Specifications

• Max Blower Airflow: 450 CFM for powerful ventilation during cooking.
• Finish: 430 Stainless Steel #4 Brushed for a sleek and modern appearance.
• Wall Mount: Yes, designed for easy installation on the wall for space-saving functionality.
• Telescopic Flue: Adjustable to accommodate ceiling heights from 8-ft. to 9-ft., with optional extensions available.
• Convertible to Non-Ducted Operation: Yes, can be converted for ductless installation with the ARKBWP Non-Duct Kit (sold separately).
• Blower Type: Single, centrifugal blower for efficient airflow and performance.
• Cord-Connected: Yes, providing easy electrical installation.
• Control Type: Soft-Touch controls for easy operation.
• Controls: Includes blower speeds (High, Medium, Low), light on/off, and a 5-minute delay feature.
• Lighting: Equipped with 2 x 5.5W LED modules (included) for bright, energy-efficient lighting.
• Grease Filters: Hybrid baffle filters that are dishwasher-safe with a quick-release latch for easy maintenance.
• Blower Specifications:
  • Duct Orientation: Round - Vertical
  • Size: 6 In.
  • Damper: Included for optimal airflow control.
  • Sones: Normal: 3.0, Medium: 4.0

Description

• 30-Inch Convertible Wall-Mount Design: Modern, low-profile chimney range hood perfect for a sleek kitchen look.
• 3-Speed 450 CFM Blower: Offers powerful ventilation to remove cooking odors, smoke, and grease efficiently.
• Dishwasher-Safe Hybrid Baffle Filter: Easy to maintain and clean, ensuring optimal performance over time.
• LED Cooktop Lighting: Provides clear, bright illumination for your cooking surface, enhancing visibility.
• Convertible Installation: Can be used as ducted or ductless based on your kitchen setup and preferences.
• Stainless Steel Construction: Durable and easy-to-clean surface that complements modern kitchen designs.

Features

• • Installation Requirements: Install the hood so that the bottom is 24" from the cooking surface. Mounting height may vary depending on ceiling height.
  • Convertible Ducted/Non-Ducted Installation: Optional non-duct kit with a recirculating air filter available for indoor exhaust recirculation.
  • Pyramidal Chimney: Sleek pyramidal design adds an elegant touch to any kitchen.
  • Telescopic Flue: Flue extensions can accommodate 8ft - 9ft ceilings, with optional extensions available for ceilings up to 10ft.
  • 600 Lumen LED: Powerful 5.5W LED lighting ensures bright, long-lasting illumination with a 25,000-hour service life.
  • Capacitive Touch Controls: Easy-to-clean, tap-touch three-speed controls for smooth operation.
  • Dishwasher Safe Filters: Deluxe filters with a quick-release latch for easy removal and replacement, dishwasher-safe for convenience.
  • Stainless Steel Construction: Offers a sleek, sophisticated design that is easy to clean and perfect for any modern kitchen.
