Specifications

• General
  • Third Rack: VarioDrawer Pro
  • Internal article number: SHV9PCM3N
  • Construction type: Built-in
  • Type of control: push-button, touch buttons
  • Hidden heating element: Yes
  • Current (A): 12
  • Volts (V): 120
  • Length outlet hose (cm): 200
  • Accessories Parts: no
  • Installation type: Full-integrated
  • Depth with open door 90 degree (mm): 1231
  • Total annual energy consumption (kWh): 240
  • Depth of the packed product (mm): 745
  • Maximum height for installation (mm): 890
  • Minimum width for installation (mm): 610
  • Maximum width for installation (mm): 618
  • Depth for installation (mm): 610
  • Energy Star® qualified: Yes
  • Net weight (kg): 41.9
  • Five-level wash: Yes
  • Gross weight (kg): 48.1
  • Reference programme: Eco
  • Home Connect Connectivity: Wi-Fi
  • Home Connect: Remote Monitoring and Control
  • Number of different wash temperatures: 6
  • Enter the minimum temperature for wash (°C): 50
  • Enter the maximum temperature for wash (°C): 71
  • Frequency (Hz): 60
  • Plug type: Nema5-15P
  • Required cutout size (HxWxD) : 33 7/8'' x 24'' x 24''
  • Drying system: Condensation Dry , Zeolite
  • Start delay options: Continuous
  • Status indicator: End of program audible, Time remaining indic. internal
  • EAN code: 4242005277056
  • Column installation: Yes
  • Type of control: Electronic
  • ChildLock: No
  • Removable work top: No
  • Door decor panel: Not possible
  • Tub material: Stainless steel
  • Watts (W): 1440
  • Power cord length (cm): 170.0
  • Power Cord Length: 67''
  • Adjustable plinth: No
  • Height of removable worktop (mm): 0
  • Maximum adjustability feet (mm): 30
  • Product group: Dishwasher
  • Brand: Bosch
  • SKU: SHV9PCM3N
  • Energy Efficiency Class: Tier 1
  • Height of the packed product (mm): 908
  • Width of the packed product (mm): 660
  • Number of place settings: 16
  • Silence level (dBA): 39
  • Length outlet hose : 78 3/4''
  • Water softener: Yes
  • Maximum accepted water hardness: [50°DH]
  • Number of wash cycles: 6
  • Maximum temperature for water intake (°C): 60
  • Stop delay or a start delay option: Start
  • Start delay time max (h): 24
  • Single basket washing: No possibility
  • Digital countdown indicator: Yes
  • End of cycle sound: End of program audible
  • Salt light indicator: Yes
  • Rinse aid light indicator: Yes
  • Minimum height for installation (mm): 860
  • List of programmes: 1 Hour, Auto, Favorite, Intensive, Normal
  • Number of options: 5
  • Cycle Options: HygienePlus, Remote Start, Zeo Dry, ZoneControl™ Back, ZoneControl™ Custom, ZoneControl™ Front
  • Automatic programmes: Yes
  • Safety device: Single Water Protection 24h
  • Software update: Yes
  • UPC code: 825225965008
  • Total annual water consumption : 688
  • Water Usage per Cycle: 3.2
  • Interior light: Yes
  • Optional accessories: SGZ1010UC, SMZ1008UC, SMZ4000UC, SMZ5000, SMZ5002UC
  • Net weight : 92.000
  • Adjustable upper rack: Rackmatic 3-stage
  • Basket with handle: Bottom basket, Top basket

Description

16 Place Setting Capacity: Offers ample space to accommodate large loads, ideal for families or those who frequently host gatherings.

9 Wash Cycles: Includes a variety of cycles to meet all your washing needs, from heavy-duty to delicate care.

Flexible 3rd Rack: Provides extra space for utensils, small items, or additional dishes, making it more versatile for different load types.

39 dBA: Exceptionally quiet operation, ensuring your kitchen remains peaceful even when the dishwasher is running.

PrecisionWash® with PowerControl™: Features advanced technology that uses intelligent sensors and adjustable washing power to ensure a thorough clean on every cycle.

Panel Ready Design: Integrates seamlessly with your kitchen cabinets, offering a sleek, customized look that matches your décor.

Features

• Near Silent Operation at 39 dBA: creating a dishwasher so quiet, you can't always tell it is running -- this is what makes Bosch the quietest dishwasher brand in the U.S.*
• Home Connect®: access additional wash cycles to choose the right one for your needs with Smart Cycle.
• RackMatic®: adjusts the upper rack to 9 different positions, allowing for taller items like stemware or leaving room for pots and pans below.
• 10 years warranty: our promise against rust-through.
• CrystalDry™: transforms moisture into heat up to 176°F to give dishes, even plastics, the ultimate dry.
