Specifications

• General
  • Product name / series name: Freestand combination cooker
  • Optional accessories - primary cavity: HEZ9GR41UC, HEZ9GW23UC, HEZ9LLUC, HEZ9TK30UC, HEZ9YZ04UC, HEZ9YZ30UC, HEZ9ZZ30UC
  • SKU: HDS8055U
  • Internal article number: HDS8055U
  • EAN code: 4242005193264
  • Bake Element Wattages primary cavity : 1700
  • Type of control: Electronic
  • Product color: Stainless steel
  • Number of gas burners: 5
  • Number of electric cooking zones: 0
  • Number of electric elements: 0
  • Number of radiant elements: 0
  • Number of halogen elements: 0
  • Product group: Cooker
  • Number of induction elements: 0
  • Which kind of hobs can be controlled?: Mixed
  • Variable cooker height : 1 1/4"
  • Gas type: Natural gas 15 mbar (USA)
  • Gas connection rating (W): 14100
  • Current (A): 20
  • Volts (V): 240/208
  • Frequency (Hz): 60
  • Depth with open door 90 degree (mm): 1161
  • Product packaging dimensions (HxWxD) : 34 1/16" x 32 7/8" x 28"
  • Height of the packed product (mm): 865
  • Overall appliance dimensions (HxWxD) : 36" x 29 15/16" x 24 15/16"
  • Adjustable feet: Yes - all
  • Maximum adjustability feet (mm): 32
  • Net weight (kg): 93.5
  • Gross weight (kg): 104.4
  • Construction type: Freestanding
  • Type of control: Front, Rotary knob, sword knobs
  • Total number of cooktop burners: 5
  • Convection Element Wattages primary cavity : 2700
  • Plug type: No Plug
  • Cooking mode: 3rd Element Convection, Bake, Bottom heat, Convection Bake, Convection Broil, Convection Roast, Pizza, Proof, Special baking setting, Top heat
  • Number of cavities (2010/30/EC): 1
  • Power of the heating element: 1.5
  • Location of the heating element: front left
  • Power of 3rd heating element (kW): 2.9
  • Location of 3rd heating element: back left
  • Power of 5th heating element (kW): 1.5
  • Location of 5th heating element: back right
  • Type of 5th heating element: Gas
  • Required cutout size (HxWxD) : 30" width slide-in
  • Number of Double grates: 2
  • Plate on indicator: 0
  • Power of 5th burner : 5000
  • Type of safety device for gas: Electromagnetic for each burner
  • Brand: Bosch
  • Material Color - door: Stainless Steel
  • Type of heating element: Gas
  • Ignition system: Yes
  • Main on/off switch: No
  • Power of 6th burner : 10000
  • Safety device: Safety valve
  • Control panel information: LCD, On control knob, Printing on panel front
  • Settings backup: No
  • Sealed Burners: Yes
  • Optional accessories: HEZ9GR41UC, HEZ9GW23UC, HEZ9LLUC, HEZ9TK30UC, HEZ9YZ04UC, HEZ9YZ30UC, HEZ9ZZ30UC
  • Interior light: Yes
  • Location of 2nd heating element: center left
  • Type of 3rd heating element: Gas
  • Location of 4th heating element: middle back
  • UPC code: 825225960973
  • Net weight : 206.000
  • Power cord length (cm): 140.0
  • Door Material - primary cavity: Stainless steel
  • Width of the packed product (mm): 710
  • Depth of the packed product (mm): 835
  • Knob Material: Full metal
  • Power of 1st burner : 5000
  • Residual heat indicator: Without
  • Power on indicator: No
  • Location of 6th heating element: center right
  • Total BTU load: 48000
  • Power of 3rd burner : 10000
  • Type of lid: Without
  • Timer: No
  • Power of 6th burner : 18000
  • Automatic programmes: No
  • Motorized turn spit: No
  • Probe: No
  • Gross weight : 230.000
  • Number of interior lights: 1
  • Integrated Cleaning system: Catalytic partial
  • Shelves type: Shelf support rails

Description

30-inch freestanding dual fuel range combining the precision of gas cooking with the even heat of an electric oven

Five sealed burners for efficient cooking and easy cleanup

Continuous grates allow for smooth movement of cookware across the cooktop

3.9 cu. ft. oven capacity with Genuine European Convection for even baking and roasting

Self-cleaning function for hassle-free maintenance

Sleek design that complements any kitchen décor

Ideal for home chefs looking for high performance and ease of use

Features

• The Bosch industrial-style range combines a commercial look with powerful features that are designed to perform.
• Industrial-Chic Design: features heavy duty metal knobs and a bold design, along with high-performing function.
• High Efficiency Gas Burners: requires less gas BTUs to achieve a faster boiling and cooking time
• Continuous Cast Iron Grates: allows you to easily slide heavy pots and pans from burner to burner.
• Dishwasher-safe Grates: can be removed and safely cleaned directly in the dishwasher.
• Convection Multi-Rack: bake evenly on multiple racks with this powerful third element that allows for thorough heat distribution.
