Specifications

• Appliance networking
  • Automatic function Con@ctivity 2.0 :No
  • Miele@home :No
• Cleaning convenience
  • Easy to clean ceramic surface
• Construction type
  • Independent of oven
• Control Panel
  • Minute minder
  • Automatic switch-off for all rings
  • AutoBoost
  • Operation via touchpad sensors:Simple direct selection
  • Keep-warm function
  • Individual setting options (e.g. acoustic signal tones)
  • Pan/Pan-size sensors
  • Stop & Go function
• Design
  • Elegant glass ceramic surface
  • Ceramic surface color :Black
  • All-round stainless steel frame
  • Print design :LightPrint
• Fuel type
  • Fuel type: duction
• General
  • Accessories : HBD 60-22,
  • Accessories : GP GS KM 0011 M
  • Cleaning and Care Products : GP CL KM 0252 L
  • Cleaning and Care Products : GP CA ST 0252 L,
• Indicators
  • Digital power level display
• PowerFlex rings
  • Number :2
  • Diameter in mm :150x230
  • TwinBooster in W :3850
• Ring details
  • No. of rings :3
• Ring-Left Centre
  • Position :left centre
  • Diameter in mm :? 180-280
  • Maximum number of pans with FlexTouch :2
  • Power rating in W :2500
  • Booster in W :3100
  • Type :Variable cooking zone
• Ring-Right
  • Diameter in mm :230x390
  • Position :right
  • Type :PowerFlex bridge
  • Booster in W:5000
  • TwinBooster in W :7700
  • Power rating in W :3550
• Safety
  • Safety cut-out
  • Lock function
  • System lock
  • Integrated cooling blower
  • Overheating protection
  • Fault monitoring
• Standard accessories
  • Connection wire
• Technical Data
  • Dimensions (depth) in in.(mm) :21 1/2 (544)
  • Cutout dimensions (width) in in.(mm) :22 3/8 (567)
  • Built-in height with mains connection box in in.(mm):4 7/8 (121)
  • Total connected load in kW :7.7
  • Weight in lbs. (kg) :39 (18)
  • Number of phases :1
  • Dimensions in in. (width) :24 3/4 (626)
  • Cutout dimensions (depth) in in.(mm) :20 1/2 (518)
  • Fuse rating in A :32
  • Wire length in ft (m) :3 (1.2)

Description

24-inch compact design, ideal for smaller kitchens or as a secondary cooktop

Features a smooth ceramic glass surface for easy cleaning and a sleek look

Intuitive touch controls for precise temperature adjustments and ease of use

Powerful induction heating for fast, even cooking with energy efficiency

Automatic shut-off for added safety

Child lock function ensures safe operation around young children

High-quality construction for durability and long-lasting performance

Energy-efficient, offering faster cooking times compared to traditional cooking methods

Designed to fit seamlessly in kitchens with limited space

Features

• EasyClean ceramic glass:Food can no longer burn: Because the cooktop surface remains relatively cool, soiling can be removed easily.
• Turns off if no cookware is in place:Only on induction: If no pan is on a zone when the cooktop is switched on, the power supply is stopped immediately.
• Safety turn off:Clever: If a cooking zone operates at the same power level for an unusually long time, switch-off is automatic
• Safety and system lock:Extremely useful: both functions prevent accidental or unauthorized switching on of the Cooktop.
• Overheating protection and fault monitoring:Protects the Cooktop: The cooktop automatically switches off in the case of extreme heat.
• Pan size recognition:Convincing: the size of the pan is recognized by the cooktop and energy supplied to this area only.
• Efficient and safe:A clear benefit: "no heat loss with induction, and the ceramic glass surface stays relatively cool."
• Stop & Go:So nothing will burn: With this function, all cooking zones can be reduced to power level one simultaneously.
• Keeping warm function:Food ready to serve: The keep warm function controls the temperature in the pan base and prevents food burning.
• Auto heat-up:Always at the right time: This function reduces the initial power boost to prevent burning.
• Individual settings:Completely unique: basic cooktop settings can be adapted to suit personal preferences.
• Versatile cooking zone configuration:For all sorts of cookware: Perfect for a wide variety of pans.
• Timer:It makes sense: This feature allows you to set a Minute minder.
