helps you entertain with ease : Entertaining for large groups is easy with the industry's first six burner, edge-to-edge cooktop that can accommodate cookware of all sizes and a cast-iron integrated griddle that provides enough room to perfectly flip crab cakes, arepas and other crowd favorites
• An attractive appearance at all times : Every detail of your kitchen is designed to delight, thanks to a sleek backlit glass touch control panel that visually disappears when not in use and wakes up when prompted
• Share favorite creations with your favorite people : Create an unforgettable dinner, using a 21K triple ring burner to do everything from searing scallops to simmering a lemon caper white wine sauce and a 15K power boil burner to boil water quickly for al dente angel hair pasta
• Treat yourself to the best of both worlds : Get the precision you need to pull off a multi-course dinner party with Dual Fuel, which boasts a gas-powered cooktop for precise heat control and electric True Convection with Precise Air in the oven for even baking results
• Never-scrub, smooth-glide racks : Easily remove heavy dishes with a roller rack that is specially designed to glide smoothly and stay in the oven during the self-clean cycle, so you never have to handle cumbersome racks again
• Create a look that matches your personal style : Select any combination of premium finishes and hardware options to create a stunning look customized to any owner’s taste
• Prepare foods to perfect doneness : Get roasts and meats just right with a temperature probe that lets you monitor progress without opening the oven door
• Allow your appliances to interact with one another : Create a chef-like experience with Chef Connect, which can synchronize your appliance clocks and surface lights and vent when a range burner is in use, and even your microwave and range clocks
• Worry about guests, not the cooking : Confidently cook over a steady flame with the electronic ignition’s automatic reignition feature that instantly revives any accidentally extinguished flames
• Choose the range you want with total confidence : When you’re updating your kitchen, attention to detail is a priority. That’s why Café 30” slide-in ranges are guaranteed for an exact fit or Café Appliances will pay up to $300 toward modifications.
